Automatic Transmission External Controls: Removal & Installation Ford Econoline E350 Super Duty

Automatic Trans 13 illustrations ~506 words

Removal and Installation

Note. To prevent shift cable damage, do not apply force to the transmission shift cable assembly between the steering column shift tube bracket and the steering column bracket.

Scheme 375

Scheme 375: Removal and Installation

Scheme 376

Scheme 376

Scheme 377

Scheme 377

Scheme 378

Scheme 378
  1. Remove the instrument panel steering column cover, the driver side knee brace and the instrument panel steering column opening cover reinforcement.
  2. Disconnect the shift cable. Disconnect the shift cable from the steering column shift tube lever. Carefully lift the locking tab and disconnect the shift cable from the steering column bracket.
  3. Push the rubber grommet and the transmission shift cable through the bulkhead.
  4. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-231335) .
  5. Disconnect the cable at the manual control lever.
  6. Remove the locking tab and shift cable from the bracket. Discard the locking tab.
  7. Remove the shift cable bracket (all except vehicles equipped with 4.2L engine). Remove the bolts. To install, tighten to 25 m (18 lb-ft). Remove the shift cable bracket.
  8. To install, reverse the removal procedure. Adjust the shift cable. For additional information, refer to «GENERAL PROCEDURES»(ref-231387-S27564687312006050800000) .

Scheme 379

Scheme 379

Scheme 380

Scheme 380
  1. Disconnect the transmission shift cable from the steering column. Disconnect the transmission shift cable from the steering column shift tube lever. Carefully lift the locking tab and disconnect the transmission shift cable from the steering column bracket.
  2. Disconnect the cable push pin from the stud in the bulkhead.
  3. Push the rubber grommet and transmission shift cable through the bulkhead.
  4. Raise and support the vehicle. For additional information, refer to «JACKING & LIFTING»(ref-231335) .
  5. Remove the transmission shift cable from the transmission. Disconnect the transmission shift cable from the manual control lever.
  6. Remove the shift cable bracket from the transmission. Remove the bolts. To install, tighten to 48 Nm (35 lb-ft).
  7. To install, reverse the removal procedure. Adjust the shift cable. For additional information, refer to «CABLE AND BRACKET ADJUSTMENT»(ref-231387-S21006528112006050800000) .

Scheme 381

Scheme 381: Removal and Installation

Scheme 382

Scheme 382

Scheme 383

Scheme 383

Scheme 384

Scheme 384

Scheme 385

Scheme 385

Scheme 386

Scheme 386
  1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-231356) .
  2. If equipped with tilt column, position the steering wheel in the full DOWN position.
  3. Pull the headlamp knob to the ON position.
  4. Insert a small screwdriver onto the clip and pull the knob outward.
  5. Remove the headlamp switch bezel by turning it counterclockwise.
  6. Remove the audio unit. For additional information, refer to «AUDIO UNIT»(ref-231406) .
  7. Remove the 2 instrument cluster finish panel screws.
  8. Remove the instrument cluster finish panel. Disconnect the electrical connectors.
  9. Remove the ignition switch lock cylinder. Position the lock cylinder to RUN. Using a suitable tool, push upward on the cylinder release tab through the hole in the lower shroud while pulling the cylinder outward.
  10. Remove the upper steering column shroud.
  11. Remove the transmission range selector lever. Disconnect the electrical connector.
  12. To install, reverse the removal procedure.

Scheme 387

Scheme 387: Removal and Installation
  1. Remove the transmission control (TC) switch. Remove the switch cover. Remove the switch.
  2. To install, reverse the removal procedure.
