Bumper System Ford Econoline E250

Exterior Body Panels 3 illustrations ~295 words

SPECIFICATIONS

DescriptionNm
Front bumper mounting plate bolts23
Front bumper retaining nuts80
Rear bumper retaining nuts70

TORQUE SPECIFICATIONS

Bumper Rust Prevention - Front, Chrome

ItemSpecification
High Temperature Anti-Corrosion Coating PM-13-A
Motorcraft® Custom Bright Metal Cleaner ZC-15ESR-M5B194-B

MATERIAL SPECIFICATIONS

Scheme 1

Scheme 1
  1. If equipped, remove the license plate bracket.
  2. Remove the front bumper. For additional information, refer to «BUMPER - FRONT»(/ford/econoline-e250/2012-2013/remont/exterior-body-panels/#bumper-system) .
  3. Clean excessive dirt from an area of 2" (50 mm) around the center vent on the inside of the bumper.
  4. Clean the red rust stains from the inside edges of the center vent opening with Motorcraft Custom Bright Metal Cleaner.
  5. Apply masking tape around the center vent opening on the outside chrome part of the front bumper allowing for a 1 inch overhang into the opening.
  6. Using a foam brush, paint the edge of the center vent opening and at least 1" (25 mm) around the inside of the front bumper with the Motorcraft Anti-Corrosion Coating.
  7. Remove the masking tape around the center vent opening.
  8. Install the front bumper. For additional information, refer to «BUMPER - FRONT»(/ford/econoline-e250/2012-2013/remont/exterior-body-panels/#bumper-system) .
  9. If equipped, install the license plate bracket.

Scheme 2

Scheme 2: Removal and Installation
ItemPart NumberDescription
1W503924-SFront bumper-to-valence panel screw (7 required)
2011901-AFront bumper nut (4 required)
317626-AValence panel
417C786-AValence panel pushpin (8 required)
517B884-AFront bumper mounting plate
6W505435-SFront bumper mounting plate bolt (8 required)
717981-AFront bumper reinforcement bracket (2 required)
817C965-CFront bumper
  1. Remove the valence panel in the following sequence. Remove the A/C condenser air deflector. Remove the 7 front bumper-to-valence panel screws. Remove the 8 pushpin retainers. Remove the wiring harness retainer for the block heater cord.
  2. Remove the front bumper in the following sequence. Remove the 4 nuts. Remove the 4 bolts and remove the bumper. To install, tighten to 80 Nm (59 lb-ft).
  3. To install, reverse the removal procedure.

Removal and Installation

Note. Step-type bumper shown in illustration, standard bumper similar.

Scheme 3

Scheme 3: Removal and Installation
ItemPart NumberDescription
1N804525Nut (4 required)
214A624Parking aid electrical connector
3Parking aid sensor electrical connector
417906Bumper
  1. Remove the 4 retaining nuts from the rear bumper. To install, tighten to 70 Nm (52 lb-ft).
  2. Disconnect the rear parking aid sensor electrical connector.
  3. If equipped, remove the trailer hitch wiring retainers.
  4. Remove the rear bumper.
  5. To install, reverse the removal procedure.
