Automatic Transmission Cooling System Ford Econoline E250

Automatic Trans 24 illustrations ~1404 words

SPECIFICATIONS

ItemSpecificationFill Capacity
Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVMERCON® LV18.0L (1) (19.2 qt)
Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVMERCON® LV13.1L (2) (13.9 qt)
(1) TorqShift® transmission (2) 4R75E transmission
(1)TorqShift® transmission
(2)4R75E transmission

MATERIAL SPECIFICATIONS

DescriptionNm
Auxiliary transmission fluid cooler bolts8
Battery cable12
Ground cable20
Solenoid wire6
Transmission fluid cooler tube bracket-to-engine stud nut (gas)12
Transmission fluid cooler tube fitting (4R75E)27
Transmission fluid cooler tube fitting (TorqShift®)40

TORQUE SPECIFICATIONS

The transmission fluid cooling system, without an auxiliary transmission fluid cooler, consists of

  1. an in-tank fluid cooler inlet tube.
  2. a non-repairable in-tank transmission fluid cooler.
  3. an in-tank fluid cooler return tube.

The transmission fluid cooling system, with an auxiliary transmission fluid cooler, consists of

  1. an in-tank fluid cooler inlet tube.
  2. a non-repairable in-tank transmission fluid cooler.
  3. fluid cooler hoses.
  4. hose clamps.
  5. an auxiliary transmission fluid cooler.
  6. a fluid cooler return tube.

The transmission fluid flows from the transmission (front fitting for TorqShift®, bottom fitting for the 4R75E), to the in-tank transmission fluid cooler, to the auxiliary transmission fluid cooler (if equipped) and returns to the transmission (rear fitting for TorqShift®, top fitting for 4R75E).

For the Transmission Fluid Cooler Backflushing and Cleaning procedures, refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .

Scheme 311

Scheme 311: Transmission Cooling Components - TorqShift® Transmission
Scheme 311: Transmission Cooling Components - TorqShift® Transmission
ItemPart NumberDescription
17H420Transmission fluid cooler tube inlet fitting
27H420Transmission fluid cooler tube outlet fitting
3N811309Transmission
47890Auxiliary transmission fluid cooler outlet hose
57A095Auxiliary transmission fluid cooler
67890Auxiliary transmission fluid cooler inlet hose
77J081Transmission fluid cooler tube secondary latch
88C2P-7C107-AAClamps
98C2P-7C107-AAClamps

Scheme 312

Scheme 312: Transmission Cooling Components - 4R75E Transmission
Scheme 312: Transmission Cooling Components - 4R75E Transmission
ItemPart NumberDescription
18005Radiator (with in-tank transmission fluid cooler)
27A095Auxiliary transmission fluid cooler
37D273Transmission fluid cooler tube outlet fitting
47D273Transmission fluid cooler tube inlet fitting
57R081Transmission fluid cooler return tube
67R081In-tank transmission fluid cooler inlet tube
74R75E transmission
8W714762Clamps

Inspection and Verification

Note. When internal wear/damage occurs in the transmission, metal particles, clutch plate material and band material can travel into the torque converter, the transmission fluid cooler tubes, the in-tank transmission fluid cooler and the auxiliary transmission fluid cooler, if equipped. These contaminants are a major cause of recurring transmission concerns. To prevent future concerns, remove these contaminants from the cooling system before placing the transmission back into use. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT for the Transmission Fluid Cooler Flow Test, Transmission Fluid Cooler Backflushing and Cleaning and Torque Converter Contamination Inspection procedures.

  1. Visually inspect for obvious signs of mechanical damage, incorrect component installation and system leaks. Repair as necessary. Install a new or remanufactured radiator when transmission fluid is found leaking from the in-tank transmission fluid cooler. Refer to «ENGINE COOLING»(/ford/econoline-e250/2012-2013/remont/cooling-system-mechanical/#engine-cooling-system) . Install a new O-ring seal when transmission fluid is found leaking between the radiator transmission fluid cooler and the transmission fluid cooler fitting (not the cooler tube into the fitting). Refer to «COMPONENT TEST»(/ford/econoline-e250/2012-2013/remont/automatic-trans/#automatic-transmission-cooling-system) . Install a new auxiliary transmission fluid cooler if there is leakage from the auxiliary transmission fluid cooler, and always as part of a transmission overhaul or exchange. Refer to «AUXILIARY TRANSMISSION FLUID COOLER»(/ford/econoline-e250/2012-2013/remont/automatic-trans/#automatic-transmission-cooling-system__auxiliary-transmission-fluid-cooler) .
  2. If the fault is not visually evident, GO to «SYMPTOM CHART»(/ford/econoline-e250/2012-2013/remont/automatic-trans/#automatic-transmission-cooling-system__symptom-chart-transmission-cooling) .

Symptom Chart - Transmission Cooling

ConditionPossible SourcesAction
Transmission overheatingIncorrect transmission fluid levelCHECK and, if necessary, ADJUST the transmission fluid to the correct level. REFER to Preliminary Inspection in AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or Preliminary Inspection in AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
Transmission fluid conditionCHECK transmission fluid condition. REFER to Preliminary Inspection in AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or Preliminary Inspection in AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
Incorrect transmission fluid typeREFER to SPECIFICATIONS .
Transmission cooling system damaged, blocked, restricted or installed incorrectlyCARRY OUT the Transmission Fluid Cooler Flow Test. REFER to Transmission Fluid Cooler Flow Test in AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or Transmission Fluid Cooler Flow Test in AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
System leaksREFER to Leakage Inspection in AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or Leakage Inspection in AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
Excessive vehicle or towing loads, severe vehicle useREFER to the vehicle specification manual for load and GVW information. REFER to the Owner's Literature.
Engine overheatingREFER to ENGINE COOLING .
Powertrain control system electrical inputs/outputs, vehicle wiring harness, PCM, Torque Converter Clutch (TCC) solenoidCARRY OUT On-Board Diagnostic (OBD) test. REFER to the INTRODUCTION - GASOLINE MODELS . REFER to Diagnostics in AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or Diagnostics in AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
Internal transmission concernsREFER to Diagnosis by Symptom in AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or Diagnosis by Symptom in AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
Transmission fluid leak at radiator in-tank transmission fluid coolerTransmission fluid cooler-to-fluid cooler fittingREFER to the COMPONENT TEST .

SYMPTOM CHART - TRANSMISSION COOLING

Symptom Chart - NVH

Note. NVH symptoms should be identified using the diagnostic tools that are available. For a list of these tools, an explanation of their uses and a glossary of common terms, refer to NOISE, VIBRATION & HARSHNESS . Since it is possible any one of multiple systems may be the cause of a symptom, it may be necessary to use a process of elimination type of diagnostic approach to pinpoint the responsible system. If this is not the causal system for the symptom, refer back to NOISE, VIBRATION & HARSHNESS for the next likely system and continue diagnosis.

ConditionPossible SourcesAction
Vibration - a high frequency (20-80 Hz) that is felt through the seat or selector lever. Changes with engine speedTransmission fluid cooler tubes grounded outCHECK the transmission fluid cooler tubes. REPAIR as necessary. REFER to TRANSMISSION FLUID COOLER TUBES - 4R70E, 4R75E or TRANSMISSION FLUID COOLER TUBES - TORQSHIFT .

SYMPTOM CHART - NVH

Transmission Fluid Cooler Leaks at Radiator

Transmission fluid may leak between the radiator in-tank transmission fluid cooler and the transmission fluid cooler fitting (not the transmission fluid cooler tube into the fitting), which may result in a residue of transmission fluid on the radiator tank around the transmission fluid cooler fitting. This may be caused by insufficient thread sealer on the transmission fluid cooler fitting.

  1. Clean the area around the transmission fluid cooler fittings.
  2. Verify that transmission fluid is leaking between the transmission fluid cooler tube fitting into the transmission fluid cooler (not the transmission fluid cooler and the transmission fluid cooler fitting). Inspect the rubber transmission fluid cooler hose and the transmission fluid cooler fitting clamp. If the leak is at the transmission fluid cooler fitting, install a new transmission fluid cooler fitting clamp or the transmission fluid cooler hose.
  3. If the leak is at the transmission cooler fittings, install a new radiator. Refer to «ENGINE COOLING»(/ford/econoline-e250/2012-2013/remont/cooling-system-mechanical/#engine-cooling-system) .

Auxiliary Transmission Fluid Cooler

ItemSpecification
Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVMERCON® LV

MATERIAL SPECIFICATIONS

Scheme 313

Scheme 313: Auxiliary Transmission Fluid Cooler
Scheme 313: Auxiliary Transmission Fluid Cooler
ItemPart NumberDescription
1Radiator grille pushpin (5 required)
2Radiator grille
38C2P-7C107-AAHose clamps
4N606676-SAuxiliary transmission fluid cooler bolts
57A095Auxiliary transmission fluid cooler

Removal

  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/econoline-e250/2012-2013/remont/hoistjack/#jacking-lifting) .
  2. Remove the 5 pushpins and the radiator grille.
  3. Remove the transmission fluid cooler hoses from the auxiliary transmission fluid cooler.
  4. Remove the 3 bolts and the auxiliary transmission fluid cooler.

Installation

  1. Install the auxiliary transmission fluid cooler and the 3 bolts. Tighten to 8 Nm (71 lb-in).
  2. Install the transmission fluid cooler hoses to the auxiliary transmission fluid cooler. Install the hose clamps.
  3. Install the radiator grille.
  4. Fill the transmission with the specified type and quantity of transmission fluid. For additional information, refer to Transmission Fluid Drain and Refill in «AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E»(/ford/econoline-e250/2012-2013/remont/automatic-trans/#automatic-transmission-4r70ew-4r75ew) or Transmission Fluid Drain and Refill in «AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT»(/ford/econoline-e250/2012-2013/remont/automatic-trans/#automatic-transmission-5r110w-torqshiftr) .
  5. Check for leaks.

Transmission Fluid Cooler Tubes - 4R70E, 4R75E

ItemSpecification
Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVMERCON® LV

MATERIAL SPECIFICATIONS

Scheme 314

Scheme 314: Transmission Fluid Cooler Tubes
Scheme 314: Transmission Fluid Cooler Tubes
ItemPart NumberDescription
17R081Transmission fluid cooler tube fitting
27R081Transmission fluid cooler tube fitting
38287Clamps
47B028Transmission fluid cooler hose
57C410Transmission fluid cooler hose

Scheme 315

Scheme 315: Removal and Installation
Scheme 315: Removal and Installation

Scheme 316

Scheme 316
Scheme 316

Scheme 317

Scheme 317
Scheme 317

Scheme 318

Scheme 318
Scheme 318

Scheme 319

Scheme 319
Scheme 319

Scheme 320

Scheme 320
Scheme 320
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/econoline-e250/2012-2013/remont/hoistjack/#jacking-lifting) .
  2. If equipped, remove the pushpin retainers and the splash shield.
  3. Remove the 6 screws and the lower air deflector.
  4. Remove the transmission fluid cooler tubes from the bracket.
  5. Remove the transmission fluid cooler hoses from the radiator in-tank transmission fluid cooler and the pushpin retainers.
  6. Remove the transmission fluid cooler hoses from the auxiliary transmission fluid cooler and the pushpin retainers.
  7. Remove the transmission fluid cooler tube fittings from the transmission. To install, tighten to 27 Nm (20 lb-ft).
  8. To install, reverse the removal procedure. Fill the transmission with transmission fluid. For additional information, refer to Transmission Fluid Drain and Refill in «AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E»(/ford/econoline-e250/2012-2013/remont/automatic-trans/#automatic-transmission-4r70ew-4r75ew) . Check for leaks.

Transmission Fluid Cooler Tubes - TorqShift

SPECIAL TOOLS CHART Disconnect Tool, Transmission Cooler Line 307-459

Scheme 321

Scheme 321: Transmission Fluid Cooler Tubes - TorqShift
Scheme 321: Transmission Fluid Cooler Tubes - TorqShift
ItemSpecification
Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVMERCON® LV

MATERIAL SPECIFICATIONS

Scheme 322

Scheme 322: Transmission Fluid Cooler Tubes
Scheme 322: Transmission Fluid Cooler Tubes
ItemPart NumberDescription
17C1C7Clamps
27Z465Transmission fluid cooler tube secondary latch
37890Transmission fluid cooler hose
47890Transmission fluid cooler hose
57R081Transmission fluid cooler tube assembly
6Transmission fluid cooler tube fittings

Scheme 323

Scheme 323
Scheme 323

Scheme 324

Scheme 324
Scheme 324

Scheme 325

Scheme 325
Scheme 325

Scheme 326

Scheme 326
Scheme 326

Scheme 327

Scheme 327
Scheme 327

Scheme 328

Scheme 328
Scheme 328

Scheme 329

Scheme 329
Scheme 329

Scheme 330

Scheme 330
Scheme 330

Scheme 331

Scheme 331
Scheme 331
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/econoline-e250/2012-2013/remont/hoistjack/#jacking-lifting) .
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/econoline-e250/2012-2013/remont/charging-system/#battery-battery-mounting-battery-cables) .
  3. If equipped, remove the pushpin retainers and the splash shield.
  4. Remove the pushpin retainers and the lower air deflector.
  5. Remove the transmission fluid cooler tubes from the transmission case.
  6. Remove the transmission fluid cooler tube secondary latch from the transmission fluid cooler hose.
  7. Using the Transmission Cooler Line Disconnect Tool, disconnect the transmission fluid cooler hose.
  8. Disconnect the fluid cooler hose from the radiator.
  9. Remove the nut for the transmission cooler tubes and starter motor electrical harness front bracket, and move the bracket aside.
  10. If equipped, remove the transmission cooler tubes from the bracket.
  11. Remove the starter motor solenoid terminal cover.
  12. Disconnect the starter motor electrical connections.
  13. Disconnect the starter motor electrical harness pushpin and move the harness to the front of the vehicle.
  14. Remove the transmission fluid cooler tubes from the vehicle.

Scheme 332

Scheme 332
Scheme 332

Scheme 333

Scheme 333
Scheme 333

Scheme 334

Scheme 334
Scheme 334
  1. Install the transmission fluid cooler tubes into the vehicle.
  2. Reposition the starter motor electrical harness to the rear of the vehicle and connect the pushpin.
  3. Connect the starter motor electrical connections. Tighten the ground cable to 20 Nm (177 lb-in). Tighten the battery cable to 12 Nm (106 lb-in). Tighten solenoid wire to 6 Nm (53 lb-in).
  4. Install the starter motor solenoid terminal cover.
  5. If equipped, install the transmission fluid cooler tubes into the bracket.
  6. Install the transmission fluid cooler tubes bracket-to-engine stud nut. Tighten to 12 Nm (106 lb-in).
  7. Connect the transmission fluid cooler hose.
  8. Install the transmission fluid cooler tube secondary latch onto the transmission fluid cooler hose.
  9. Install the transmission fluid cooler hose onto the radiator fitting.
  10. Install the transmission fluid cooler tube fittings. Tighten to 27 Nm (20 lb-ft).
  11. Install the lower air deflector and the pushpin retainers.
  12. If equipped, install the splash shield and the pushpin retainers.
  13. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/econoline-e250/2012-2013/remont/charging-system/#battery-battery-mounting-battery-cables) .
  14. Fill the transmission with the specified transmission fluid type and quantity. For additional information, refer to Transmission Fluid Drain and Refill in «AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT»(/ford/econoline-e250/2012-2013/remont/automatic-trans/#automatic-transmission-5r110w-torqshiftr) .
  15. Check for leaks.
