Supplemental Restraint System Ford Econoline E250

SPECIFICATIONS

TORQUE SPECIFICATIONS

The Supplemental Restraint System (SRS) is designed to provide increased collision protection for front seat occupants in addition to that provided by the 3-point safety belt system. Safety belt use is necessary to obtain the best occupant protection and to receive the full advantages of the SRS.

The serviceable air bag and safety belt pretensioner SRS components are shown in the following illustration.

Scheme 1

SPECIAL TOOLS CHART Flex Probe Kit NUD105-R025D or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 2

Principles of Operation

The Restraints Control Module (RCM) continuously receives/monitors inputs from the following Supplemental Restraint System (SRS) components.

1. Front impact severity sensor
2. Driver safety belt buckle switch
3. Passenger Air Bag Deactivation (PAD) switch

If the RCM detects sudden vehicle deceleration and/or lateral deceleration based on all the information received from all sensors and switches and determines that deployment is required, the RCM sends voltage and current to deploy the appropriate SRS components.

During a frontal crash, the RCM may deploy the following SRS components, based on crash severity and sensor input.

1. Safety belt buckle pretensioner(s)
2. Driver and passenger single-stage air bags

The fact that the safety belt buckle pretensioners or air bags did not activate for both front seat occupants in a crash does not mean that something is wrong with the system.

The RCM performs a self-test of the complete SRS during each startup. If a SRS fault exists, the air bag warning indicator will illuminate and remain illuminated for the rest of the ignition cycle. In addition to the self-test at start up, the RCM continuously monitors all of its SRS components and circuitry for correct operation.

Air Bag Warning Indicator

The air bag warning indicator

1. located in the Instrument Panel Cluster (IPC) module will prove out by lighting for 6 seconds and then turn off.
2. will flash and/or illuminate based on the message the IPC module receives from the RCM.
3. will illuminate if the IPC module does not receive a message from the RCM.

Clockspring

The clockspring

1. allows for continuous electrical connections between the driver air bag module and the RCM when the steering wheel is turned.

Driver Air Bag Module

The driver air bag module

1. is a single stage air bag and will deploy depending on vehicle impact severity and sensor input.

High Speed Controller Area Network (HS-CAN)

This vehicle utilizes a communication system called a High Speed Controller Area Network (HS-CAN). The RCM communicates with various modules for required information about the vehicle. Refer to MODULE COMMUNICATIONS NETWORK for information about the HS-CAN.

Passenger Air Bag Module

The passenger air bag module

1. is a single stage air bag and will deploy depending on vehicle impact severity and sensor input.

Restraints Control Module (RCM)

Note. This vehicle is equipped with the SYNC® feature which supports the 911 assist option. Refer to the Owner's Literature.

The RCM carries out the following functions

1. Activates the driver/passenger air bag modules depending upon vehicle impact severity and sensor input, in the event of a deployable collision
2. Activates the safety belt buckle pretensioners to remove slack from the safety belt in the event of a deployable collision
3. Monitors the SRS for faults
4. Sends a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator if a fault is detected
5. Communicates through the Data Link Connector (DLC) the current and/or historical DTCs

The RCM monitors the SRS for possible faults. If a fault is detected, the RCM will request the IPC module to illuminate the air bag warning indicator. When the ignition is turned OFF and then ON, the IPC module will prove out the air bag warning indicator by lighting for 6 seconds. If no faults are detected by the RCM the IPC module will turn the air bag warning indicator off and it will remain off. If the RCM detects a fault, it will send a message to the IPC module to turn the air bag warning indicator on and it will remain on for the rest of the key cycle. If the RCM requests illumination of the air bag warning indicator and the air bag warning indicator does not function, the IPC module will automatically activate an audible chime. The chime is a series of 5 sets of 5 tone bursts. If the chime is heard, the SRS and the air bag warning indicator require repair.

The RCM includes a backup power supply. The backup power supply will deploy the SRS components in the event that the ignition circuit is lost or damaged during impact. The backup power supply will deplete its stored energy approximately one minute after power and/or ground has been removed from the RCM. The backup power supply will deplete its stored energy approximately one minute after the battery ground cable is disconnected.

The RCM will also communicate the on-demand (current) and continuous (historical) DTCs through the DLC to the scan tool.

Safety Belt Buckle Switches

The driver safety belt buckle is comprised of integrated circuits called a Hall-effect switch. The safety belt buckle switch indicates to the RCM whether the safety belt are buckled or unbuckled.

The RCM also communicates the driver safety belt buckle switch status to the IPC module, which monitors the information to control the safety belt warning indicator. For information on the safety belt warning indicator, refer to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .

Safety Belt Buckle Pretensioners

The safety belt buckle pretensioners remove excess slack from the safety belt webbing. The pretensioners are activated by the RCM when the module detects a crash event force exceeding a programmed limit.

Secondary Air Bag Warning (Chime)

The secondary air bag warning chime is an audible chime located in and controlled by the IPC module. If a fault is detected with the air bags warning indicator a DTC will be stored in memory of the IPC module. Upon receiving the message from the RCM that a SRS fault has been detected, the IPC module will sound the secondary air bag warning chime in a pattern of 5 sets of 5 beeps.

Impact Sensors (Restraints Sensor)

For this vehicle line, the SRS uses one satellite sensor in addition to the RCM. The RCM is mounted beneath the driver seat. All vehicles have one front impact severity sensor located in the front-center area of the vehicle, behind the grille mounted on the radiator support. Mounting orientation is critical for correct operation of all impact sensors.

The air bag warning indicator may not illuminate to indicate a fault is present until approximately 30 seconds after the ignition switch has been turned from the OFF to the ON position. This is the time required for the RCM to complete the testing of the SRS. If the air bag warning indicator is inoperative and an SRS fault exists, a chime will sound in a pattern of 5 sets of 5 beeps. If this occurs, the air bag warning indicator will need to be repaired before diagnosis can continue.

Inspection and Verification

1. Verify the customer concern by checking the air bag warning indicator in the IPC module. Refer to Prove Out the System in this article.
2. Visually inspect for obvious signs of mechanical or electrical damage. Do not disconnect electrical connectors until directed to do so within the pinpoint test. VISUAL INSPECTION CHART Mechanical Electrical Damaged Restraints Control Module (RCM) or loose mounting Damaged front impact severity sensor Damaged Passenger Air Bag Deactivation (PAD) switch Open Smart Junction Box (SJB) fuse(s): 32 (10A) 46 (7.5A) Damaged wiring harness Loose, damaged or corroded connectors Circuitry open/shorted Damaged shorting bars
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the cause is not visually evident, connect the scan tool to the DLC.
5. If the scan tool does not communicate with the VCM: check the VCM connection to the vehicle. check the scan tool connection to the VCM. refer to «MODULE COMMUNICATIONS NETWORK»(/ford/econoline-e250/2012-2013/remont/communication-devices/#module-communications-network) , No Power To The Scan Tool, to diagnose no power to the scan tool.
6. If the scan tool does not communicate with the vehicle: verify the ignition is in the ON position. verify the scan tool operation with a known good vehicle. refer to «MODULE COMMUNICATIONS NETWORK»(/ford/econoline-e250/2012-2013/remont/communication-devices/#module-communications-network) to diagnose no response from the PCM.
7. Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/econoline-e250/2012-2013/remont/communication-devices/#module-communications-network) . If the network test passes, retrieve and record on-demand and Continuous Memory Diagnostic Trouble Codes (CMDTCs) from the RCM.
8. If the DTCs retrieved are related to the concern, go to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) . For all other DTCs, refer to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/econoline-e250/2012-2013/remont/cruise-control-systems/#multifunction-electronic-modules) .
9. If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__symptom-chart) .

Restraints Control Module (RCM) DTC Chart

While the LFCs are an indication of a general concern in the SRS , the DTCs are more specific. The DTCs can be retrieved from the RCM with a scan tool via the DLC .

Note. Always make sure the correct Supplemental Restraint System (SRS) component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. This module utilizes a 5-character DTC followed by a 2-character failure type code. The failure type code provides information about specific fault conditions such as opens or shorts to ground. Continuous Memory Diagnostic Trouble Codes (CMDTCs) have an additional 2-character DTC status code suffix to assist in determining DTC history.

RESTRAINTS CONTROL MODULE (RCM) DTC DESCRIPTION CHART

Symptom Chart

SYMPTOM CHART

Pinpoint Test A: The Air Bag Warning Indicator is Illuminated Continuously

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

Normal Operation

During normal operation, the Instrument Panel Cluster (IPC) module will illuminate the air bag indicator continuously for 6 seconds after the ignition is placed in the ON position. If the Supplemental Restraint System (SRS) is fault free, the air bag warning indicator will turn off and remain off. If a fault is detected in the SRS, the air bag warning indicator will illuminate and remain illuminated for the rest of the ignition cycle until the fault is no longer detected. The Restraints Control Module (RCM) communicates to the IPC module via the High Speed Controller Area Network (HS-CAN). The IPC module will illuminate the air bag warning indicator based on messaging from the RCM or if there is no communication between the RCM and IPC module.

This pinpoint test is intended to diagnose the following

1. IPC module
2. RCM

Note. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

1. A1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Were any DTCs retrieved on-demand during self-test? Yes : If DTCs were retrieved, GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. Do not clear any DTCs until all DTCs have been resolved. No : If the RCM does communicate with the scan tool, REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#information-center-instrumentation-message-center-and-warning-chimes) to diagnose the IPC module concern. If the RCM does not communicate with the scan tool, REFER to «MODULE COMMUNICATIONS NETWORK»(/ford/econoline-e250/2012-2013/remont/communication-devices/#module-communications-network) No Power To The Scan Tool, to diagnose no power to the scan tool. Do not clear any DTCs until all DTCs have been resolved.

Pinpoint Test B: DTCs B0001:11, B0001:12, B0001:13 and B0001:1A

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) continuously monitors driver air bag module stage 1 and circuits for the following faults

1. Resistance out of range
2. Unexpected voltage
3. Short to ground
4. Faulted driver air bag module

If a fault is detected, the RCM will store DTC B0001:11, B0001:12, B0001:13 or B0001:1A in memory and send a message to the IPC module to illuminate the air bag warning indicator.

The RCM analyzes the deployment loop resistance and uses this measurement in combination with an age correction factor to determine if a fault exists. The value displayed in the PID is the deployment loop resistance as measured by the RCM. If the value displayed is lower or higher than the desired range ( (Scheme 2)below), the RCM can set a DTC. As the deployment loop resistance drifts farther outside the desired range, the chance for a DTC increases. The RCM fault trigger threshold may vary as the vehicle ages. Small variations in resistance can occur due to the effect of road vibrations on terminal fit and/or temperature changes. These variables can result in an intermittent fault. For this reason, the test will require the PID value to be within the desired range before the fault is considered repaired, regardless if the module is reporting an on-demand DTC at time of diagnosis. Following this direction will help make sure that minor changes in resistance do not create a repeat concern. This test will use a process of elimination to diagnose each part of the deployment loop circuit including

Scheme 3

1. Wiring
2. Connections
3. Clockspring
4. Driver air bag module
5. RCM

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Clockspring
3. Driver air bag module
4. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. B1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0001:11, B0001:12, B0001:13 and B0001:1A retrieved on-demand during self test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. For B0001:13 or B0001:1A, GO to B2. For B0001:11, GO to B12 . For B0001:12, GO to B15 . No : This is an intermittent fault when present as a CMDTC only. For B0001:13 or B0001:1A, GO to B20 . For B0001:11, GO to B21 . For B0001:12, GO to B22 .
2. B2 CHECK THE DRIVER AIR BAG STAGE 1 RESISTANCE (DEPLOY_00_R) PID Enter the following diagnostic mode on the scan tool: DataLogger - RCM. DEPLOY_00_R PID Does the PID value read between 2 and 3.68 ohms? Yes : GO to B19 . No : GO to B3.
3. B3 CHECK THE DRIVER AIR BAG STAGE 1 RESISTANCE (DEPLOY_00_R) PID WHILE CARRYING OUT A HARNESS TEST NOTE: Do not remove the driver air bag module from its mounted position at this time. While monitoring the DEPLOY_00_R PID, carry out a harness test of the driver air bag circuits and accessible connectors (including any in-line connectors) by wiggling and flexing the wire harness, connectors, tilting and rotating the steering wheel frequently. Does the PID value read between 2 and 3.68 ohms while carrying out the harness test? Yes : DEPOWER the SRS and REPAIR the connector, terminals or wire harness or INSTALL a new clockspring as needed. REFER to «CLOCKSPRING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to B24 . No : For PID value less than 2 ohms, GO to B4. For PID value greater than 3.68 ohms, GO to B8 .
4. B4 CHECK THE DRIVER AIR BAG STAGE 1 FOR DTC FAULT STATUS CHANGE (LOW RESISTANCE INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver air bag module disconnected, open circuit fault would normally be retrieved on stage 1 and 2. Did the on-demand DTC change from B0001:1A to B0001:13? Yes : GO to B17 . No : GO to B5.
5. B5 CHECK THE DRIVER AIR BAG STAGE 1 DTC FOR FAULT STATUS CHANGE (LOW RESISTANCE INDICATED) (CLOCKSPRING DISCONNECTED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Disconnect: Clockspring C218A. Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver air bag module disconnected, open circuit fault would normally be retrieved on stage 1 and 2. Did the on-demand DTC change from B0001:1A to B0001:13? Yes : GO to B18 . No : GO to B6.
6. B6 CHECK FOR A SHORT BETWEEN DRIVER AIR BAG STAGE 1 CIRCUITS Measure the resistance between clockspring C218A-1, circuit CR101 (VT/BN), harness side and C218A-3, circuit RR101 (YE/GN), harness side. Is the resistance greater than 10, 000 ohms? Yes : GO to B7. No : REPAIR circuits CR101 (VT/BN) and RR101 (YE/GN). GO to B24 .
7. B7 CHECK THE RCM FOR LOW RESISTANCE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between RCM C310A pins 3 and 4, component side. Is the resistance greater than 10, 000 ohms? Yes : REPAIR circuits CR101 (VT/BN) and RR101 (YE/GN). GO to B24 . No : GO to B19 .
8. B8 CHECK THE DRIVER AIR BAG STAGE 1 CIRCUITS FOR AN OPEN Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between RCM C310A, harness side and driver air bag module stage 1 C216, harness side using the following chart. RCM Circuit Driver Air Bag Module Electrical Connector C310A-4 CR101 (VT/BN) C216-1 C310A-3 RR101 (YE/GN) C216-2 Are the resistances less than 1 ohm? Yes : GO to B10 . No : GO to B9.
9. B9 CHECK THE DRIVER AIR BAG MODULE STAGE 1 CIRCUITS FOR AN OPEN (CLOCKSPRING DISCONNECTED) Disconnect: Clockspring C218A. Measure resistance between RCM C310A, harness side and clockspring C218A, harness side using the following chart. RCM Circuit Clockspring Electrical Connector C310A-4 CR101 (VT/BN) C218A-1 C310A-3 RR101 (YE/GN) C218A-3 Are the resistances less than 0.5 ohm? Yes : GO to B18 . No : REPAIR circuit CR101 (VT/BN) or RR101 (YE/GN). GO to B24 .
10. B10 CHECK THE DRIVER AIR BAG STAGE 1 DTC FOR FAULT STATUS CHANGE (OPEN INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Connect: RCM C310A and C310B. Connect a fused jumper wire between driver air bag module stage 1 C216 pins 1 and 2, harness side. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver air bag module stage 1 circuits shorted together, a low resistance fault would normally be retrieved. Was DTC B0001:1A retrieved on-demand during self-test? Yes : GO to B17 . No : GO to B11.
11. B11 CHECK THE DRIVER AIR BAG STAGE 1 CIRCUITS FOR AN OPEN (CLOCKSPRING DISCONNECTED) Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the fused jumper wire from the driver air bag module electrical connector. Disconnect: Clockspring C218A. Connect a fused jumper wire between clockspring electrical connector C218A pins 1 and 3, harness side. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the clockspring stage 1 circuits shorted together, a low resistance fault would normally be retrieved. Was DTC B0001:1A retrieved on-demand during self-test? Yes : GO to B18 . No : GO to B19 .
12. B12 CHECK THE DRIVER AIR BAG STAGE 1 DTC FOR FAULT STATUS CHANGE (SHORT TO GROUND INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver air bag module disconnected, open circuit faults would normally be retrieved. Did the on-demand DTC change from B0001:11 to B0001:13? Yes : GO to B17 . No : GO to B13.
13. B13 CHECK THE DRIVER AIR BAG STAGE 1 DTC FOR FAULT STATUS CHANGE (SHORT TO GROUND INDICATED) (CLOCKSPRING DISCONNECTED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Disconnect: Clockspring C218A. Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the clockspring disconnected, open circuit faults would normally be retrieved. Did the on-demand DTC change from B0001:11 to B0001:13? Yes : GO to B18 . No : GO to B14.
14. B14 CHECK THE DRIVER AIR BAG STAGE 1 CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between clockspring: C218A-1, circuit CR101 (VT/BN), harness side and ground. C218A-3, circuit RR101 (YE/GN), harness side and ground. Are the resistances greater than 10, 000 ohms? Yes : GO to B19 . No : Due to the shorting bar feature in the RCM electrical connector, the fault can exist in either circuit. Do not remove or defeat the shorting bar. REPAIR circuit CR101 (VT/BN) or RR101 (YE/GN). GO to B24 .
15. B15 CHECK THE DRIVER AIR BAG STAGE 1 DTC FOR FAULT STATUS CHANGE (SHORT TO BATTERY INDICATED) (CLOCKSPRING DISCONNECTED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Clockspring C218A. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver air bag module/clockspring disconnected, open circuit fault would normally be retrieved. Did the on-demand DTC change from B0001:12 to B0001:13? Yes : GO to B18 . No : GO to B16.
16. B16 CHECK THE DRIVER AIR BAG STAGE 1 CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between clockspring: C218A-1, circuit CR101 (VT/BN), harness side and ground. C218A-3, circuit RR101 (YE/GN), harness side and ground. Is voltage present on either circuit? Yes : Due to the shorting bar feature in the RCM electrical connector, the fault can exist in either circuit. Do not remove or defeat the shorting bar. REPAIR circuit CR101 (VT/BN) or RR101 (YE/GN). GO to B24 . No : GO to B19 .
17. B17 CONFIRM THE DRIVER AIR BAG MODULE FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If previously installed, remove the fused jumper wire between driver air bag module. Install the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new driver air bag module. REFER to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to B24 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . For B0001:13 or B0001:1A, GO to B20 . For B0001:11, GO to B21 . For B0001:12, GO to B22 .
18. B18 CONFIRM THE CLOCKSPRING FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If previously installed, remove the fused jumper wire from the driver air bag module electrical connector. Connect: Clockspring C218A. Install the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new clockspring. REFER to «CLOCKSPRING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to B24 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . For B0001:13 or B0001:1A, GO to B20 . For B0001:11, GO to B21 . For B0001:12, GO to B22 .
19. B19 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If installed in a previous step, remove the fused jumper wire from the driver air bag module electrical connector. Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B Connector Position Assurance (CPA) lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. If previously removed, install the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Connect: Clockspring C218A (if previously disconnected). Connect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to B24 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . For B0001:13 or B0001:1A, GO to B20. For B0001:11, GO to B21
20. B20 CHECK THE DRIVER AIR BAG STAGE 1 RESISTANCE (DEPLOY_00_R) PID FOR AN INTERMITTENT LOW RESISTANCE OR OPEN CIRCUIT FAULT Enter the following diagnostic mode on the scan tool: DataLogger - RCM. DEPLOY_00_R PID Attempt to recreate the fault by wiggling connectors (including any in-line connectors), and flexing the wire harness, tilting and rotating the steering wheel frequently. Does the PID value read between 2 and 3.68 ohms? Yes : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to B23 . No : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to B24 .
21. B21 CHECK THE DRIVER AIR BAG STAGE 1 FOR AN INTERMITTENT SHORT TO GROUND FAULT Attempt to recreate the fault by wiggling connectors (including any in-line connectors) and flexing the wire harness, tilting and rotating the steering wheel frequently. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0001:11 retrieved on-demand during self-test? Yes : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to B24 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to B23 .
22. B22 CHECK THE DRIVER AIR BAG STAGE 1 FOR AN INTERMITTENT SHORT TO BATTERY FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the driver air bag module. Refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Attempt to recreate the fault by wiggling connectors (including any in-line connectors) and flexing the wire harness, tilting and rotating the steering wheel frequently. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0001:12 retrieved on-demand during self-test? Yes : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to B24 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to B23.
23. B23 CHECK THE HARNESS AND CONNECTORS Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the driver air bag module: inspect connector(s) (including any in-line connectors) for corrosion, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. Inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Were any concerns found? Yes : REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to B24. No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to B23 .
24. B24 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCMCM DTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test C: DTCs B0010:11, B0010:12, B0010:13 and B0010:1A

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) continuously monitors passenger air bag module stage 1 and circuits for the following faults

1. Resistance out of range
2. Unexpected voltage
3. Short to ground
4. Faulted passenger air bag module

If a fault is detected, the RCM will store DTC B0010:11, B0010:12, B0010:13 or B0010:1A in memory and send a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator.

The RCM analyzes the deployment loop resistance and uses this measurement in combination with an age correction factor to determine if a fault exists. The value displayed in the PID is the deployment loop resistance as measured by the RCM. If the value displayed is lower or higher than the desired range of (refer to diagram below), the RCM can set a DTC. As the deployment loop resistance drifts farther outside the desired range, the chance for a DTC increases. The RCM fault trigger threshold may vary as the vehicle ages. Small variations in resistance can occur due to the effect of road vibrations on terminal fit and/or temperature changes. These variables can result in an intermittent fault. For this reason, the test will require the PID value to be within the desired range before the fault is considered repaired, regardless if the module is reporting an on-demand DTC at time of diagnosis. Following this direction will help make sure that minor changes in resistance do not create a repeat concern. This test will use a process of elimination to diagnose each part of the deployment loop circuit including

Scheme 10

1. Wiring
2. Connections
3. Passenger air bag module
4. RCM

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Passenger air bag module
3. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. C1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0010:11, B0010:12, B0010:13 and B0010:1A retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. For B0010:13 or B0010:1A, GO to C2. For B0010:11, GO to C9 . For B0010:12, GO to C11 . No : This is an intermittent fault when present as a CMDTC only. For B0010:13 or B0010:1A, GO to C14 . For B0010:11, GO to C15 . For B0010:12, GO to C16 .
2. C2 CHECK THE PASSENGER FRONTAL STAGE 1 DEPLOYMENT CONTROL RESISTANCE (DEPLOY_05_R) PID Enter the following diagnostic mode on the scan tool: DataLogger - RCM. DEPLOY_05_R PID Does the PID value read between 1.7 and 2.78 ohms? Yes : GO to C13 . No : GO to C3.
3. C3 CHECK THE PASSENGER FRONTAL STAGE 1 DEPLOYMENT CONTROL RESISTANCE (DEPLOY_05_P) PID WHILE CARRYING OUT A HARNESS TEST While monitoring the DEPLOY_05_R PID, carry out a harness test of the passenger air bag module circuits and accessible connectors (including any in-line connectors), by wiggling connectors and flexing the wire harness. Does the PID value read between 1.7 and 2.78 ohms while carrying out the harness test? Yes : DEPOWER the SRS and REPAIR the connector, terminals or wire harness as needed. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to C18 . No : For PID value less than 1.7 ohms, GO to C4. For PID value greater than 2.78 ohms, GO to C7 .
4. C4 CHECK THE PASSENGER FRONTAL STAGE 1 DEPLOYMENT CONTROL DTC FOR FAULT STATUS CHANGE (LOW RESISTANCE INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the glove compartment to access the passenger air bag module connector. Refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal. Disconnect: Passenger Air Bag Module C256. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the passenger air bag module disconnected, open circuit faults would normally be retrieved on passenger air bag stage 1 circuits. Did the on-demand DTC change from B0010:1A to B0010:13? Yes : GO to C12 . No : GO to C5.
5. C5 CHECK FOR A SHORT BETWEEN PASSENGER AIR BAG STAGE 1 CIRCUITS Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Measure the resistance between passenger air bag C256-1, circuit CR103 (GY/BU), harness side and C256-2, circuit RR103 (VT/GN), harness side. Is the resistance greater than 10, 000 ohms? Yes : GO to C13 . No : GO to C6.
6. C6 CHECK THE RCM FOR LOW RESISTANCE Disconnect: RCM C310A and C310B. Measure the resistance between RCM C310A pins 1 and 2, component side. Is the resistance greater than 10, 000 ohms? Yes : REPAIR circuits CR103 (GY/BU) and RR103 (VT/GN). GO to C18 . No : GO to C13 .
7. C7 CHECK THE PASSENGER AIR BAG STAGE 1 CIRCUITS FOR AN OPEN Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the glove compartment to gain access to the passenger air bag module connector. Refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal. Disconnect: Passenger Air Bag Module C256. Disconnect: RCM C310A and C310B. Measure the resistance between RCM C310A, harness side and passenger air bag module C256, harness side using the following chart. RCM Circuit Passenger Air Bag Module Electrical Connector C310A-1 CR103 (GY/BU) C256-1 C310A-2 RR103 (VT/GN) C256-2 Are the resistances less than 0.5 ohm? Yes : GO to C8. No : REPAIR circuit CR103 (GY/BU) or RR103 (VT/GN). GO to C18 .
8. C8 CHECK THE PASSENGER FRONTAL STAGE 1 DEPLOYMENT CONTROL DTC FOR FAULT STATUS CHANGE (OPEN INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Connect: RCM C310A and C310B. Connect a fused jumper wire between passenger air bag module electrical connector C256 pins 1 and 2, harness side. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the passenger air bag module stage 1 circuits shorted together, a low resistance fault would normally be retrieved on stage 1. Did the on-demand DTC change from B0010:13 to B0010:1A? Yes : GO to C12 . No : GO to C13 .
9. C9 CHECK THE PASSENGER FRONTAL STAGE 1 DEPLOYMENT CONTROL DTC FOR FAULT STATUS CHANGE (SHORT TO GROUND INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the glove compartment to gain access to the passenger air bag module connector. Refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal. Disconnect: Passenger Air Bag Module C256. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the passenger air bag module disconnected, open circuit faults would normally be retrieved on passenger air bag stage 1 circuits. Did the on-demand DTC change from B0010:11 to B0010:13? Yes : GO to C12 . No : GO to C10.
10. C10 CHECK THE PASSENGER AIR BAG STAGE 1 CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between passenger air bag module: C256-1, circuit CR103 (GY/BU), harness side and ground. C256-2, circuit RR103 (VT/GN), harness side and ground. Are the resistances greater than 10, 000 ohms? Yes : GO to C13 . No : Due to the shorting bar feature in the RCM electrical connector, the fault can exist in either circuit. Do not remove or defeat the shorting bar. REPAIR circuit CR103 (GY/BU) or RR103 (VT/GN). GO to C18 .
11. C11 CHECK THE PASSENGER AIR BAG STAGE 1 CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the glove compartment to gain access to the passenger air bag module connector. Refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal. Disconnect: Passenger Air Bag Module C256. Disconnect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between passenger air bag module: C256-1, circuit CR103 (GY/BU), harness side and ground. C256-2, circuit RR103 (VT/GN), harness side and ground. Is voltage present on either circuit? Yes : Due to the shorting bar feature in the RCM electrical connector, the fault can exist in either circuit. Do not remove or defeat the shorting bar. REPAIR circuit CR103 (GY/BU) or RR103 (VT/GN). GO to C18 . No : GO to C13 .
12. C12 CONFIRM THE PASSENGER AIR BAG MODULE FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If installed in a previous step, remove the fused jumper wire from the passenger air bag module electrical connector. Connect: Passenger Air Bag Module C256 (if previously disconnected). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new passenger air bag module. REFER to «PASSENGER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to C18 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . For DTC B0010:13 or B0010:1A, GO to C14 . For DTC B0010:11, GO to C15 . For DTC B0010:12, GO to C16 .
13. C13 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If installed in a previous step, remove the fused jumper wire from the passenger air bag module electrical connector. Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: Passenger Air Bag Module C256 (if previously disconnected). Connect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to C18 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . For DTC B0010:13 or B0010:1A, GO to C14. For DTC B0010:11, GO to C15 . For DTC B0010:12, GO to C16 .
14. C14 CHECK THE PASSENGER FRONTAL STAGE 1 DEPLOYMENT CONTROL RESISTANCE (DEPLOY_05_R) PID FOR AN INTERMITTENT LOW RESISTANCE OR OPEN CIRCUIT FAULT Enter the following diagnostic mode on the scan tool: DataLogger - RCM. DEPLOY_05_R PID Attempt to recreate the fault by wiggling connectors (including any in-line connectors), and flexing the wire harness frequently. Does the PID value read between 1.7 and 2.78 ohms? Yes : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to C17 . No : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to C18 .
15. C15 CHECK THE PASSENGER FRONTAL STAGE 1 DEPLOYMENT CONTROL CIRCUITS FOR AN INTERMITTENT SHORT TO GROUND FAULT Enter the following diagnostic mode on the scan tool: Self Test - RCM. Attempt to recreate the fault by wiggling connectors (including any in-line connectors) and flexing the wire harness. Was DTC B0010:11 retrieved on-demand during self-test? Yes : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to C18 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to C17 .
16. C16 CHECK THE PASSENGER FRONTAL STAGE 1 DEPLOYMENT CONTROL CIRCUITS FOR AN INTERMITTENT SHORT TO BATTERY FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Remove the glove compartment. Refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal. Disconnect: Passenger Air Bag Module C256. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Attempt to recreate the fault by wiggling connectors (including any in-line connectors) and flexing the wire harness. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0010:12 retrieved on-demand during self-test? Yes : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to C18 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to C17.
17. C17 CHECK THE HARNESS AND CONNECTORS Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . NOTE: To gain access to the passenger air bag module C256, the glove compartment must be removed. Refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal. Disconnect the passenger air bag module C256 (if not previously disconnected). inspect connector(s) (including any in-line connectors) for corrosion, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Were any concerns found? Yes : REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to C18. No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to C18.
18. C18 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCM and OCSMCMDTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test D: DTCs B0050:11, B0050:12, B0050:13 and B0050:1D

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) monitors the driver safety belt buckle switch and circuits for the following faults

1. Open circuit
2. Short to voltage
3. Short to ground
4. Current out of range
5. Faulted driver safety belt buckle switch

If a fault is detected, the RCM will store DTC B0050:11, B0050:12, B0050:13 or B0050:1D in memory and will send a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Driver safety belt buckle and pretensioner assembly
3. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. D1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0050:11, B0050:12, B0050:13 or B0050:1D retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during the self-test. For DTC B0050:11 or B0050:1D, GO to D2. For DTC B0050:12, GO to D4 . For DTC B0050:13, GO to D5 . No : This is an intermittent fault when present as a CMDTC only. GO to D10 .
2. D2 CHECK THE DRIVER SEATBELT SENSOR DTC FOR FAULT STATUS CHANGE (SHORT TO GROUND OR CURRENT OUT OF RANGE INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Disconnect: Driver Safety Belt Buckle C3338. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver safety belt buckle disconnected, an open circuit fault would normally be retrieved. Did the on-demand DTC change from B0050:11 or B0050:1D to B0050:13? Yes : GO to D8 . No : For DTC B0050:11, GO to D3. For DTC B0050:1D, GO to D9 .
3. D3 CHECK THE DRIVER SAFETY BELT BUCKLE SWITCH CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between driver safety belt buckle C3338-4, circuit CR201 (GN/BU), harness side and ground. Is the resistance greater than 10, 000 ohms? Yes : GO to D9 . No : REPAIR circuit CR201 (GN/BU). GO to D11 .
4. D4 CHECK THE DRIVER SEAT BELT BUCKLE SWITCH CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Disconnect: Driver Safety Belt Buckle C3338. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between driver safety belt buckle C3338-4, circuit CR201 (GN/BU), harness side and ground. Is any voltage present? Yes : REPAIR circuit CR201 (GN/BU). GO to D11 . No : GO to D9 .
5. D5 CHECK THE DRIVER SEATBELT SENSOR DTC FOR FAULT STATUS CHANGE (OPEN INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Disconnect: Driver Safety Belt Buckle C3338. Connect a fused jumper wire between driver safety belt buckle C3338-4, circuit CR201 (GN/BU), harness side and C3338-3, circuit GD126 (BK/WH), harness side. Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver safety belt buckle switch circuits shorted together, a short to ground fault would normally be retrieved. Did the on-demand DTC change from B0050:13 to B0050:11? Yes : GO to D8 . No : GO to D6.
6. D6 CHECK THE DRIVER SAFETY BELT BUCKLE SWITCH CIRCUIT FOR AN OPEN Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Remove the fused jumper wire from the driver safety belt buckle electrical connector. Measure the resistance between RCMC310B-34, circuit CR201 (GN/BU), harness side and driver safety belt buckle C3338-4, circuit CR201 (GN/BU), harness side. Is the resistance less than 0.5 ohm? Yes : GO to D7. No : REPAIR circuit CR201 (GN/BU). GO to D11 .
7. D7 CHECK THE DRIVER SAFETY BELT BUCKLE SWITCH GROUND CIRCUIT FOR AN OPEN Measure the resistance between driver safety belt buckle C3338-3, circuit GD126 (BK/WH), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to D9 . No : REPAIR circuit GD126 (BK/WH). GO to D11 .
8. D8 CONFIRM THE DRIVER SAFETY BELT BUCKLE SWITCH FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If previously installed, remove the fused jumper wire from the driver safety belt buckle electrical connector. Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: RCM C310A and C310B. Connect: Driver Safety Belt Buckle C3338. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new driver safety belt buckle and pretensioner. REFER to «SAFETY BELT SYSTEM»(/ford/econoline-e250/2012-2013/remont/passive-restraints/#safety-belt-system) . GO to D11 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to D10 .
9. D9 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: Driver Safety Belt Buckle C3338. Connect: RCM C310A and C310B (if previously disconnected). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to D11 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to D10.
10. D10 CHECK FOR AN INTERMITTENT FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect the driver safety belt buckle C3338: inspect connector(s) (including any in-line connectors) for corrosion, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: All Previously Disconnected Component(s)/Connector(s). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0050:11, B0050:12, B0050:13 or B0050:1D retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during the self-test. For DTC B0050:11 or B0050:1D, GO to D2 . For DTC B0050:12, GO to D4 . For DTC B0050:13, GO to D5 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to D11.
11. D11 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCM and OCSMCMDTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test E: DTCs B0090:11 and B0090:93

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) checks the front impact severity sensor and circuits for the following faults

1. Open circuit
2. Short to voltage
3. Short to ground
4. Faulted front impact severity sensor

If a fault is detected, the RCM will store DTC B0090:11, B0090:81, B0090:93 or B0090:96 in memory and send a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator.

1. DTC B0090:11 (Left Frontal Restraints Sensor: Circuit Short to Ground) - When the RCM senses a short to ground on the front impact severity sensor feed circuit, a fault will be indicated.
2. DTC B0090:93 (Left Frontal Restraints Sensor: No Operation) - When the RCM senses a faulted sensor, short to voltage on the feed circuit, open on the feed or return circuit, a fault will be indicated.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Front impact severity sensor
3. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Note. Do not probe any impact sensor. The impact sensor can not be tested using a multi-meter.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. E1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0090:11, B0090:81, B0090:93 or B0090:96 retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. For DTC B0090:11, GO to E2. For DTC B0090:93, GO to E5 . REFER to «FRONT IMPACT SEVERITY SENSOR»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to E11 . No : The fault is intermittent when present as a CMDTC only. GO to E10 .
2. E2 CHECK THE LEFT FRONTAL RESTRAINTS SENSOR DTC FOR FAULT STATUS CHANGE (SHORT TO GROUND INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Front Impact Severity Sensor C177. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Did the on-demand DTC change from B0090:11 to B0090:93? Yes : INSTALL a new front impact severity sensor. REFER to «FRONT IMPACT SEVERITY SENSOR»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to E11 . No : GO to E3.
3. E3 CHECK THE FRONT IMPACT SEVERITY SENSOR FEED CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between front impact severity sensor C177-1, circuit VR213 (VT/GN), harness side and ground. Is the resistance greater than 10, 000 ohms? Yes : GO to E4. No : REPAIR circuit VR213 (VT/GN). GO to E11 .
4. E4 CHECK FOR A SHORT BETWEEN FRONT IMPACT SEVERITY SENSOR CIRCUITS Measure the resistance between front impact severity sensor C177-1, circuit VR213 (VT/GN), harness side and C177-2, circuit RR129 (YE/GY), harness side. Is the resistance greater than 10, 000 ohms? Yes : GO to E9 . No : REPAIR circuits VR213 (VT/GN) and RR129 (YE/GY). GO to E11 .
5. E5 CHECK THE FRONT IMPACT SEVERITY SENSOR AND RCM CONNECTIONS (NO OPERATION INDICATED) Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Inspect front impact severity sensor C177 to be fully seated and locked. Seat and lock connector as necessary. Gain access to the RCM and inspect C310A and C310B to be fully seated and locked. Seat and lock the connector(s) as necessary. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0090:93 retrieved on-demand during self-test? Yes : GO to E6. No : Fault corrected. GO to E11 .
6. E6 CHECK THE FRONT IMPACT SEVERITY SENSOR CIRCUITS FOR A SHORT TO VOLTAGE (NO OPERATION INDICATED) Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Front Impact Severity Sensor C177. Disconnect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between front impact severity sensor: C177-1, circuit VR213 (VT/GN), harness side and ground. C177-2, circuit RR129 (YE/GY), harness side and ground. Is voltage present on either circuit? Yes : REPAIR circuit VR213 (VT/GN) or RR129 (YE/GY). GO to E11 . No : GO to E7.
7. E7 CHECK THE FRONT IMPACT SEVERITY SENSOR CIRCUITS FOR AN OPEN (NO OPERATION INDICATED) Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Measure the resistance between RCM C310B, harness side and front impact severity sensor C177, harness side using the following chart. RCM Circuit Front Impact Severity Sensor C310B-27 VR213 (VT/GN) C177-1 C310B-28 RR129 (YE/GY) C177-2 Are the resistances less than 0.5 ohm? Yes : GO to E8. No : REPAIR circuit VR213 (VT/GN) or RR129 (YE/GY). GO to E11 .
8. E8 CHECK THE LEFT FRONTAL RESTRAINTS SENSOR DTC FOR A FAULT STATUS CHANGE (NO OPERATION INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Connect: RCM C310A and C310B. Connect a fused jumper wire between front impact severity sensor C177-1, circuit VR213 (VT/GN), harness side and C177-2, circuit RR129 (YE/GY), harness side. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0090:11 retrieved on-demand during self-test? Yes : INSTALL a new front impact severity sensor. REFER to «FRONT IMPACT SEVERITY SENSOR»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to E11 . No : GO to E9.
9. E9 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B Connector Position Assurance (CPA) lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: RCM C310A and C310B. Connect: Front Impact Severity Sensor C177. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to E11 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to E10.
10. E10 CHECK FOR AN INTERMITTENT FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Front Impact Severity Sensor C177. Disconnect: RCM C310A and C310B. Inspect for the following: inspect harness and component connectors for loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect RCM C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: All Previously Disconnected Component(s)/Connector(s). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B0090:11 or B0090:93 retrieved on-demand during self-test? Yes : The fault condition is now present. This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. For DTC B0090:11, GO to E2 . For DTC B0090:93, GO to E5 . GO to E11. No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to E11.
11. E11 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCM DTCs, PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test F: DTCs B00D5:11, B00D5:12 and B00D5:13

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) briefly activates the Passenger Air Bag Deactivation (PAD) indicator to prove-out and verify to the occupants correct functional operation of the PAD indicator.

The RCM monitors the PAD indicator circuits for the following faults

1. Open circuit
2. Short to voltage
3. Short to ground
4. Faulted PAD indicator

If a fault is detected, the RCM will store DTC B00D5:11, B00D5:12 and B00D5:13 in memory and send a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator.

1. DTC B00D5:11 (Restraint System Passenger Disable Indicator: Circuit Short to Ground) - When the RCM senses a short to ground on the PAD indicator circuit, a fault will be indicated.
2. DTC B00D5:12 (Restraint System Passenger Disable Indicator: Circuit Short to Battery) - When the RCM senses a short to voltage on the PAD indicator circuit, a fault will be indicated.
3. DTC B00D5:13 (Restraint System Passenger Disable Indicator: Circuit Open) - When the RCM senses an open circuit on the PAD indicator or loss of ignition voltage to the PAD indicator, a fault will be indicated.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. PAD indicator
3. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. F1 RETRIEVE RCM DTCs Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B00D5:11, B00D5:12 or B00D5:13 retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. For B00D5:11, GO to F2. For B00D5:12, GO to F6 . For B00D5:13, GO to F3 . No : This is an intermittent fault when present as a CMDTC only. GO to F9 .
2. F2 CHECK THE PAD INDICATOR CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Disconnect: PAD Indicator C2099. Measure the resistance between PAD indicator C2099-2, circuit CR116 (GN/WH), harness side and ground. Is the resistance greater than 10, 000 ohms? Yes : GO to F8 . No : REPAIR circuit CR116 (GN/WH). GO to F10 .
3. F3 CHECK THE IGNITION CIRCUIT FOR VOLTAGE AT THE PAD INDICATOR Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Disconnect: PAD Indicator C2099. Ignition ON. Measure the voltage between PAD indicator C2099-1, circuit CBP46 (WH/BU), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to F4. No : VERIFY Smart Junction Box (SJB) fuse 46 (7.5A) is OK. Refer to «SMART JUNCTION BOX (SJB)»(/ford/econoline-e250/2012-2013/remont/fuses-circuit-breakers/#oem-fuse-and-relay-information) . If OK, REPAIR circuit CBP46 (WH/BU). GO to F10 . If not OK, REFER to the appropriate System Wiring Diagrams article to identify the possible causes of the circuit short.
4. F4 CHECK THE PAD INDICATOR CIRCUIT FOR AN OPEN Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between PAD indicator C2099-2, circuit CR116 (GN/WH), harness side and RCMC310A-22, circuit CR116 (GN/WH), harness side. Is the resistance less than 0.5 ohm? Yes : GO to F5. No : REPAIR circuit CR116 (GN/WH). GO to F10 .
5. F5 CHECK THE PAD INDICATOR LAMP Connect: PAD Indicator C2099. Connect a fused jumper wire between RCMC310A-22, circuit CR116 (GN/WH), harness side and ground. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Does the PAD indicator illuminate? Yes : GO to F8 . No : INSTALL a new PAD switch. REFER to «PASSENGER AIR BAG DEACTIVATION (PAD) SWITCH»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to F10 .
6. F6 CHECK THE PAD INDICATOR CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: PAD Indicator C2099. Disconnect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between PAD indicator C2099-2, circuit CR116 (GN/WH), harness side and ground. Is any voltage present? Yes : REPAIR circuit CR116 (GN/WH). GO to F10 . No : GO to F7.
7. F7 CHECK THE PAD SWITCH NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Connect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the PAD indicator disconnected, a open circuit fault would normally be retrieved. Did the on-demand DTC change from B00D5:12 to B00D5:13? Yes : INSTALL a new PAD switch. REFER to «PASSENGER AIR BAG DEACTIVATION (PAD) SWITCH»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to F10 . No : GO to F8.
8. F8 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: PAD Indicator Switch C2099. Connect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to F10 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to F9.
9. F9 CHECK FOR AN INTERMITTENT FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect the PAD indicator C2099: inspect connector(s) (including any in-line connectors) for corrosion, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: All Previously Disconnected Component(s)/Connector(s). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B00D5:11, B00D5:12 or B00D5:13 retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. For B00D5:11 and/or B005D:13, GO to F2 . For B00D5:12, GO to F6 . No : CHECK for causes of intermittent open or short to ground on circuit RR116 (BN/GN). ATTEMPT to recreate the hard fault by flexing the wire harness and cycling the ignition frequently. ACTIVATE other systems in the same wire harness. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to F10.
10. F10 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCMCMDTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test G: DTC B00DF:11, B00DF:12, B00DF:13 or B00DF:1D

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Passenger Air Bag Deactivation (PAD) switch signals the Restraints Control Module (RCM) by switching a resistance to ground. If the RCM senses 900-1100 ohms in the PAD switch, it enables the passenger air bag and turns off the PAD switch indicator. If the RCM senses 400-600 ohms in the PAD switch, it deactivates the passenger air bag and turns the PAD switch indicator on.

The RCM monitors the status of the PAD switch and circuity. The RCM monitors the PAD switch circuit for the following faults

1. Open circuit
2. Short to voltage
3. Short to ground
4. Faulted PAD switch

The RCM will store DTC B00DF:11, B00DF:12, B00DF:13 or B00DF:1D in memory if any of these conditions are detected. If a fault is detected, the RCM will send a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator.

This pinpoint test is intended to diagnose the following

1. Damaged wiring, terminals or connectors
2. PAD switch
3. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when making measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct Supplemental Restraint System (SRS) component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. G1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B00DF:11, B00DF:12, B00DF:13 or B00DF:1D retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during the self-test. For B00DF:11 or B00DF:1D, GO to G2. For B00DF:13, GO to G4 . For B00DF:12, GO to G7 . No : This is an intermittent fault when present as a CMDTC only. GO to G10 .
2. G2 CHECK THE PAD SWITCH DTC FOR A FAULT STATUS CHANGE (SHORT TO GROUND OR CIRCUIT CURRENT OUT OF RANGE INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Disconnect: PAD Switch C2099. Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Did the on-demand DTC change from B00DF:11 to B00DF:13? Yes : INSTALL a new PAD switch. GO to G11 . No : GO to G3.
3. G3 CHECK THE PAD SWITCH CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between PADC2099-4, circuit CR225 (YE), harness side and ground. Is the resistance greater than 10, 000 ohms? Yes : GO to G9 . No : REPAIR circuit CR225 (YE). GO to G11 .
4. G4 CHECK THE PAD SWITCH DTC FOR A FAULT STATUS CHANGE (OPEN CIRCUIT INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Disconnect: PAD Switch C2099. Connect a fused jumper wire between PADC2099-4, circuit CR225 (YE), harness side and C2099-3, circuit GD115 (BK/GY), harness side. Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Did the on-demand DTC change from B00DF:13 to B00DF:11? Yes : GO to G8 . No : GO to G5.
5. G5 CHECK THE PAD SWITCH CIRCUIT FOR AN OPEN Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Remove the fused jumper wire from the PAD switch C2099. Measure the resistance between RCMC310A-20, circuit CR225 (YE), harness side and PAD switch C2099-4, circuit CR225 (YE), harness side. Is the resistance less than 5 ohms? Yes : GO to G6. No : REPAIR circuit CR225 (YE). GO to G11 .
6. G6 CHECK THE PAD SWITCH GROUND CIRCUIT FOR AN OPEN Measure the resistance between PAD switch C2099-3, circuit GD115 (BK/GY), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to G9 . No : REPAIR circuit GD115 (BK/GY). GO to G11 .
7. G7 CHECK THE PAD SWITCH CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: PAD Switch C2099. Disconnect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between PADC2099-4, circuit CR225 (YE), harness side and ground. Is any voltage present? Yes : REPAIR circuit CR225 (YE). GO to G11 . No : GO to G9 .
8. G8 CONFIRM THE PAD SWITCH FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Remove the fused jumper wire from PAD switch C2099. Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: PAD Switch C2099. Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original on-demand DTC retrieved during self-test? Yes : INSTALL a new PAD switch. REFER to «PASSENGER AIR BAG DEACTIVATION (PAD) SWITCH»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to G11 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to G10 .
9. G9 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: PAD Switch C2099. Connect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to G11 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to G10.
10. G10 CHECK FOR AN INTERMITTENT FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: PAD Switch C2099. Disconnect: RCM C310A and C310B. Inspect for the following: inspect harness and component connectors for loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect RCM C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: All Previously Disconnected Component(s)/Connector(s). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B00DF:11, B00DF:12, B00DF:13 or B00DF:1D retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during the self test. For B00DF:11 or B00DF:1D, GO to G2 . For B00DF:13, GO to G4 . For B00DF:12, GO to G7 . No : CHECK for causes of intermittent faults on circuit CR225 (YE). ATTEMPT to recreate the hard fault by flexing the wire harness and cycling the ignition key frequently. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to G11.
11. G11 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCM continuous memory DTCs. PROVE OUT the SRS. REPAIR is complete. RETURN the vehicle to the customer.

Pinpoint Test H: DTCs B1212:11, B1212:12, B1212:13 and B1212:1A

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) monitors the driver safety belt buckle pretensioner and circuits for the following faults

1. Resistance out of range
2. Unexpected voltage
3. Short to ground
4. Faulted driver safety belt buckle pretensioner

If a fault is detected, the RCM will store DTC B1212:11, B1212:12, B1212:13 or B1212:1A in memory and send a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator.

The RCM analyzes the deployment loop resistance and uses this measurement in combination with an age correction factor to determine if a fault exists. The value displayed in the PID is the deployment loop resistance as measured by the RCM. If the value displayed is lower or higher than the desired range (refer to diagram below), the RCM can set a DTC. As the deployment loop resistance drifts farther outside the desired range, the chance for a DTC increases. The RCM fault trigger threshold may vary as the vehicle ages. Small variations in resistance can occur due to the effect of road vibrations on terminal fit and/or temperature changes. These variables can result in an intermittent fault. For this reason, the test will require the PID value to be within the desired range before the fault is considered repaired, regardless if the module is reporting an on-demand DTC at time of diagnosis. Following this direction will help make sure that minor changes in resistance do not create a repeat concern. This test will use a process of elimination to diagnose each part of the deployment loop circuit including

Scheme 33

1. Wiring
2. Connections
3. Driver safety belt buckle pretensioner
4. RCM

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Driver safety belt buckle pretensioner
3. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. H1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was B1212:11, B1212:12, B1212:13 or B1212:1A retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. For B1212:13 or B1212:1A, GO to H2. For B1212:11, GO to H8 . For B1212:12, GO to H10 . No : This is an intermittent fault when present as a CMDTC only. For B1212:13 or B1212:1A, GO to H13 . For B1212:11, GO to H14 . For B1212:12, GO to H15 .
2. H2 CHECK THE DRIVER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL RESISTANCE (DEPLOY_18_R) PID Enter the following diagnostic mode on the scan tool: DataLogger - RCM. DEPLOY_18_R PID Does the PID value read between 1.7 and 2.78 ohms? Yes : GO to H12 . No : GO to H3.
3. H3 CHECK THE DRIVER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL RESISTANCE (DEPLOY_18_R) PID WHILE CARRYING OUT A HARNESS TEST While monitoring the DEPLOY_18_R PID, carry out a harness test of the driver safety belt buckle pretensioner circuits and accessible connectors (including any in-line connectors), by wiggling connectors and flexing the wire harness. Does the PID value read between 1.7 and 2.78 ohms while carrying out a harness test? Yes : DEPOWER the SRS and REPAIR the connector, terminals or wire harness as needed. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to H17 . No : For PID value less than 1.7 ohms, GO to H4. For PID value greater than 2.78 ohms, GO to H6 .
4. H4 CHECK THE DRIVER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL DTC FOR A FAULT STATUS CHANGE (LOW RESISTANCE INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Driver Safety Belt Buckle C3338. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver safety belt buckle disconnected, an open circuit fault would normally be retrieved. Did the on-demand DTC change from B1212:1A to B1212:13? Yes : GO to H11 . No : GO to H5.
5. H5 CHECK FOR A SHORT BETWEEN DRIVER SAFETY BELT BUCKLE PRETENSIONER CIRCUITS Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between the driver safety belt buckle C3338-2, circuit CR120 (BU/OG), harness side and C3338-1, circuit RR120 (BN/GN), harness side. Is the resistance greater than 10, 000 ohms? Yes : GO to H12 . No : REPAIR circuits CR120 (BU/OG) and RR120 (BN/GN). GO to H17 .
6. H6 CHECK THE DRIVER SAFETY BELT BUCKLE PRETENSIONER CIRCUITS FOR AN OPEN Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Driver Safety Belt Buckle C3338. Disconnect: RCM C310A and C310B. Measure the resistance between RCM, C310B and driver safety belt buckle C3338, harness side using the following chart. RCM Circuit Driver Safety Belt Buckle Electrical Connector C310B-3 CR120 (BU/OG) C3338-2 C310B-4 RR120 (BN/GN) C3338-1 Are the resistances less than 0.5 ohm? Yes : GO to H7. No : REPAIR circuit CR120 (BU/OG) or RR120 (BN/GN). GO to H17 .
7. H7 CHECK THE DRIVER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL DTC FOR A FAULT STATUS CHANGE (OPEN INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Connect: RCM C310A and C310B. Connect a fused jumper wire between the driver safety belt buckle C3338-2, circuit CR120 (BU/OG), harness side and C3338-1, circuit RR120 (BN/GN), harness side. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver safety belt buckle pretensioner circuits shorted together, a low resistance fault would normally be retrieved. Did the on-demand DTC change from B1212:13 to B1212:1A? Yes : GO to H11 . No : GO to H12 .
8. H8 CHECK THE DRIVER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL DTC FOR A FAULT STATUS CHANGE (SHORT TO GROUND INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Driver Safety Belt Buckle C3338. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver safety belt buckle disconnected, an open circuit fault would normally be retrieved. Did the on-demand DTC change from B1212:11 to B1212:13? Yes : GO to H11 . No : GO to H9.
9. H9 CHECK THE DRIVER SAFETY BELT BUCKLE PRETENSIONER CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between the driver safety belt buckle: C3338-2, circuit CR120 (BU/OG), harness side and ground. C3338-1, circuit RR120 (BN/GN), harness side and ground. Are the resistances greater than 10, 000 ohms? Yes : GO to H12 . No : REPAIR circuit CR120 (BU/OG) or RR120 (BN/GN). GO to H17 .
10. H10 CHECK THE DRIVER SAFETY BELT BUCKLE PRETENSIONER CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Driver Safety Belt Buckle C3338. Disconnect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between the driver safety belt buckle: C3338-1, circuit RR120 (BN/GN), harness side and ground. C3338-2, circuit CR120 (BU/OG), harness side and ground. Is voltage present on either circuit? Yes : REPAIR circuit CR120 (BU/OG) or RR120 (BN/GN). GO to H17 . No : GO to H12 .
11. H11 CONFIRM THE DRIVER SEATBELT BUCKLE PRETENSIONER FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, erroneous DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If installed in a previous step, remove the fused jumper wire from the driver safety belt buckle electrical connector. Connect: Driver Safety Belt Buckle C3338. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original on-demand DTC retrieved during self-test? Yes : INSTALL a new driver safety belt buckle and pretensioner. REFER to «SAFETY BELT SYSTEM»(/ford/econoline-e250/2012-2013/remont/passive-restraints/#safety-belt-system) . GO to H17 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . For B1212:13 or B1212:1A, GO to H13 . For B1212:11, GO to H14 . For B1212:12, GO to H15 .
12. H12 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If installed in a previous step, remove the fused jumper wire from the driver safety belt buckle electrical connector. Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: Driver Safety Belt Buckle C3388. Connect: RCM C310A and C310B (if previously disconnected). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to H17 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . For B1212:13 or B1212:1A, GO to H13. For B1212:11, GO to H14 . For B1212:12, GO to H15 .
13. H13 CHECK FOR AN INTERMITTENT DRIVER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL RESISTANCE (DEPLOY_18_R) PID LOW RESISTANCE OR OPEN CIRCUIT FAULT Enter the following diagnostic mode on the scan tool: DataLogger - RCM. DEPLOY_18_R PID Attempt to recreate the fault by wiggling the connectors (including any in-line connectors) and flexing the wire harness. Does the PID value read between 1.7 and 2.78 ohms? Yes : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to H16 . No : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to H17 .
14. H14 CHECK FOR AN INTERMITTENT DRIVER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL SHORT TO GROUND FAULT Attempt to recreate the fault by wiggling connectors (including any in-line connectors) and flexing the wire harness. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the DTC B1212:11 retrieved on-demand during self-test? Yes : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to H17 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to H16 .
15. H15 CHECK FOR AN INTERMITTENT DRIVER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL SHORT TO VOLTAGE FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Driver Safety Belt Buckle C3338. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Attempt to recreate the fault by wiggling connectors (including any in-line connectors) and flexing the wire harness. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B1212:12 retrieved on-demand during self-test? Yes : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to H17 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to H16.
16. H16 CHECK THE HARNESS AND CONNECTORS Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect the driver safety belt buckle C3338: inspect connector(s) (including any in-line connectors) for corrosion, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. Were any concerns found? Yes : REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to H17. No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to H17.
17. H17 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCMCMDTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test I: DTCs B1213:11, B1213:12, B1213:13 and B1213:1A

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) monitors passenger safety belt buckle pretensioner and circuits for the following faults

1. Resistance out of range
2. Unexpected voltage
3. Short to ground
4. Faulted passenger safety belt buckle pretensioner

If a fault is detected, the RCM will store DTC B1213:11, B1213:12, B1213:13 or B1213:1A in memory and send a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator.

The RCM analyzes the deployment loop resistance and uses this measurement in combination with an age correction factor to determine if a fault exists. The value displayed in the PID is the deployment loop resistance as measured by the RCM. If the value displayed is lower or higher than the desired range (refer to diagram below), the RCM can set a DTC. As the deployment loop resistance drifts farther outside the desired range, the chance for a DTC increases. The RCM fault trigger threshold may vary as the vehicle ages. Small variations in resistance can occur due to the effect of road vibrations on terminal fit and/or temperature changes. These variables can result in an intermittent fault. For this reason, the test will require the PID value to be within the desired range before the fault is considered repaired, regardless if the module is reporting an on-demand DTC at time of diagnosis. Following this direction will help make sure that minor changes in resistance do not create a repeat concern. This test will use a process of elimination to diagnose each part of the deployment loop circuit including

Scheme 38

1. Wiring
2. Connections
3. Passenger air bag module
4. RCM

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Passenger safety belt buckle pretensioner
3. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. I1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC B1213:11, B1213:12, B1213:13 or B1213:1A retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. For B1213:13 or B1213:1A, GO to I2. For B1213:11, GO to I8 . For B1213:12, GO to I10 . No : This is an intermittent fault when present as a CMDTC only. For B1213:13 or B1213:1A, GO to I13 . For B1213:11, GO to I14 . For B1213:12, GO to I15 .
2. I2 CHECK THE PASSENGER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL RESISTANCE (DEPLOY_19_R) PID Enter the following diagnostic mode on the scan tool: DataLogger - RCM. DEPLOY_19_R PID Does the PID value read between 1.7 and 2.78 ohms? Yes : GO to I12 . No : GO to I3.
3. I3 CHECK THE PASSENGER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL RESISTANCE (DEPLOY_19_R) PID WHILE CARRYING OUT A HARNESS TEST While monitoring the DEPLOY_19_R PID, carry out a harness test of the driver buckle pretensioner circuits and accessible connectors (including any in-line connectors), by wiggling connectors and flexing the wire harness. Does the PID value read between 1.7 and 2.78 ohms while carrying out a harness test? Yes : DEPOWER the SRS and REPAIR the connector, terminals or wire harness as needed. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to I17 . No : For PID value less than 1.7 ohms, GO to I4. For PID value greater than 2.78 ohms, GO to I6 .
4. I4 CHECK THE PASSENGER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL DTC FOR A FAULT STATUS CHANGE (LOW RESISTANCE INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Passenger Safety Belt Buckle Pretensioner C3336. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the driver safety belt buckle pretensioner disconnected, an open circuit fault would normally be retrieved. Did the on-demand DTC change from B1213:1A to a B1213:13? Yes : GO to I11 . No : GO to I5.
5. I5 CHECK FOR A SHORT BETWEEN PASSENGER SAFETY BELT BUCKLE PRETENSIONER CIRCUITS Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure resistance between the passenger safety belt buckle pretensioner C3336-1, circuit CR122 (WH/OG), harness side and C3336-2, circuit RR122 (BN), harness side. Is the resistance greater than 10, 000 ohms? Yes : GO to I12 . No : REPAIR circuits CR122 (WH/OG) and RR122 (BN). GO to I17 .
6. I6 CHECK THE PASSENGER SAFETY BELT BUCKLE PRETENSIONER CIRCUITS FOR AN OPEN Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Passenger Safety Belt Buckle Pretensioner C3336. Disconnect: RCM C310A and C310B. Measure resistance between RCM, C310B and passenger safety belt buckle pretensioner C3336, harness side using the following chart. RCM Circuit Passenger Safety Belt Buckle Pretensioner C310B-13 CR122 (WH/OG) C3336-1 C310B-14 RR122 (BN) C3336-2 Are the resistances less than 0.5 ohm? Yes : GO to I7. No : REPAIR circuit CR122 (WH/OG) or RR122 (BN). GO to I17 .
7. I7 CHECK THE PASSENGER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL DTC FOR A FAULT STATUS CHANGE (OPEN INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Connect: RCM C310A and C310B. Connect a fused jumper wire between the passenger safety belt buckle pretensioner electrical connector pins 1 and 2, harness side. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the passenger safety belt buckle pretensioner circuits shorted together, a low resistance fault would normally be retrieved. Did the on-demand DTC change from B1213:13 to B1213:1A? Yes : GO to I11 . No : GO to I12 .
8. I8 CHECK THE PASSENGER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL DTC FOR A FAULT STATUS CHANGE (SHORT TO GROUND INDICATED) NOTE: This pinpoint test step will attempt to change the fault reported by the RCM by inducing a different fault condition. If the fault reported changes, this indicates the RCM is functioning correctly and is not the source of the fault. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Passenger Safety Belt Buckle Pretensioner C3336. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. DIAGNOSTIC TIP: When viewing DTCs with the passenger safety belt buckle pretensioner disconnected, an open circuit fault would normally be retrieved. Did the on-demand DTC change from B1213:11 to B1213:13? Yes : GO to I11 . No : GO to I9.
9. I9 CHECK THE PASSENGER SAFETY BELT BUCKLE PRETENSIONER CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between the passenger safety belt buckle pretensioner: C3336-1, circuit CR122 (WH/OG), harness side and ground. C3336-2, circuit RR122 (BN), harness side and ground. Are the resistances greater than 10, 000 ohms? Yes : GO to I12 . No : REPAIR circuit CR122 (WH/OG) or RR122 (BN). GO to I17 .
10. I10 CHECK THE PASSENGER SAFETY BELT BUCKLE PRETENSIONER CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Passenger Safety Belt Buckle Pretensioner C3336. Disconnect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between the passenger safety belt buckle pretensioner: C3336-1, circuit CR122 (WH/OG), harness side and ground. C3336-2, circuit RR122 (BN), harness side and ground. Is voltage present on either circuit? Yes : REPAIR circuit CR122 (WH/OG) or RR122 (BN). GO to I17 . No : GO to I12 .
11. I11 CONFIRM THE PASSENGER SEATBELT BUCKLE PRETENSIONER FAULT NOTE: Make sure all restraint system components, sensor electrical connectors and the RCM electrical connectors are connected before carrying out the self-test. If not, erroneous DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If installed in a previous step, remove the fused jumper wire from the passenger safety belt buckle pretensioner electrical connector. Connect: Passenger Safety Belt Buckle Pretensioner C3336. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original on-demand DTC retrieved during self-test? Yes : INSTALL a new passenger safety belt buckle pretensioner. REFER to «SAFETY BELT SYSTEM»(/ford/econoline-e250/2012-2013/remont/passive-restraints/#safety-belt-system) . GO to I17 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . For B1213:13 or B1213:1A, GO to I13 . For B1213:11, GO to I14 . For B1213:12, GO to I15 .
12. I12 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . If installed in a previous step, remove the fused jumper wire from the passenger safety belt buckle pretensioner electrical connector. Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: Passenger Safety Belt Buckle Pretensioner C3336. Connect: RCM C310A and C310B (if previously disconnected). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to I17 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . REPAIR any intermittent wiring, terminal or connector concerns found. For B1213:13 or B1213:1A, GO to I13. For B1213:11, GO to I14 . For B1213:12, GO to I15 .
13. I13 CHECK FOR AN INTERMITTENT PASSENGER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL RESISTANCE (DEPLOY_19_R) PID LOW RESISTANCE OR OPEN CIRCUIT FAULT Enter the following diagnostic mode on the scan tool: DataLogger - RCM. DEPLOY_19_R PID Attempt to recreate the fault by wiggling the connectors (including any in-line connectors) and flexing the wire harness. Does the PID value read between 1.7 ohms and 2.78 ohms? Yes : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to I16 . No : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to I17 .
14. I14 CHECK FOR AN INTERMITTENT PASSENGER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL SHORT TO GROUND FAULT Attempt to recreate the fault by wiggling connectors (including any in-line connectors) and flexing the wire harness. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the DTC B1213:11 retrieved on-demand during self-test? Yes : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to I17 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to I16 .
15. I15 CHECK FOR AN INTERMITTENT PASSENGER SEATBELT BUCKLE PRETENSIONER DEPLOYMENT CONTROL SHORT TO VOLTAGE FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: Passenger Safety Belt Buckle Pretensioner C3336. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Attempt to recreate the fault by wiggling connectors (including any in-line connectors) and flexing the wire harness. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the DTC B1213:12 retrieved on-demand during self-test? Yes : DEPOWER the SRS and REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to I17 . No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to I16.
16. I16 CHECK THE HARNESS AND CONNECTORS Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect the passenger safety belt buckle pretensioner C3336: inspect connector(s) (including any in-line connectors) for corrosion, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. Were any concerns found? Yes : REPAIR as necessary. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to I17. No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to I17.
17. I17 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCMCMDTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test J: DTCs B0001:2B, B0010:2B, B0050:2B, B00DF:2B, B1212:2B and B1213:2B

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) monitors driver air bag, passenger air bag, Passenger Air Bag Deactivation (PAD) switch, driver safety buckle switch and safety belt pretensioner circuits for a signal cross coupled (short) between circuits. If the RCM detects a short between the circuits of one device and another device, it will store a DTC for each of the signal cross coupled faults in memory. The RCM sends a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator. When a normal loop fault is present (one loop is either shorted to battery/ground, has an open circuit or has low resistance), then signal cross coupled diagnostics will not be active. Once the normal loop fault is repaired, then the signal cross coupled diagnostics will resume.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

1. J1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. NOTE: Signal cross coupled DTCs will be retrieved in pairs. Were any signal cross coupled DTCs retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. GO to J2. No : This is an intermittent fault when present as a CMDTC only. GO to J4 .
2. J2 CHECK DEPLOYABLE CIRCUITS FOR A SIGNAL CROSS COUPLED FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Disconnect ALL of the affected SRS devices. NOTE: Most signal cross coupled faults are due to connector and/or wiring harness damage. Carry out a thorough inspection of connector(s) and/or wiring harness for damage. Using the following table, measure resistance between the circuits of the affected SRS devices. DEPLOYABLE DEVICES Device/Loop/Squib (DTC) Connector - Pin Circuit Driver air bag module stage 1 (B0001:2B) C216-2 C216-1 RR101 (YE/GN) CR101 (VT/BN) Passenger air bag module stage 1 (B0010:2B) C256-1 C256-2 CR103 (GY/BU) RR103 (VT/GN) Driver safety belt buckle switch (B0050:2B) C3338-3 - CR201 (GN/BU) - Passenger restraints disable switch (B00DF:2B) C2099-2 - CR201 (GN/BU) - Driver safety belt buckle pretensioner (B1213:2B) C3338-1 C3338-2 CR120 (BU/OG) RR120 (BU/GN) Passenger safety belt buckle pretensioner (B1213:2B) C3336-1 C3336-2 CR122 (WH/OG) RR122 (BN) Are the resistances greater than 10, 000 ohms between the affected circuits? Yes : GO to J3. No : REPAIR the affected circuits. GO to J5 .
3. J3 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: Any Previously Disconnected SRS Component. Connect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to J5 . No : In the process of diagnosing the fault, the fault condition has become intermittent. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to J4.
4. J4 CHECK FOR AN INTERMITTENT FAULT NOTE: Most cross link faults are due to connector and/or wiring harness damage. Carry out a thorough inspection of connector(s) and/or wiring harness for damage. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect ALL of the affected SRS devices. Inspect the wiring harness(es) for any type of damage. Repair as necessary. Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Were any signal cross coupled DTCs retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during self-test. GO to J2 . No : The fault is not present and cannot be recreated at this time. CHECK for causes of the intermittent fault. ATTEMPT to recreate the hard fault by flexing the wire harness and cycling the ignition frequently. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to J5.
5. J5 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCMCMDTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test K: DTCs B0001:4A, B0010:4A, B0050:4A, B0090:4A, B00D5:4A, B00DF:4A, B1212:4A, B1213:4A and U3000:4A

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

The Restraints Control Module (RCM) monitors all of Supplemental Restraint System (SRS) device connections. If the RCM detects a connection or device connected that is not stored in memory, the RCM will set a DTC and send a message to the Instrument Panel Cluster (IPC) module to illuminate air bag warning indicator.

This pinpoint test is intended to diagnose the following

1. Incorrect RCM for vehicle
2. RCM not configured

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

1. K1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Were any incorrect component installed DTCs retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved during the self-test. GO to K2. No : This is an intermittent fault when present as a CMDTC only. GO to K6 .
2. K2 CHECK VEHICLE HISTORY Ignition OFF. Check the vehicle repair history. Has a new RCM or ABS module been installed during this or a prior repair? Yes : GO to K3. No : GO to K5 .
3. K3 CHECK RCM AND ABS Gain access to the RCM and check the part number on the RCM against the part number listed in the Ford Catalog Advantage™ or equivalent. Refer to the «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) procedure. Gain access to the ABS module and check the part number on the ABS module against the part number listed in the Ford Catalog Advantage™ or equivalent. Refer to the Anti-Lock Brake System (ABS) Module procedure in «ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL»(/ford/econoline-e250/2012-2013/remont/anti-locktraction-control/#anti-lock-brake-system-and-stability-control) . Do the part numbers on the RCM and ABS modules match? Yes : GO to K4. No : INSTALL the correct RCM or ABS module. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in this article or the ABS Module Removal and Installation procedure in «ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL»(/ford/econoline-e250/2012-2013/remont/anti-locktraction-control/#anti-lock-brake-system-and-stability-control) . GO to K7 .
4. K4 CHECK RCM Ignition ON. Carry out Programmable Module Installation (PMI) for the RCM. Refer to «MODULE CONFIGURATION»(/ford/econoline-e250/2012-2013/remont/communication-devices/#module-configuration-system) . Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was any incorrect component installed DTCs retrieved on-demand during self-test? Yes : GO to K5. No : Fault corrected. GO to K7 .
5. K5 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: Any Previously Disconnected SRS Component. Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was the original DTC retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to K7 . No : In the process of diagnosing the fault, the fault condition has become intermittent. CHECK for causes of the intermittent fault. ATTEMPT to recreate the hard fault by flexing the wire harness and cycling the ignition frequently. ACTIVATE other systems in the same wire harness. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to K6.
6. K6 CHECK FOR INTERMITTENT FAULTS Enter the following diagnostic mode on the scan tool: Self Test - RCM. Were any DTCs retrieved? Yes : INSTALL new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to K7. No : CHECK for causes of the intermittent fault. ATTEMPT to recreate the hard fault by flexing the wire harness and cycling the ignition frequently. ACTIVATE other systems in the same wire harness. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to K7.
7. K7 CHECK FOR ADDITIONAL SRS DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Are any RCM DTCs retrieved on-demand during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the «RESTRAINTS CONTROL MODULE (RCM) DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__restraints-control-module-rcm-dtc-chart) for pinpoint test direction. No : CLEAR all RCMCMDTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test L: DTCs U0028:08 and U0028:88

Refer to OEM WIRING DIAGRAMS - ANTI-LOCK BRAKE SYSTEM -VEHICLE DYNAMIC SYSTEMS for schematic and connector information.

The Restraints Control Module (RCM) supplies the stability/traction control system with the yaw rate, roll rate, lateral and longitudinal accelerometer over a dedicated Controller Area Network 2 (CAN2) bus. If the RCM detects a fault with comminutions with the ABS module or CAN2 bus circuits, it will set DTC U0028:08 or U0028:88.

The RCM does not request the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator if either DTC U0028:08 or U0028:88 is set. The air bag warning indicator will remain off if either of these DTCs are set.

1. DTC U0028:08 (Vehicle Communication Bus A: Bus Signal / Message Failures) - When the RCM does not receive CAN2 bus messages from the ABS module for 5 seconds, a fault will be indicated. An open CAN2 circuit, incorrect installed ABS module or loss of power and/or ground to the ABS module can set this DTC.
2. DTC U0028:88 (Vehicle Communication Bus A: Bus Off) - When the RCM detects the CAN2 circuits are shorted to ground, shorted to voltage or shorted to each other, a fault will be indicated.

The ABS module may set similar DTCs, U0151 (Lost Communication With Restraints Control Module) and U0452 (Invalid Data Received From Restraints Control Module).

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. RCM
3. ABS module

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. Supplemental Restraint System (SRS) components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. L1 RETRIEVE RCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC U0028:08 or U0028:88 retrieved on-demand during self-test? Yes : This fault cannot be cleared until it is corrected and the DTC is no longer retrieved during self-test. For DTC U0028:08, GO to L2. For DTC U0028:88, GO to L6 . No : This is an intermittent fault when present as a CMDTC only. GO to L13 .
2. L2 CHECK FOR CORRECT RCM Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Gain access to the RCM and check the part number on the RCM against the part number listed in the Ford Catalog Advantage™ or equivalent. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Does the part number match? Yes : GO to L3. No : INSTALL the correct RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to L14 .
3. L3 CHECK FOR CORRECT ABS MODULE NOTE: This vehicle has the option of Roll Stability Control (RSC®), verify the correct option content of this vehicle. Gain access the ABS module and check the part number on the ABS module against the part number listed in the Ford Catalog Advantage™ or equivalent. Refer to the Removal and Installation procedure in «ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL»(/ford/econoline-e250/2012-2013/remont/anti-locktraction-control/#anti-lock-brake-system-and-stability-control) . Does the part number match? Yes : GO to L4. No : INSTALL the correct ABS module. REFER to the Removal and Installation procedure in «ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL»(/ford/econoline-e250/2012-2013/remont/anti-locktraction-control/#anti-lock-brake-system-and-stability-control) . GO to L14 .
4. L4 CHECK THE HS-CAN NETWORK COMMUNICATIONS (ABS MODULE COMMUNICATIONS) Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. NOTE: The Network Test does not test the CAN2 communications between the ABS module and RCM. The CAN2 is a dedicated communication network between the 2 modules. Did the Network Test pass (ABS module communicate with the scan tool)? Yes : GO to L5. No : REFER to «MODULE COMMUNICATIONS NETWORK»(/ford/econoline-e250/2012-2013/remont/communication-devices/#module-communications-network) to diagnose the HS-CAN /ABS module communication concern. GO to L14 .
5. L5 CHECK THE CAN2 CIRCUITS FOR AN OPEN Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Disconnect: ABS Module C155. Measure the resistance between the ABS module C155, harness side and the RCM C310B, harness side as indicated in the following chart: ABS Module Circuit RCM C155-20 VDB04 (WH/BU) C310B-20 C155-34 VDB05 (WH) C310B-19 Are the resistances less 5 ohms? Yes : GO to L9 . No : REPAIR circuit VDB05 (WH) or VDB04 (WH/BU). GO to L14 .
6. L6 CHECK THE CAN2 CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Disconnect: ABS Module C155. Repower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Measure the voltage between ABS module: C155-20, circuit VDB04 (WH/BU), harness side and ground. C155-34, circuit VDB05 (WH), harness side and ground. Is voltage present on either circuit? Yes : REPAIR circuit VDB04 (WH/BU) or VDB05 (WH). GO to L14 . No : GO to L7.
7. L7 CHECK THE CAN2 CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Measure the resistance between ABS module: C155-20, circuit VDB04 (WH/BU), harness side and ground. C155-34, circuit VDB05 (WH), harness side and ground. Are the resistances greater than 10, 000 ohms? Yes : GO to L8. No : REPAIR circuit VDB04 (WH/BU) or VDB05 (WH). GO to L14 .
8. L8 CHECK FOR SHORT BETWEEN CAN2 CIRCUITS Measure the resistance between ABS module C155-20, circuit VDB04 (WH/BU), harness side and ABS module C155-34, circuit VDB05 (WH), harness side. Is the resistance greater than 10, 000 ohms? Yes : GO to L9. No : REPAIR circuits VDB04 (WH/BU) and VDB05 (WH). GO to L14 .
9. L9 CHECK THE RCM TERMINATING RESISTOR Connect: RCM C310B. Measure the resistance between ABS module C155-20, circuit VDB04 (WH/BU), harness side and ABS module C155-34, circuit VDB05 (WH), harness side. Is the resistance between 108 and 132 ohms? Yes : GO to L10. No : GO to L11 .
10. L10 CHECK THE ABS MODULE TERMINATING RESISTOR Disconnect: RCM C310B. Connect: ABS Module C155. Measure the resistance between RCMC310B-20, circuit VDB04 (WH/BU), harness side and C310B-19, circuit VDB05 (WH), harness side. Is the resistance between 108 and 132 ohms? Yes : For DTC U0028:08, GO to L11. For DTC U0028:88, GO to L12 . No : GO to L12 .
11. L11 CONFIRM THE RCM FAULT NOTE: Make sure all restraint system components, sensor electrical connectors and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. If previously directed to repower the SRS, depower the SRS. Refer to SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect RCM C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . inspect ABS module C155 for dirt, corrosion, water intrusion, pushed out, loose or spread terminals and loose or frayed wire connections at terminals. repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: All Previously Disconnected Component(s)/Connector(s). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC U0028:08 retrieved on-demand during self-test? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . GO to L14 . No : In the process of diagnosing the fault, the fault condition has become intermittent. CHECK for causes of the intermittent fault. ATTEMPT to recreate the hard fault by flexing the wire harness and cycling the ignition frequently. ACTIVATE other systems in the same wire harness. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to L13 .
12. L12 CONFIRM THE ABS MODULE FAULT NOTE: Make sure all restraint system components, sensor electrical connectors and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. If previously directed to repower the SRS, depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any in-line connectors) for pushed out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. inspect RCM C310A and C310B CPA lever/lock for correct operation. Refer to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . inspect ABS module C155 for dirt, corrosion, water intrusion, pushed out, loose or spread terminals and loose or frayed wire connections at terminals. repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: All Previously Disconnected Component(s)/Connector(s). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC U0028:88 retrieved on-demand during self-test? Yes : INSTALL a new ABS module. REFER to the Removal and Installation procedure in «ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL»(/ford/econoline-e250/2012-2013/remont/anti-locktraction-control/#anti-lock-brake-system-and-stability-control) . GO to L14 . No : In the process of diagnosing the fault, the fault condition has become intermittent. CHECK for causes of the intermittent fault. ATTEMPT to recreate the hard fault by flexing the wire harness and cycling the ignition frequently. ACTIVATE other systems in the same wire harness. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to L13.
13. L13 CHECK FOR AN INTERMITTENT FAULT Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect RCM C310B and ABS module C155: inspect connector(s) (including any in-line connectors) for corrosion, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damage, pinched, cut or pierced wires. repair any concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. Connect: All Previously Disconnected Component(s)/Connector(s). Repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Was DTC U0028:08 or U0028:88 retrieved on-demand during self-test? Yes : The fault condition is now present. This fault cannot be cleared until it is corrected and the DTC is no longer retrieved on-demand during the self-test. CHECK for causes of the intermittent fault in the areas previously worked in, particularly the pins and terminals of any electrical connector that were disconnected. REPAIR any intermittent wiring, terminal or connector concerns found. Refer to «OEM CONNECTOR REPAIR PROCEDURES»(/ford/econoline-e250/2012-2013/remont/body-electrical/#oem-connector-repair-procedures) , Connector Repair Procedures for schematic and connector information. GO to L14. No : The fault is not present and cannot be recreated at this time. Do not install any new SRS components at this time. SRS components should only be installed when directed to do so in the pinpoint test . GO to L14.
14. L14 CHECK FOR ADDITIONAL RCM AND ABS MODULE DTCs Ignition OFF. WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Reconnect all SRS components (if previously disconnected). If previously directed to depower the SRS, repower the SRS. Do not prove out the SRS at this time. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in Section 501-20B. Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - RCM. Enter the following diagnostic mode on the scan tool: Self Test - ABS Module. Were any DTCs retrieved on-demand from the RCM or ABS module during self-test? Yes : Do not clear any DTCs until all DTCs have been resolved. GO to the appropriate «DTC CHART»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in this article and/or «ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL»(/ford/econoline-e250/2012-2013/remont/anti-locktraction-control/#anti-lock-brake-system-and-stability-control) for pinpoint test direction. No : CLEAR all CMDTCs. PROVE OUT the SRS. Repair is complete. RETURN the vehicle to the customer.

Pinpoint Test M: DTC U3003:16 or U3003:17

Refer to OEM WIRING DIAGRAMS - SUPPLEMENTAL RESTRAINTS System for schematic and connector information.

Note. DTCs B1317, B1318, B1676 U3003:16 and U3003:17 can be set if the vehicle has been recently jump started, the battery has been recently charged or the battery has been discharged. The battery may become discharged due to excessive load(s) on the charging system from aftermarket accessories or if the battery has been left unattended with the accessories on.

The Restraints Control Module (RCM) monitors the input voltage for correct operation. If the RCM detects input voltage below 9.5 volts, it will store DTC U3003:16 in memory. If the RCM detects input voltage of 20 volts, it will store DTC U3003:17 in memory. If the RCM sets DTC U3003:16 or U3003:17, it will send a message to the Instrument Panel Cluster (IPC) module to illuminate the air bag warning indicator.

1. DTC U3003:16 (Battery Voltage: Circuit Voltage Below Threshold) - If the RCM detects voltage below 9.5 volts with a Supplemental Restraint System (SRS) fault, it will set this DTC.
2. DTC U3003:17 (Battery Voltage: Circuit Voltage Above Threshold) - If the RCM detects voltage above 16 volts with a SRS fault or above 20 volts without a SRS fault, it will set this DTC.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. RCM

Note. Use the correct probe adapter(s) from the Flex Probe Kit when taking measurements. Failure to use the correct probe adapter(s) may damage the connector. Most faults are due to connector and/or wiring concerns. Carry out a thorough inspection and verification before proceeding with the pinpoint test.

Note. SRS components should only be disconnected or reconnected when instructed to do so within a pinpoint test step. Failure to follow this instruction may result in incorrect diagnosis of the SRS.

Note. Always make sure the correct SRS component is being installed. Parts released for other vehicles may not be compatible even if they appear physically similar. Check the part number listed in the Ford Catalog Advantage™ or equivalent to make sure the correct component is being installed. If an incorrect SRS component is installed, DTCs may set.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 49

1. M1 RETRIEVE ALL CMDTCs IN ALL MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: Self Test - ALL CMDTCs (Continuous Memory). Is DTC U3003:16 or U3003:17 present in one or more modules AND P0563, P0620, P0625, P0626 or P065B retrieved from the PCM? Yes : REFER to «CHARGING SYSTEM»(/ford/econoline-e250/2012-2013/remont/charging-system/#charging-system) to diagnose the charging system. No : GO to M2.
2. M2 TEST BATTERY CONDITION Ignition OFF. Carry out the battery condition test. Refer to «BATTERY, MOUNTING AND CABLES»(/ford/econoline-e250/2012-2013/remont/charging-system/#battery-battery-mounting-battery-cables) . Did battery pass the condition test? Yes : If the battery passed the condition test but required a recharge, REFER to «CHARGING SYSTEM»(/ford/econoline-e250/2012-2013/remont/charging-system/#charging-system) to diagnose the charging system. CLEAR all CMDTCs. TEST the system for normal operation. If the battery passed the condition test and did not require a recharge, GO to M3. No : INSTALL a new battery. CLEAR all CMDTCs. TEST the SRS for normal operation.
3. M3 CHECK THE CHARGING SYSTEM VOLTAGE NOTE: Do not allow the engine speed to increase above 2, 000 rpm while performing this step or the generator may self excite and result in default charging system output voltage. If engine speed goes above 2, 000 rpm, shut the vehicle OFF and restart the engine before performing this step. Measure the voltage of the battery: For DTC U3003:17, turn off all accessories and run the engine at 1, 500 rpm for a minimum of 2 minutes while measuring battery voltage. For DTC U3003:16, turn on headlights and HVAC fan on high and run engine at 1, 500 rpm for a minimum of 2 minutes while measuring battery voltage. Is the voltage between 13 and 15.2 volts? Yes : For DTC U3003:16, GO to M4. For DTC U3003:17, GO to M6 . No : REFER to «CHARGING SYSTEM»(/ford/econoline-e250/2012-2013/remont/charging-system/#charging-system) to diagnose the charging system. CLEAR all CMDTCs. TEST the SRS for normal operation.
4. M4 CHECK FOR OPEN IGNITION CIRCUIT TO THE MODULE Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Measure the resistance between RCM C310A-13, circuit CBP32 (GN/VT), harness side and Smart Junction Box (SJB) fuse 32 (10A). Refer to «SMART JUNCTION BOX (SJB)»(/ford/econoline-e250/2012-2013/remont/fuses-circuit-breakers/#oem-fuse-and-relay-information) . Is the resistance less than 1 ohm? Yes : GO to M5. No : REPAIR the circuit as necessary. CLEAR all CMDTCs. TEST the SRS for normal operation.
5. M5 CHECK FOR OPEN GROUND TO THE MODULE Measure the resistance between the RCM case and a good ground. Is the resistance less than 1 ohm? Yes : GO to M6. No : MAKE SURE there is no corrosion between the RCM case and mounting. MAKE SURE the fasteners are clean and tightened to specification with no corrosion. REPAIR as necessary. CLEAR all CMDTCs. TEST the SRS for normal operation.
6. M6 CHECK FOR MODULE OPERATION Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Disconnect: RCM C310A and C310B. Check for the following: corrosion. damaged pins. pushed-out pins. Connect the RCM C310A and C310B and make sure the connector seats correctly. Repower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . Ignition ON. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new RCM. REFER to «RESTRAINTS CONTROL MODULE (RCM)»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR all CMDTCs. TEST the SRS for normal operation.

SPECIAL TOOLS CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Depowering Procedure

Note. The air bag warning indicator illuminates when the correct Restraints Control Module (RCM) fuse is removed and the ignition is ON.

Note. The Supplemental Restraint System (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

1. Turn all vehicle accessories OFF.
2. Turn the ignition OFF.
3. At the Smart Junction Box (SJB), located below the LH side of the instrument panel, remove the cover and the RCM fuse 32 (10A) from the SJB. Refer to «SMART JUNCTION BOX (SJB)»(/ford/econoline-e250/2012-2013/remont/fuses-circuit-breakers/#oem-fuse-and-relay-information) . For additional information, refer to the appropriate System Wiring Diagrams article.
4. Turn the ignition ON and monitor the air bag warning indicator for at least 30 seconds. The air bag warning indicator will remain lit continuously (no flashing) if the correct RCM fuse has been removed. If the air bag warning indicator does not remain lit continuously, remove the correct RCM fuse before proceeding.
5. Turn the ignition OFF.
6. Disconnect the battery ground cable and wait at least one minute. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/econoline-e250/2012-2013/remont/charging-system/#battery-battery-mounting-battery-cables) .

Repowering Procedure

1. Turn the ignition from OFF to ON.
2. Install RCM fuse 32 (10A) to the SJB and install the cover. Refer to «SMART JUNCTION BOX (SJB)»(/ford/econoline-e250/2012-2013/remont/fuses-circuit-breakers/#oem-fuse-and-relay-information) .
3. Connect the battery ground cable.
4. Prove out the SRS as follows: Turn the ignition from ON to OFF. Wait 10 seconds, then turn the ignition back ON and monitor the air bag warning indicator with all SRS components installed and connected. The air bag warning indicator will light continuously for approximately 6 seconds and then turn off. If an air bag SRS fault is present, the air bag warning indicator will: fail to light. remain lit continuously. flash. The flashing might not occur until approximately 30 seconds after the ignition has been turned from the OFF to the ON position. This is the time required for the RCM to complete the testing of the SRS. If the air bag warning indicator is inoperative and a SRS fault exists, a chime will sound in a pattern of 5 sets of 5 beeps. If this occurs, the air bag warning indicator and any SRS fault discovered must be diagnosed and repaired. Clear all continuous DTCs from the RCM using a scan tool.

SPECIAL TOOLS CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Deactivation Procedure

Note. The Supplemental Restraint System (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 50

1. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) .
2. Remove the driver air bag module. Remove the 2 driver air bag module bolt covers (1 shown in illustration). Remove the 2 driver air bag module bolts (1 shown in illustration). Disconnect the horn electrical connector. Disconnect the clockspring electrical connector. Remove the driver air bag module.
3. Remove the glove compartment. For additional information, refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal.
4. Disconnect the passenger air bag module electrical connector.
5. Install Restraints Control Module (RCM) fuse 32 (10A) to the SJB. Refer to «SMART JUNCTION BOX (SJB)»(/ford/econoline-e250/2012-2013/remont/fuses-circuit-breakers/#oem-fuse-and-relay-information) .
6. Connect the battery ground cable.

Scheme 51

1. Remove RCM fuse 32 (10A) from the SJB.
2. Disconnect the battery ground cable.
3. Connect the passenger air bag module electrical connector.
4. Install the glove compartment. For additional information, refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal and installation.
5. Install the driver air bag module. Connect the horn electrical connector. Connect the driver air bag module electrical connector. Position the driver air bag module into the steering wheel. Install the 2 driver air bag module bolts (1 shown in illustration). Tighten to 6 Nm (53 lb-in). Install the 2 driver air bag module bolt caps (1 shown in illustration).
6. Repower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) .

Note. After diagnosing or repairing a Supplemental Restraint System (SRS), the restraint system diagnostic tools (if required) must be removed before operating the vehicle over the road.

Note. Deployable devices (such as air bag modules, pretensioners) may deploy alone or in various combinations depending on the impact event.

Note. Always refer to the appropriate service information procedures prior to carrying out vehicle repairs affecting the SRS and safety belt system.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

All vehicles

Disposal of Deployable Devices and Pyrotechnic Devices That are Undeployed/Inoperative

Note. All inoperative air bag modules and safety belt pretensioners have been placed on the Mandatory Return List. All discolored or damaged air bag modules must be treated the same as any inoperative live air bag being returned.

1. Depower the Supplemental Restraint System (SRS). For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
2. Remove the undeployed/inoperative device. For additional information, refer to the appropriate procedure in this article or «SAFETY BELT SYSTEM»(/ford/econoline-e250/2012-2013/remont/passive-restraints/#safety-belt-system) .
3. If installing a new air bag module, record the necessary information and return the inoperative air bag module to Ford Motor Company.

Disposal of Deployable Devices and Pyrotechnic Devices That Are Deployed

1. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
2. Remove the deployed device. For additional information, refer to the appropriate procedure in this article or «SAFETY BELT SYSTEM»(/ford/econoline-e250/2012-2013/remont/passive-restraints/#safety-belt-system) .
3. Dispose of the deployed device in the same manner as any other part to be scrapped.

Disposal of Deployable Devices and Pyrotechnic Devices That Require Manual Deployment

1. Safety and environmental concerns require consideration and treatment of restraints system deployable and pyrotechnic devices when disposing of vehicles, deployable devices or pyrotechnic devices. Deploying deployable and pyrotechnic devices before scrapping a vehicle or the device eliminates the potential for hazardous exposures or reactions during processing. If special handling procedures are followed, deployable and pyrotechnic devices can be deployed safely and recycled with the vehicle, shipped separately to a recycling facility or disposed of safely. NOTE: To determine the deployable devices a vehicle is equipped with, refer to the «DESCRIPTION AND OPERATION»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) portion of this section. A vehicle equipped with any of the following deployable devices requires manual deployment of the devices before scrapping the vehicle or component. For additional information, refer to the appropriate portion of this procedure. Driver air bag module Passenger air bag module Seat side air bag modules Safety Canopy® modules Side air curtain modules
2. A vehicle equipped with any of the following pyrotechnic devices requires manual deployment of the devices before scrapping the vehicle or component. For additional information, refer to the appropriate portion of this procedure. Safety belt buckle pretensioners Safety belt retractor pretensioners Adaptive load-limiting retractors Deployable steering column
3. If a dual stage driver or passenger air bag module has deployed due to a crash event, the air bag module requires manual deployment to make sure both stages have deployed before scrapping the vehicle or disposing of the air bag module. For additional information, refer to «DRIVER AIR BAG MODULE, PASSENGER AIR BAG MODULE AND SEAT SIDE AIR BAG MODULES - REMOTE DEPLOYMENT»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system__driver-air-bag-module-passenger-air) in this procedure.

Driver Air Bag Module, Passenger Air Bag Module and Seat Side Air Bag Modules - Remote Deployment

Note. For air bag modules with multiple loops, all the loops on the air bag module must be deployed.

Note. Some driver and passenger front air bags have 2 deployment stages. After a collision it is possible that Stage 1 has deployed and Stage 2 has not. If a front air bag module has deployed, it is mandatory that the front air bag module be remotely deployed using the appropriate air bag disposal procedure.

Note. A typical air bag disposal is shown in illustration that is similar for all vehicles.

All driver, passenger and seat side air bag modules

Safety Belt Buckle Pretensioners, Safety Belt Retractor Pretensioners and Adaptive Load Limiting Safety Belt Retractors - Remote Deployment

Note. A typical safety belt buckle and retractor disposal is shown in illustration that is similar for all vehicles.

Scheme 52

Scheme 53

1. Make a container to house the safety belt buckle or retractor for deployment. NOTE: The tires must be of sufficient size to accommodate the safety belt buckle or retractor. Obtain a tire and wheel assembly and an additional 4 tires (without wheels) of the same size. With the tire and wheel assembly on the bottom, stack the tires. Securely tie all of the tires together.
2. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
3. Remove the safety belt buckle or retractor. For additional information, refer to the appropriate procedure in «SAFETY BELT SYSTEM»(/ford/econoline-e250/2012-2013/remont/passive-restraints/#safety-belt-system) . When deploying a safety belt buckle pretensioner, install a nut and bolt of sufficient length and of the same diameter as was used to retain it to the seat.
4. Cut each of the safety belt buckle or retractor wires near the electrical connector that connects to the vehicle wire harness.
5. Remove any sheathing (if present) and strip the insulation from the ends of the cut wires.
6. Make a jumper harness to deploy the safety belt buckle or retractor. Obtain 2 wires (20 gauge minimum) at least 9.14 m (30 ft) long and strip both ends of each wire. At one end of the jumper harness, connect the wires together.
7. Using the end of the jumper harness that the wires are not connected together, attach each wire of the jumper harness to each wire of the safety belt buckle or retractor. Use tape or other insulating material to make sure that the leads do not make contact with each other.
8. Tip the stack of tires on its side and place the safety belt buckle or retractor inside the center tire, making sure that there are 2 tires beneath the tire containing the safety belt buckle or retractor and 2 tires (including the tire and wheel assembly) above the tire containing the safety belt buckle or retractor.
9. Place the tire stack upright, with the wheel on top.
10. Remain at least 9.14 m (30 ft) away from the safety belt buckle or retractor.
11. From the end of the jumper harness that is not connected to the safety belt buckle or retractor, disconnect the 2 wires of the jumper harness from each other.
12. Deploy the safety belt buckle or retractor by touching the ends of the 2 wires of the jumper harness to the terminals of a 12-volt battery.
13. To allow for cooling, wait at least 10 minutes before approaching the deployed safety belt buckle or retractor.
14. Dispose of the deployed safety belt buckle or retractor in the same manner as any other part to be scrapped.

Safety Belt Buckle Pretensioners, Safety Belt Retractor Pretensioners and Load Limiting Safety Belt Retractors - In-Vehicle Deployment

Note. A typical safety belt buckle and retractor disposal is shown in illustration that is similar for all vehicles.

1. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
2. Access the safety belt buckle or retractor electrical connectors. For additional information, refer to «SAFETY BELT SYSTEM»(/ford/econoline-e250/2012-2013/remont/passive-restraints/#safety-belt-system) .
3. Cut each of the safety belt buckle or retractor wires, leaving at least 101.6 mm (4 in) to work with.
4. Remove any sheathing (if present) and strip the insulation from the ends of the cut wires.
5. Make a jumper harness to deploy the safety belt buckle or retractor. Obtain 2 wires (20 gauge minimum) at least 9.14 m (30 ft) long and strip both ends of each wire. At one end of the jumper harness, connect the wires together.
6. Using the end of the jumper harness that the wires are not connected together, attach each wire of the jumper harness to each wire of the safety belt buckle or retractor. Use tape or other insulating material to make sure that the leads do not make contact with each other.
7. Remain at least 9.14 m (30 ft) away from the safety belt buckle or retractor.
8. From the end of the jumper harness that is not connected to the safety belt buckle or retractor, disconnect the 2 wires of the jumper harness from each other.
9. Deploy the safety belt buckle or retractor by touching the ends of the 2 wires of the jumper harness to the terminals of a 12-volt battery.
10. To allow for cooling, wait at least 10 minutes before approaching the deployed safety belt buckle or retractor.
11. Dispose of the deployed safety belt buckle or retractor in the same manner as any other part to be scrapped.

Safety Canopy® Modules and Side Air Curtain Modules - In-Vehicle Deployment

Note. The Safety Canopy® module deployment for a scrapped vehicle will occur in its installed position in the vehicle.

Note. A typical Safety Canopy® module disposal is shown in illustration that is similar for all vehicles.

Scheme 54

1. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
2. Access the Safety Canopy®/side air curtain module electrical connectors. For additional information, refer to the appropriate procedure.
3. Cut each of the Safety Canopy®/side air curtain module wires leaving at least 101.6 mm (4 in) to work with.
4. Remove any sheathing (if present) and strip the insulation from the ends of the cut wires.
5. For Safety Canopy®/side air curtain modules with multiple loops, twist together a wire from each loop then repeat for the remaining wires from each loop (shown in illustration).
6. Make a jumper harness to deploy the Safety Canopy®/side air curtain module. Obtain 2 wires (20 gauge minimum) at least 9.14 m (30 ft) long and strip both ends of each wire. At one end of the jumper harness, connect the wires together.
7. Using the end of the jumper harness where the wires are not connected together, attach each wire of the jumper harness to each wire of the Safety Canopy®/side air curtain module or to the twisted-together wires if multiple loops. Use tape or other insulating material to make sure that the leads do not make contact with each other.
8. From the end of the jumper harness that is not connected to the Safety Canopy®/side air curtain module, disconnect the 2 wires of the jumper harness from each other.
9. Deploy the Safety Canopy®/side air curtain module by touching the ends of the 2 wires of the jumper harness to the terminals of a 12-volt battery.
10. To allow for cooling, wait at least 10 minutes before approaching the deployed Safety Canopy®/side air curtain module.
11. Dispose of the deployed Safety Canopy®/side air curtain module in the same manner as any other part to be scrapped.

Deployable Steering Column - In-Vehicle Deployment

Scheme 55

1. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
2. Access the deployable steering column electrical connector.
3. Cut each of the deployable steering column wires, leaving at least 101.6 mm (4 in) to work with.
4. Remove any sheathing (if present) and strip the insulation from the ends of the cut wires.
5. Make a jumper harness to deploy the deployable steering column. Obtain 2 wires (20 gauge minimum) at least 9.14 m (30 ft) long and strip both ends of each wire. At one end of the jumper harness, connect the wires together.
6. Using the end of the jumper harness where the wires are not connected together, attach each wire of the jumper harness to each wire of the deployable steering column. Use tape or other insulating material to make sure that the leads do not make contact with each other.
7. Remain at least 9.14 m (30 ft) away from the deployable steering column.
8. From the end of the jumper harness that is not connected to the deployable steering column, disconnect the 2 wires of the jumper harness from each other.
9. Deploy the deployable steering column by touching the ends of the 2 wires of the jumper harness to the terminals of a 12-volt battery.
10. To allow for cooling, wait at least 10 minutes before approaching the deployed steering column.
11. Dispose of the deployed steering column in the same manner as any other part to be scrapped.

Scheme 56

Removal

Note. The air bag warning indicator illuminates when the correct Restraints Control Module (RCM) fuse is removed and the ignition is ON.

Note. The Supplemental Restraint System (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. Remove the driver air bag module. For additional information, refer to «DRIVER AIR BAG MODULE»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) .
2. Remove the steering column opening cover. Pull outward on the steering column opening cover to release the retaining clips.
3. Detach the pin-type retainer and remove the electrical connector on the steering column opening lower finish panel reinforcement.
4. Remove the 2 Data Link Connector (DLC) screws and position aside.
5. Disconnect the clockspring electrical connectors and detach them from the bracket at the base of the steering column.
6. Place the road wheels in the straight-ahead position and remove the steering wheel. For additional information, refer to «STEERING COLUMN»(/ford/econoline-e250/2012-2013/remont/steering-column/#steering-column) .
7. If equipped, loosen the tilt lever/handle and remove.
8. Remove the ignition lock cylinder. Turn the lock cylinder to the RUN position. Using a suitable tool, push upward on the lock cylinder release tab through the hole in the lower shroud while pulling outward.
9. Remove the 3 screws and lower steering column shroud.
10. Remove the upper steering column shroud.
11. If reusing the clockspring, tape the rotor to the outer housing to prevent it from rotating.
12. If equipped, remove the key-in-ignition warning indicator switch.
13. Release the 3 clockspring retaining clips.
14. Detach the 2 clockspring retaining clips holding the wire to the steering column.
15. Route the wiring through the instrument panel and remove the clockspring.

Installation

Installing a new clockspring

Scheme 61

Note. The air bag warning indicator illuminates when the correct Restraints Control Module (RCM) fuse is removed and the ignition is ON.

Note. The Supplemental Restraint System (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

1. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
2. Remove the 2 driver air bag module bolt caps (1 shown in illustration) from the steering wheel.
3. Remove the 2 driver air bag module bolts (1 shown in illustration). To install, tighten to 6 Nm (53 lb-in).
4. Disconnect the electrical connectors and remove the driver air bag module.
5. To install, reverse the removal procedure.
6. Repower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.

Scheme 62

Removal and Installation

Note. The air bag warning indicator illuminates when the correct Restraints Control Module (RCM) fuse is removed and the ignition is ON.

Note. The Supplemental Restraint System (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 63

1. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
2. If necessary, remove the radiator grille. Remove the screw. Remove the 4 scrivets. Grasp the grille and pull forward to disengage the 3 lower clips and remove.
3. Disconnect the front impact severity sensor electrical connector.
4. Remove the 2 bolts and front impact severity sensor. NOTE: For installation, position the front impact severity sensor at the top of the mounting bracket with the connector end facing the RH side of the vehicle. To install, tighten to 12 Nm (106 lb-in).
5. To install, reverse the removal procedure.
6. Repower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.

Scheme 64

1. Turn the ignition OFF and wait at least one minute.
2. Remove the instrument cluster finish panel. For additional information, refer to «INSTRUMENT CLUSTER FINISH PANEL»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for removal and installation .
3. Remove the 3 screws and PAD switch.
4. To install, reverse the removal procedure.

Scheme 65

Note. The air bag warning indicator illuminates when the correct Restraints Control Module (RCM) fuse is removed and the ignition is ON.

Note. The Supplemental Restraint System (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

1. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.
2. Remove the glove compartment. For additional information, Refer to the «GLOVE COMPARTMENT»(/ford/econoline-e250/2012-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) for glove compartment removal.
3. Carefully pry the instrument panel trim panel at the LH edge outward and remove the 3 passenger air bag trim cover bolts.
4. Remove the 2 passenger air bag module-to-cross beam bolts. To install, tighten to 8 Nm (71 lb-in). Align the passenger air bag module J-nuts correctly before installing the passenger air bag module bolts.
5. Partially remove the passenger air bag module.
6. Disconnect the electrical connector, release the wiring harness pin-type retainer and remove the passenger air bag module.
7. To install, reverse the removal procedure.
8. Repower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) in the General Procedures portion of this section.

Scheme 66

Note. When installing a new Restraints Control Module (RCM), it is necessary to carry out Programmable Module Installation (PMI). System failure may occur if PMI is not performed. For additional information, refer to MODULE CONFIGURATION .

Note. The air bag warning indicator illuminates when the correct Restraints Control Module (RCM) fuse is removed and the ignition is ON.

Note. The Supplemental Restraint System (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 67

1. When installing a new RCM, carry out the appropriate steps necessary for the Programmable Module Installation (PMI) procedure. For additional information, refer to «MODULE CONFIGURATION»(/ford/econoline-e250/2012-2013/remont/communication-devices/#module-configuration-system) .
2. Depower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) .
3. Position the driver seat to gain access to the RCM.
4. Disconnect the large RCM electrical connector. Pinch the thumb tab and pivot the connector position assurance lever all the way back until it stops. Pull out and disconnect the large RCM electrical connector.
5. Disconnect the small RCM electrical connector.
6. Remove the 3 nuts and RCM.

Scheme 68

Scheme 69

1. Install the RCM and 3 retainer nuts. Tighten to 12 Nm (106 lb-in).
2. Connect the small RCM electrical connector.
3. Make sure the large RCM connector position assurance lever is in the full release position before attempting to connect the connector.
4. Connect the large RCM electrical wiring connector. Using the connector position assurance lever, pivot it toward the RCM, drawing the connector into the RCM. Make sure the thumb tab is engaged to the retainer on the RCM and locked in place.
5. Repower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(/ford/econoline-e250/2012-2013/remont/airbag/#supplemental-restraint-system) .
6. If a new RCM was installed, carry out the appropriate steps to complete the Programmable Module Installation (PMI) procedure. For additional information, refer to «MODULE CONFIGURATION»(/ford/econoline-e250/2012-2013/remont/communication-devices/#module-configuration-system) .

See also:
• MODULE COMMUNICATIONS NETWORK
• INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES
• MULTIFUNCTION ELECTRONIC MODULES
• INFORMATION AND ENTERTAINMENT SYSTEMS
• INTRODUCTION - GASOLINE MODELS
• OEM CONNECTOR REPAIR PROCEDURES
• GLOVE COMPARTMENT
• SAFETY BELT SYSTEM
• SMART JUNCTION BOX (SJB)
• ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL
• MODULE CONFIGURATION
• CHARGING SYSTEM
• BATTERY, MOUNTING AND CABLES
• STEERING COLUMN
• IGNITION SWITCH -- MECHANICAL
• STEERING WHEEL
• RESTRAINTS CONTROL MODULE (RCM) DTC CHART
• SYMPTOM CHART
• PINPOINT TEST A
• PINPOINT TEST B
• PINPOINT TEST J
• PINPOINT TEST K
• RESTRAINTS CONTROL MODULE (RCM)
• PINPOINT TEST C
• PINPOINT TEST D
• PINPOINT TEST E
• PINPOINT TEST F
• PINPOINT TEST G
• PINPOINT TEST H
• PINPOINT TEST I
• PINPOINT TEST L
• PINPOINT TEST M
• DRIVER AIR BAG MODULE, PASSENGER AIR BAG MODULE AND SEAT SIDE AIR BAG MODULES - REMOTE DEPLOYMENT
