GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Rear View Mirror Adhesive TA-17 |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Exterior rear view mirror nuts | 7 |
| Exterior rear view mirror motor screws - Aero | 5 |
TORQUE SPECIFICATIONS
The rear view mirrors consist of the following
- Interior rear view mirror (17700).
- Exterior mirror control switch (14B133).
- Exterior rear view mirror trailer tow (17682/17683).
- Exterior rear view mirror, Western (17A721)
- Exterior rear view mirror glass.
- Exterior rear view mirror motor (Aero).
The interior rear view mirror
- Is windshield-mounted.
- Is a manual hand-set day/night mirror.
The exterior rear view mirrors
- Are controlled manually or by optional power controls.
- Are of a fold-away design.
Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.
SPECIAL TOOL(S)
Scheme 1
Scheme 2
- Verify the customer concern by operating the power exterior rear view mirrors.
- Visually inspect for obvious signs of mechanical and electrical damage. Refer to the following chart: VISUAL INSPECTION CHART
- Verify components or systems related to the fuse for correct operation. If the components or systems are not operating correctly, the fuse(s), fuse feed circuits or fuse load side circuit(s) may be faulty.
- If the fault is not visually evident, determine the symptom. GO to «SYMPTOM CHART»(ref-210206-S21601526092005121400000) .
