BRAKE SYSTEM GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Brake Pads | |
| Brake pad minimum thickness | 3.0 mm (0.118 inch) |
| Brake pad maximum thickness variation (pad-to-pad) | 2.0 mm (0.079 inch) |
| Brake pad maximum taper wear (in any direction) | 3.0 mm (0.118 inch) |
| Brake Disc | |
| Front brake disc minimum thickness (E-150) | 29.2 mm (1.14 inch) |
| Rear brake disc minimum thickness (E-150) | 20.4 mm (0.8 inch) |
| Minimum thickness to machine front brake disc (E-150) | 29.8 mm (1.17 inch) |
| Minimum thickness to machine rear brake disc (E-150) | 21.0 mm (0.82 inch) |
| Front brake disc minimum thickness (E-250, E-350) | 28.0 mm (1.1 inch) |
| Rear brake disc minimum thickness (E-250, E-350) | 28.0 mm (1.1 inch) |
| Minimum thickness to machine front brake disc (E-250, E-350) | 28.6 mm (1.12 inch) |
| Minimum thickness to machine rear brake disc (E-250, E-350) | 28.6 mm (1.12 inch) |
| Front brake disc minimum thickness (E-450) | 28.0 mm (1.1 inch) |
| Rear brake disc minimum thickness (E-450) | 36.3 mm (1.42 inch) |
| Minimum thickness to machine front brake disc (E-450) | 28.6 mm (1.12 inch) |
| Minimum thickness to machine rear brake disc (E-450) | 36.9 mm (1.45 inch) |
| Lubricant | |
| High Performance DOT 3 Motor Vehicle Brake Fluid PM-1 (Canada CPM-1) | ESA-M6C25-A |
| High Temperature Nickel Anti-Seize Lubricant XL-2 (Canada CXG-2-B) | ESE-M12A4-A |
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
| Brake Parts Cleaner PM-4 | |
BRAKE SYSTEM GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Brake master cylinder tube fitting, 9/16 | 20 |
| Brake master cylinder tube fitting, 7/16 | 20 |
| Caliper bleeder screw, rear | 15 |
| Caliper bleeder screw, front | 15 |
TORQUE SPECIFICATIONS
The braking system on the E-Series vehicle consists of the following components
- An electronic hydraulic control unit (HCU)
- Vacuum booster power booster (E-150 to E-350)
- A Hydro-Boost® power booster (E -450 only)
- Master cylinder
- Front brake discs
- Rear brake discs
- Parking brakes
- 4 wheel anti-lock brake system (4WABS)
The significant features of the brake system are as follows
- All vehicles are equipped with rear disc brakes. For additional information, refer to «DISC & DRUM»(ref-161514) .
- All vehicles have front disc brakes. For additional information, refer to «DISC & DRUM»(ref-161514) .
- The parking brake is foot-operated and, on the E-150, E-250 and E-350, uses a drum-in-hat brake system. The E-450 is equipped with a transmission-mounted parking brake. For additional information, refer to «DISC & DRUM»(ref-161514) .
- The brake hydraulic system is split front and rear at the brake master cylinder. For additional information on the brake hydraulic system, refer to «DISC & DRUM»(ref-161514) .
- The brake power assist is vacuum-operated on the E-150, E-250 and E-350. The E-450 is equipped with a Hydro-Boost® power brake booster powered by the power steering pump. For additional information, refer to «DISC & DRUM»(ref-161514) .
- All vehicles are equipped with a 4-wheel anti-lock brake system (4WABS). For additional information, refer to «ANTI-LOCK CONTROL»(ref-210121) .
Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.
SPECIAL TOOL(S)
Scheme 96
MATERIAL
| Item | Specification |
|---|---|
| High Performance DOT 3 Motor Vehicle Brake Fluid PM-1 (Canada CPM-1) | ESA-M6C25-A |
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
| Brake Parts Cleaner PM-4 |
MATERIAL SPECIFICATIONS
