Illuminated Entry

On vehicles equipped with an optional remote keyless entry (RKE) system, the illuminated entry activates the interior lamps anytime an RKE transmitter unlock button is pressed. The length of time the illuminated entry system is energized is controlled by the RKE module. The illuminated entry feature will be canceled when any of the following conditions are met

25 seconds have elapsed since the illuminated entry feature was activated and the interior lamp control is turned off.
The ignition is in the RUN or START position, and the interior lamp control is not activated.
The RKE transmitter lock button is pressed.

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

SPECIAL TOOL(S)

Scheme 10

Scheme 10: Interior Lighting

Scheme 11

Scheme 11: Inspection and Verification

Verify the customer concern.
Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART
If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
If the cause is not visually evident, verify the symptom and GO to «SYMPTOM CHART»(ref-210193-S18355673832005121400000) .
