Engine Emission Control: Specifications Ford Econoline E250

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

All engines are equipped with an exhaust gas recirculation (EGR) system. The function of the EGR system is to reduce the emission of nitrogen oxide (NOx).

The engine emission control system consists of the following components

1. Positive crankcase ventilation (PCV) system
2. Exhaust gas recirculation (EGR) system

The PCV system uses intake manifold vacuum to ventilate the crankcase and return the fumes to the intake manifold for combustion.

The EGR system returns a portion of the exhaust gas to the intake manifold to reduce the combustion temperature. This reduces the oxides of nitrogen (NOx) in the exhaust emissions.

The PCM controls the EGR vacuum regulator solenoid. The EGR vacuum regulator solenoid controls the vacuum to the EGR valve. When the EGR valve opens, exhaust gas flows to the intake manifold. The differential pressure feedback EGR sensor measures the flow through the EGR valve to exhaust manifold tube and sends a signal to the PCM. A metering orifice in the EGR valve to exhaust manifold tube restricts the flow rate when the EGR valve is open.

For further description and operation, refer to the appropriate INTRODUCTION article.

All engines are equipped with a positive crankcase ventilation (PCV) system. The function of the PCV system is to circulate blow-by gases from the engine crankcase to the engine intake.

The PCV system consists of

1. PCV valve
2. PCV tube

For further description and operation, refer to the appropriate INTRODUCTION article.

The exhaust gas recirculation (EGR) system includes

1. EGR valve actuator/Pintle position sensor
2. EGR cooler assembly

The exhaust gas recirculation (EGR) system reduces the peak combustion temperatures and oxides of nitrogen (NOx). The EGR valve is an electromechanical device that uses a linear actuator to control the relative position of the valve's pintle. This device also has a built-in pintle position sensor that functions to provide the powertrain control module (PCM) with a feedback signal. This output signal provides the information on the valve position relative to its seat. The advantage of this "closed loop" feedback is the ability to continuously vary exhaust gas flow to match operating conditions. The EGR cooler, cools a portion of the engine exhaust gases and then recirculates them back into the inlet air stream. This increases the engine's tolerance for EGR and reduces the amount of smoke formed by exhaust gas dilution of the mixture.

Scheme 1

Refer to the appropriate INTRODUCTION article.

Scheme 2

1. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
2. Remove the exhaust gas recirculation (EGR) valve. Disconnect the vacuum line. Disconnect the EGR valve tube fitting. Remove the bolts. Discard the gasket.

Scheme 3

Scheme 4

1. Carefully clean both sealing surfaces. Install a new EGR gasket.
2. Install the EGR valve. Tighten the bolts in two stages. Stage 1: Tighten the bolts to 20 Nm (15 lb-ft). Stage 2: Tighten the bolts an additional 90 degrees.
3. Connect the EGR valve. Connect the EGR valve tube fitting. Connect the vacuum line.
4. Install the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .

Scheme 5

Scheme 6

1. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
2. Disconnect the exhaust gas recirculation (EGR) valve tube upper fitting and EGR vacuum hose.
3. Remove the bolts and the EGR valve. Discard the gasket.

Scheme 7

Scheme 8

1. Carefully clean both sealing surfaces. Install a new EGR gasket and the EGR valve.
2. Install the EGR valve. Tighten the bolts in two stages. Stage 1: Tighten the bolts to 20 Nm (15 lb-ft). Stage 2: Tighten the bolts an additional 90 degrees.
3. Connect the EGR valve tube upper fitting and EGR vacuum hose.
4. Install the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .

Scheme 9

MATERIALS

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-210181) .
2. Remove the push pin retainers and upper air deflector.
3. Remove the bolts for the power steering bracket.
4. Remove the bolts and power steering fluid indicator. Remove the power steering reservoir mounting bracket. Install the power steering fluid indicator and position it aside.
5. Disconnect the coolant hoses from the air cleaner outlet tube.
6. Loosen the clamps and remove the air cleaner outlet tube.
7. Loosen the clamps and remove the charge air cooler (CAC) duct.
8. Remove the bolts and position the manifold absolute pressure (MAP) sensor and the ground wire aside.
9. Remove the bolts and disconnect the push pin retainer. Position the cowl wiring harness aside.
10. Loosen the clamp for the CAC duct.
11. Remove the bolts for the CAC duct and oil fill tube.
12. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
13. Loosen the clamp at the turbocharger outlet hose.
14. Disconnect the oil fill tube at the valve cover.
15. Remove the retaining nuts, CAC duct, oil fill tube and bracket.
16. Remove the bolts and intake adapter.
17. Disconnect the TP sensor electrical connector.
18. Disconnect the throttle position (TP) control module electrical connector.
19. Remove the bolts and throttle plate adapter. Cover the opening after the throttle plate adapter is removed.
20. Remove the secondary fuel filter and drain the housing. Install the fuel filter and cover.
21. Disconnect the fuel tubes at the secondary fuel filter and position them aside.
22. Remove the bolts and position the secondary fuel filter assembly aside.
23. Disconnect the EGR valve assembly electrical connector.
24. Remove the bolts and rotate the EGR valve counterclockwise.
25. Install the special tool and remove the EGR valve.
26. Remove and discard the O-ring seals and the EGR gaskets.
27. Using an appropriate brush, clean the EGR port. Vacuum the ash and foreign material from inside the intake manifold.

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. Position the secondary fuel filter and install the bolts.
2. Position the fuel tubes and connect at the secondary fuel filter.
3. Install a new EGR gasket. Install new O-ring seals and lubricate with clean engine oil.
4. Install the EGR valve and bolts.
5. Connect the EGR valve assembly electrical connector.
6. Install the throttle plate adapter and bolts.
7. Connect the TP sensor electrical connector.
8. Connect the TP control module electrical connector.
9. Install the intake adapter and bolts.
10. Install the CAC duct, oil fill tube, bracket and retaining nuts.
11. Connect the oil fill tube at the valve cover.
12. Install the bolts for the CAC duct and oil fill tube.
13. Tighten the clamp for the turbocharger outlet pipe.
14. Install the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
15. Tighten the clamp for the CAC duct.
16. Position the cowl wiring harness. Install the bolts and connect the push pin retainer.
17. Position the MAP sensor and install the bolt. Position the ground wire and install the bolt.
18. Install the CAC duct and tighten the clamps.
19. Install the air cleaner outlet tube and tighten the clamps.
20. Connect the coolant hoses to the air cleaner outlet tube.
21. Remove the power steering fluid indicator. Install the power steering reservoir mounting bracket and bolts, then install the power steering fluid indicator.
22. Install the bolts for the power steering reservoir bracket.
23. Install the upper air deflector and push pin retainers.
24. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-210181) .

Scheme 49

Scheme 50

1. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
2. Disconnect the differential pressure feedback exhaust gas recirculation (EGR) sensor hoses.
3. Remove the EGR valve tube. Disconnect the upper and lower fittings. Remove the tube.
4. To install, reverse the removal procedure.

Scheme 51

Scheme 52

1. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
2. Disconnect the differential pressure feedback exhaust gas recirculation (EGR) sensor hoses.
3. Remove the EGR valve tube. Disconnect the upper and lower fittings. Remove the tube.
4. To install, reverse the removal procedure.
