Ford Econoline E150 (1997-2012) lt grn Wiring diagrams

1 2 3 4 5 6 7 8 9 10 11 ABS WARNING LAMP OUTPUT RELAY CTRL OUTPUT 1 2 GROUND POWER 14 15 16 17 18 19 20 21 22 23 24 POWER BPP SWITCH INPUT ABS CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT) ABS RELAY (BEHIND CENTER OF DASH) ACCY ANTI-LOCK BRAKE INDICATOR BATTERY JUNCTION BOX (IN LEFT FRONT OF ENGINE COMPARTMENT) BLK WIRE BRAKE FLUID LEVEL SWITCH (AT LEFT SIDE OF ENGINE COMPT) BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) BRAKE WARN LAMP HIGH DATA LINK CONN BRAKE WARNING INDICATOR BRAKE WARNING LAMP LOW DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DIESEL DK GRN WIRE DK GRN/YEL WIRE ELECTRONIC CRASH SENSOR (ECS) MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE CONTROLS SYSTEM FUSE 1 FUSE 11 FUSE 19 HOT AT ALL TIMES HOT IN RUN IGNITION SWITCH INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT FRONT WHEEL SPEED SENSOR LOCK OFF LT BLU WIRE LT BLU/PNK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE NCA WIRE OHM 1600 PNK WIRE PNK/LT GRN WIRE REAR AXLE SPEED SENSOR REAR SENSOR (HIGH) RIGHT FRONT SENSOR (HIGH) LEFT FRONT SENSOR (HIGH) REAR SENSOR (LOW) RIGHT FRONT SENSOR (LOW) LEFT FRONT SENSOR (LOW) RED WIRE RED/BLK WIRE RIGHT FRONT WHEEL SPEED SENSOR RUN WIRE TAN WIRE TAN/BLK WIRE TAN/LT GRN WIRE TAN/ORG WIRE VIO WIRE VIO/YEL WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

1 2 3 4 5 6 7 8 9 10 11 DATA LINK CONN BPP SWITCH INPUT 7.3L ABS CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT) ANTI-LOCK BRAKE INDICATOR BATTERY JUNCTION BOX (BJB) (IN LEFT FRONT OF ENGINE COMPARTMENT) BLK WIRE BRAKE FLUID LEVEL SWITCH (AT LEFT SIDE OF ENGINE COMPT) BRAKE PEDAL POSITION (BPP) SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) BRAKE WARNING INDICATOR DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH) DK GRN WIRE ELECTRONIC CRASH SENSOR (ECS) MODULE (BEHIND RIGHT SIDE OF DASH) FUSE 1 FUSE 11 FUSE 19 GRN WIRE GROUND VBATT GROUND VBATT BRAKE WARNING LAMP LOW HOT AT ALL TIMES HOT IN RUN IGNITION SWITCH INSTRUMENT CLUSTER LEFT FRONT SENSOR (LOW) RIGHT FRONT SENSOR (LOW) REAR SENSOR (LOW) LEFT FRONT WHEEL SPEED SENSOR (BEHIND LEFT FRONT WHEEL) LOCK OFF LT BLU WIRE LT BLU/PNK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE NCA WIRE PARKING BRAKE SWITCH (NEAR LEFT KICK PANEL) PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (NEAR BRAKE MASTER CYLINDER) RED WIRE RED/PNK WIRE RIGHT FRONT WHEEL SPEED SENSOR (BEHIND RIGHT FRONT WHEEL) RUN WIRE TAN WIRE TAN/BLK WIRE TAN/LT GRN WIRE TAN/ORG WIRE VACUUM WARNING SWITCH VIO/WHT WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) AUXILIARY POWERTRAIN CONTROL MODULE (7.3L DIESEL) (LEFT SIDE OF DASH) BLK WIRE BLK/LT BLU WIRE BLK/WHT WIRE DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH) ELECTRONIC CRASH SENSOR MODULE (BEHIND RIGHT SIDE OF DASH) HOT AT ALL TIMES HOT AT ALL TIMES CENTRAL JUNCTION BOX (LEFT SIDE OF DASH) FUSE 23 IGNITION SWITCH LOCK OFF LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/RED WIRE NATURAL GAS VEHICLE MODULE (LEFT FRONT INNER FENDER) PNK WIRE PNK/LT BLU WIRE POWERTRAIN CONTROL MODULE (PCM) (NEAR MASTER BRAKE CYLINDER) RED WIRE RED/LT GRN WIRE RUN WIRE TAN/ORG WIRE VIO WIRE WHT WIRE

BLK WIRE BRN WIRE CENTRAL JUNCTION BOX LEFT SIDE OF DASH, NEAR KICK PANEL) ENDS IN HARNESS FUSE 4 HOT AT ALL TIMES INTERIOR LEFT FRONT DOOR AJAR SWITCH LT BLU WIRE LT GRN WIRE MAIN LIGHT SWITCH NCA WIRE PNK WIRE RED WIRE RIGHT FRONT DOOR AJAR SWITCH WARNING SYSTEMS YEL WIRE

1 2 3 4 5 6 P V LO BEAM BATT IGN GND HI BEAM IN 507/13 527/12 BATTERY JUNCTION BOX BLK WIRE BLK/LT BLU WIRE BLK/ORG WIRE CENTRAL JUNCTION BOX FUSE 30 DK BLU WIRE FLASH TO PASS FUSE 15 FUSE 25 FUSE 31 FUSE 6 HEAD PARK HI PASS LO HOT AT ALL TIMES HOT AT ALL TIMES CENTRAL JUNCTION BOX FUSE 10 HOT AT ALL TIMES FUSE 27 HOT IN INSTRUMENT CLUSTER HI BEAM IND. LEFT HEADLAMP LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MAIN LIGHT SWITCH MULTI- FUNCTION SWITCH DIMMER OFF ORG/ WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT HEADLAMP RUN WIRE TAN WIRE VIO WIRE VIO/ORG WIRE WHT WIRE YEL/LT BLU WIRE

ANTENNA BLK WIRE BLK/LT GRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (CJB) (LEFT SIDE OF DASH, NEAR KICK PANEL) CUTAWAYS DK GRN/ORG WIRE FUSE 22 FUSE 27 FUSE 3 FUSE 36 GRY/LT BLU WIRE HINGED SIDE DOOR HOT AT ALL TIMES HOT IN HOT IN PARK OR HEAD HOT IN RUN OR ACC ILLUMINATION GROUND NOISE REDUCTION LEFT FRONT DOOR SPEAKER LEFT MID SPEAKER (W/ 6 SPEAKERS) LEFT REAR SPEAKER LT BLU WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE NOT USED ORG/LT GRN WIRE ORG/RED WIRE RADIO RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT SPEAKER RIGHT MID SPEAKER (W/ 6 SPEAKERS) RIGHT MID SPEAKER (W/ 6 SPEAKERS) RIGHT REAR SPEAKER RIGHT SLIDING DOOR CONTACT SWITCH SLIDING SIDE DOOR TAN/YEL WIRE VANS, WAGONS WHT WIRE WHT/LT GRN WIRE YEL WIRE YEL/BLK WIRE

ANTENNA BARE BARE SHIELD SIGNAL SIGNAL SIGNAL SIGNAL BLK WIRE BLK/LT GRN WIRE BRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX LEFT SIDE OF DASH, NEAR KICK PANEL) DK GRN/ORG WIRE FUSE 22 FUSE 27 FUSE 3 FUSE 33 FUSE 36 FUSE 39 GRY/LT BLU WIRE HOT AT ALL TIMES HOT IN HOT IN PARK OR HEAD HOT IN RUN OR ACC ILLUMINATION GROUND NOISE REDUCTION LEFT FRONT DOOR SPEAKER LT BLU WIRE LT BLU/PNK WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE NCA WIRE ORG/ WIRE ORG/LT GRN WIRE ORG/RED WIRE PNK 1 WIRE POWER POINT CONSOLE 1 POWER POINT CONSOLE 2 RADIO RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT SPEAKER SIGNAL SIGNAL SIGNAL TAN WIRE TAN/YEL WIRE WHT WIRE WHT/LT GRN WIRE YEL WIRE YEL/BLK WIRE

240 OHMS A/C SYSTEM BLK WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR (ON FRONT CENTER OF ENGINE) CENTRAL JUNCTION BOX (BELOW LEFT SIDE OF DASH, NEAR LEFT KICK PANEL) DIGITAL TRANSMISSION RANGE (DTR) SENSOR (LEFT SIDE OF TRANSMISSION) DK BLU/YEL WIRE DK GRN WIRE DK GRN/VIO WIRE DPFE INPUT CHT INPUT CANISTER VENT VSS (+) A/C RLY CNTRL EVAPORATIVE EMISSIONS CANISTER VENT SOLENOID (REAR OF VEHICLE, NEAR FUEL TANK) FROM DTR SENSOR (DIAGRAM 1 OF 4) FUEL TANK PRESS FUSE 11 GROUND GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR 11 HEATED OXYGEN SENSOR 12 HEATED OXYGEN SENSOR 21 HEATED OXYGEN SENSOR 22 HEATER CTRL HOT AT ALL TIMES IAC CTRL OSS (-) CMP SENSOR INJ 5 CTRL INJ 3 CTRL INJ 1 CTRL GND GND IGN COIL TCIL FUEL PUMP CTRL EPC SOL INJ 6 CTRL INJ 4 CTRL INJ 2 CTRL LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE MAF SENS OUT TP SENS IN REF OUTPUT VOLT SIG RTN BRAKE ON/OFF MASS AIR FLOW SENSOR (ON TOP (CENTER OF ENGINE COMPT) NCA WIRE OVER- HEAD CONSOLE PNK/WHT WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (LEFT REAR OF ENGINE COMPT, NEAR MASTER CYLINDER) RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/YEL WIRE TCC SOL KAP B(+) EVAP VALVE KNOCK SENSOR VIO/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE VPWR VSS INPUT WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE

240 OHMS BLK/LT GRN WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR (FRONT OF LEFT CYLINDER HEAD) CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION) DK BLU/YEL WIRE DK GRN WIRE DPFE SENS CYL HEAD TEMP EVAP SOL VSS (+) EXCEPT STRIPPED CHASSIS FROM DTR SENSOR (DIAGRAM 1 OF 4) FUEL TANK PRESS IPS SENSOR FUSE 11 GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR HEATER CTRL HOT AT ALL TIMES IAC SOL OSS (+) CYLINDER ID LT BLU WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE LT GRN/RED WIRE MAF SENS IN TP SENS IN MASS AIR FLOW SENSOR (TOP CENTER OF ENGINE COMPT) NCA WIRE OVER- HEAD CONSOLE PNK/LT BLU WIRE PNK/WHT WIRE PWR GND COIL ON PLUG 2 RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE SIG RTN BRAKE ON/OFF STRIPPED CHASSIS TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TAN/YEL WIRE VIO/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE VPWR FUEL INJ 8 FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 VSS INPUT WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE

240 OHMS BLK/LT GRN WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR (FRONT OF LEFT CYLINDER HEAD) CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) DIGITAL TRANSMISSION RANGE SENSOR (DTR SENSOR) (LEFT SIDE OF TRANSMISSION) DK BLU/YEL WIRE DK GRN WIRE DK GRN/WHT WIRE DPFE SENS CYL HEAD TEMP EVAP SOL VSS (+) EXCEPT STRIPPED CHASSIS FROM DTR SENSOR (DIAGRAM 1 OF 4) FUEL TANK PRESS IPS SENSOR FUSE 11 GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR HEATER CTRL HOT AT ALL TIMES IAC SOL OSS (+) CYLINDER ID LT BLU WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE LT GRN/RED WIRE MAF SENS IN TP SENS IN MASS AIR FLOW SENSOR (TOP CENTER OF ENGINE COMPT) NCA WIRE OVER- HEAD CONSOLE PNK/LT BLU WIRE PNK/WHT WIRE PWR GND COIL ON PLUG 2 RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE SIG RTN BRAKE ON/OFF STRIPPED CHASSIS TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TAN/YEL WIRE TSS SENSOR VIO/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE VPWR FUEL INJ 8 FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 VSS INPUT WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE
