Ford Econoline E150 (1997-2012) lt grn Wiring diagrams

BATTERY BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DIGITAL TRANSMISSION RANGE (DTR) SENSOR (LEFT SIDE OF TRANSMISSION) DK GRN WIRE DRIVE FUSE 18 FUSE 33 FUSE 7 HOT AT ALL TIMES IGNITION SWITCH LOCK OFF LT BLU WIRE LT GRN WIRE NEUTRAL PARK PNK WIRE RED WIRE REV RUN WIRE STARTER MOTOR (AT LOWER RIGHT REAR OF ENGINE) STARTER RELAY TAN WIRE VIO WIRE WHT WIRE YEL WIRE

BATTERY BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DIGITAL TRANSMISSION RANGE (DTR) SENSOR (LEFT SIDE OF TRANSMISSION) DK GRN WIRE DRIVE FUSE 18 FUSE 33 FUSE 7 HOT AT ALL TIMES IGNITION SWITCH LOCK OFF LT BLU WIRE LT GRN WIRE NEUTRAL PARK PNK WIRE RED WIRE REV RUN WIRE STARTER MOTOR (AT LOWER RIGHT REAR OF ENGINE) STARTER RELAY TAN WIRE VIO WIRE WHT WIRE YEL WIRE

16 17 15 DRIVER DOOR AJAR SLIDING DOOR AJAR DOORS AJAR 23 22 MS CAN+ MS CAN- 5 10 RUN/START PWR GROUND BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BLK/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FRONT PASSENGER WINDOW/DOOR LOCK SWITCH FUSE 14 FUSE 22 HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER LEFT FRONT DOOR AJAR SWITCH (AT LEFT KICK PANEL) LOCK LOGIC GROUND LR GRN WIRE LT BLU WIRE LT GRN WIRE MASTER WINDOW/ DOOR LOCK/UNLOCK SWITCH NCA WIRE PNK PNK WIRE PNK WIRE PNK/LT GRN WIRE PNK/YEL WIRE REAR DOORS DOOR AJAR RED WIRE RED/PNK WIRE RED/WHT WIRE RIGHT FRONT DOOR AJAR SWITCH (AT RIGHT KICK PANEL) RIGHT SIDE DOOR AJAR SWITCH (IN FRONT OF RIGHT SIDE DOOR) RIGHT SLIDING DOOR AJAR SWITCH (AT RIGHT "B" PILLAR) SWITCH (EXCEPT CUTAWAY) UNLOCK W/ HINGED CARGO DOOR W/ SLIDING CARGO DOOR WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE

11 1 DOME REQ BATTERY SVR 16 13 15 17 LF AJAR SW SIG CRTSY LAMP DR AJAR SW SIG SLIDING DOOR AJAR SW SIG AUXILIARY CARGO LAMP AUXILIARY RELAY BOX 2 (BEHIND CENTER OF DASH) INTERIOR LAMP RELAY BATTERY SAVER RELAY BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/WHT WIRE CARGO LAMP CARGO LAMP 1 CARGO LAMP 2 CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DOME DOOR AJAR SWITCH (LEFT FRONT) (BEHIND LEFT KICK PANEL) MAIN LIGHT SWITCH DOOR AJAR SWITCH (REAR DOORS) (EXCEPT CUTAWAY) FUSE 22 FUSE 4 HIGH MOUNTED STOPLAMP HOT AT ALL TIMES INSTRUMENT CLUSTER INTERIOR LAMP INTERIOR/ MAP LAMPS ASSEMBLY (FRONT) LT BLU WIRE LT GRN WIRE LT GRN/ORG WIRE LT GRN/YEL WIRE NCA WIRE OFF ORG/ WIRE ORG/LT GRN WIRE REAR INTERIOR LAMP RED WIRE RED/PNK WIRE RIGHT FRONT DOOR AJAR SWITCH (BEHIND RIGHT KICK PANEL) RIGHT SIDE DOOR AJAR SWITCH (FRONT OF RIGHT SIDE FRONT HINGED DOOR) RIGHT SLIDING DOOR AJAR SWITCH (AT RIGHT "B" PILLAR) VANITY MIRROR LAMP (LEFT) VANITY MIRROR LAMP (RIGHT) VIO WIRE VIO/ORG WIRE W/ FULL HEADLINER W/ HINGED W/ SLIDING CARGO DOOR CARGO DOOR W/ SPEAKER W/O SPEAKER WHT WIRE YEL WIRE

BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 4 HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE MAIN LIGHT SWITCH OFF DOME TO I/P BODY BUILDER CONNECTOR YEL WIRE

BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) BRN WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 39 DK BLU WIRE DK GRN WIRE ELECTRONIC FLASHER MODULE (BEHIND LEFT SIDE OF DASH) ENDS IN HARNESS FUSE 10 FUSE 11 FUSE 7 GRN WIRE HAZARD SWITCH HEAD OFF HOT AT ALL TIMES HOT IN RUN INSTRUMENT CLUSTER LEFT TURN LEFT TURN IND LEFT TURN SIGNAL LT BLU WIRE LT GRN WIRE LT GRN/WHT WIRE MAIN LIGHT SWITCH MICROPROCESSOR MULTI- FUNCTION SWITCH ORG/ WIRE PARK RED WIRE RESISTOR RIGHT TURN RIGHT TURN IND RIGHT TURN SIGNAL SIDE MARKER STOP LAMPS TAN WIRE TO PARKING LAMP TRAILER TOW RELAY (DIAGRAM 2 OF 2) TO RIGHT TURN TRAILER TOW RELAY (DIAGRAM 2 OF 2) W/ REAR LIGHTS W/O REAR LIGHTS WHT WIRE WHT/LT BLU WIRE YEL WIRE

AUXILIARY BATTERY DIODE BATTERY JUNCTION BOX (LEFT FRONT FRONT OF OF ENG COMPT) AUXILIARY BATTERY RELAY (RIGHT FRONT OF ENGINE COMPT, NEAR BATTERY) AUXILIARY RELAY BOX 1 (AT LEFT SIDE OF ENGINE COMPT) BACK-UP LAMPS CIRCUIT BATTERY 2 BATTERY CHARGE TRAILER TOW RELAY BATTERY JUNCTION BOX (BJB) BATTERY JUNCTION BOX (BJB) (AT LEFT FRONT OF ENGINE COMPT) BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT) BLK WIRE BLU WIRE BRN WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE ENDS IN HARNESS EXCEPT DIESEL, W/ AUXILIARY BATTERY EXCEPT DIESEL, W/ AUXILIARY BATTERY JUMPER FUSE 12 FUSE 15 FUSE 20 FUSE 24 FUSE 26 FUSE 8 HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR ACC LEFT TURN TRAILER TOW RELAY LT BLU WIRE LT GRN WIRE ORG/ WIRE PARKING LAMP TRAILER TOW RELAY PNK WIRE RED WIRE RED/YEL WIRE REVERSING LAMP TRAILER TOW RELAY RIGHT FRAME RAIL) RIGHT TURN TRAILER TOW RELAY TRAILER TOW CONNECTOR (7 PIN) (CLASS II) (AT RIGHT SIDE OF REAR BUMPER) VIO WIRE W/O AUXILIARY BATTERY WHT WIRE WHT/VIO WIRE YEL WIRE

1 2 3 4 5 6 LO BEAM VBATT VPWR GND FPPWR BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT) BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 30 DAYTIME RUNNING LAMPS (DRL) MODULE (RIGHT FRONT OF ENGINE COMPARTMENT) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/ORG WIRE DRL EXCEPT DIESEL DIESEL FUSE 10 FUSE 15 FUSE 25 FUSE 3 FUSE 31 FUSE 6 GRY WIRE GRY/WHT WIRE HI FTP LO HI-BEAM IND HIGH BEAM, DRL HOT AT ALL TIMES HOT IN INSTRUMENT CLUSTER LOGIC GROUND LOW BEAM LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MAIN LIGHT SWITCH MULTI- FUNCTION SWITCH OFF HEAD PARK ORG/ WIRE PARK BR SW PARKING BRAKE SWITCH (NEAR LEFT KICK PANEL) RED WIRE RED/BLK WIRE RUN WIRE STRIPPED CHASSIS CONNECTIONS TAN WIRE W/ PARKING AID WHT WIRE WHT/LT BLU WIRE YEL WIRE

AUXILIARY BLOWER MOTOR (BEHIND LEFT REAR WHEELWELL) AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY (BEHIND LEFT REAR WHEELWELL) AUXILIARY BLOWER MOTOR SWITCH BLK WIRE BLOWER MOTOR RELAY BLOWER MOTOR RESISTOR (RIGHT SIDE OF ENGINE COMPT) BRN WIRE DK BLU WIRE FROM FUNCTION SELECTOR SWITCH (DIAGRAM 1 OF 2) FRONT BLOWER MOTOR (RIGHT REAR OF ENGINE COMPT) FRONT FUNCTION SELECTOR SWITCH ASSEMBLY MH ML HIGH LOW BLOWER MOTOR SWITCH FUSE 14 FUSE 17 HOT AT ALL TIMES LT BLU WIRE LT BLU/ORG WIRE LT GRN WIRE ML MH OFF ORG/ WIRE ORG/BLK WIRE PNK WIRE REAR A/C BLOWER SPEED RELAY 1 (IN LEFT REAR CORNER OF VEHICLE, ABOVE WHEELWELL) REAR A/C BLOWER SPEED RELAY 2 (IN LEFT REAR CORNER OF VEHICLE, ABOVE WHEELWELL) RED WIRE RED/ORG WIRE VAN, WAGON CUTAWAY WHT WIRE YEL WIRE

10 5 PWR GROUND RUN/START 16 17 15 DRIVER DOOR AJAR SLIDING DOOR AJAR DOORS AJAR 23 22 MS CAN+ MS CAN- BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BLK/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FRONT PASSENGER WINDOW/DOOR LOCK SWITCH FUSE 14 FUSE 22 HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER (IC) LEFT FRONT DOOR AJAR SWITCH (BEHIND LEFT KICK PANEL) LOCK UNLOCK LOGIC GROUND LT BLU WIRE LT GRN WIRE MASTER WINDOW/ DOOR LOCK/UNLOCK SWITCH NCA WIRE PNK PNK WIRE PNK WIRE PNK/LT GRN WIRE PNK/YEL WIRE REAR DOORS DOOR AJAR RED WIRE RED/PNK WIRE RED/WHT WIRE RIGHT FRONT DOOR AJAR SWITCH (BEHIND RIGHT KICK PANEL) RIGHT SIDE DOOR AJAR SWITCH (FRONT OF RIGHT SIDE FRONT HINGED DOOR) RIGHT SLIDING DOOR AJAR SWITCH (AT RIGHT "B" PILLAR) SWITCH (EXCEPT CUTAWAY) UNLOCK LOCK W/ HINGED CARGO DOOR W/ SLIDING CARGO DOOR W/ STRIPPED CHASSIS WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE
