Maintenance Information Ford Crown Victoria I

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 1

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

1. Short Trips (About 10 Miles) In Freezing Temperatures
2. Towing Or Heavily Loaded
3. Severe Dust Conditions
4. Hot Weather, Stop-And-Go Driving
5. Extensive Idling Conditions (Taxi Or Delivery Type Service)

Normal Service

1. Driven More Than 10 Miles Daily
2. No Operating Conditions From Severe Service Schedule

REAR AXLE FLUID CHANGE

Rear axle lubricant must be changed every 100,000 miles. Change fluid immediately if the axle has been submerged in water. Otherwise, check level only if a leak is suspected or a repair is required.

COOLING SYSTEM, HOSES & CLAMPS

Replace engine coolant every 36 months or 30,000 miles, whichever comes first. Check condition of hoses and clamps annually, regardless of mileage or driving conditions. Replace hoses and clamps as necessary.

Scheme 2

SERVICE LABOR TIMES

Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

Inflation pressure and recommended tire size can be found on decal attached to front face of right door pillar.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 85-104 ft. lbs. (115-142 N.m). If wheels are equipped with locking type lug nuts, ALWAYS position "Keyed" nut opposite valve stem.

Note. On vehicles equipped with anti-theft wheel lug nuts, there is one locking lug nut on each wheel. The key for this nut is attached to the lug wrench in spare tire compartment.

BATTERY SPECIFICATIONS

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM

Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.

The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.

When performing maintenance on air bag equipped vehicles always observe proper safety precautions.

ANTI-LOCK BRAKE SYSTEM (ABS)

BATTERY WARNING

REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

ENGINE OIL

FUEL SYSTEM SERVICE

HALOGEN BULBS

RADIATOR CAP

RADIATOR FAN

SPARK PLUGS

Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.

WARRANTY INFORMATION

BASIC NEW CAR LIMITED WARRANTY

All parts of the vehicle, except tires, are covered against defects in factory-supplied materials and workmanship for 12 months or 12,000 miles, whichever occurs first.

POWERTRAIN WARRANTY

Note. Powertrain Warranty varies in coverage length (4 years/50,000 miles or 6 years/60,000 miles) depending on model year.

Under this warranty, certain parts of the engine, transmission, axle and driveline are warranted against defects in materials and workmanship. This coverage begins after 12 months or 12,000 miles. See copy of warranty for specific components covered and length of coverage.

BUMPER-TO-BUMPER COVERAGE

All 1992-93 vehicles have complete warranty coverage against defects in materials and workmanship for 3 years or 36,000 miles, whichever occurs first.

Note. 1991-93 Lincoln models are covered bumper-to-bumper for 4 years or 50,000 miles whichever occurs first.

There is no deductible with this warranty. Items not covered include tires and parts that are subject to normal wear and tear, such as windshield wiper blades, brake linings, brake pads, clutch linings and scheduled maintenance items. There is no extended powertrain coverage included in this warranty.

BATTERY COVERAGE

Begins at warranty start date and lasts up to 3 years or 36,000 miles, whichever occurs first. For the first 12 months in service (less than 36,000 miles), battery will be replaced at no charge. After that, battery will be replaced on a customer-participation basis: For the 13th-24th month in service, Ford will pay 50%; for the 25th-36th month, Ford will pay 25%. Labor is covered for 3 years or 36,000 miles, whichever occurs first.

SAFETY RESTRAINT SYSTEM COVERAGE

Begins at warranty start date and lasts for 5 years or 50,000 miles, whichever occurs first. Covers safety restraint problems not related to comfort or appearance. Coverage for model years earlier than 1990 is 3 years with unlimited miles.

CORROSION COVERAGE

Begins at warranty start date and lasts for 6 years or 60,000 miles, whichever occurs first. 1992-93 models are covered for 6 years or 100,000 miles, whichever occurs first. Covers any holes in body sheet metal caused by corrosion.

EMISSIONS DEFECT & PERFORMANCE WARRANTIES (EXCEPT CALIFORNIA)

Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship for a period of 5 years or 50,000 miles, whichever occurs first.

The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed for the vehicle to pass a Federally required state or local emissions test.

Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered. Performance Warranty coverage is limited to fewer components after 2 years or 24,000 miles.

EMISSIONS PERFORMANCE WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

EMISSIONS DEFECT WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are warranted for 7 years or 70,000 miles whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

The fuse panel is located in the instrument panel to the left of the steering column. To expose fuse panel, remove lower steering column finish panel.

Scheme 3

Fuse & Circuit Breaker Identification

1. 1 - 15 Amp Stoplights & Speed Control Module, Emergency Warning System, Cornering Light & Trailer Tow Relays
2. 2 - 8.25 Amp (Circuit Breaker) Windshield Wiper/Washer
3. 3 - Blank
4. 4 - 15 Amp Side Marker, Taillights & Park Lights, License & Coach Lights, Cluster Illumination, Trailer Tow Relay, Automatic Light (1988-89)
5. 5 - 15 Amp Turn Signal & Back-Up Lights, Trailer Tow & Cornering Relays, Keyless Entry Module, Illuminated Entry (1983-85), Load Leveling Module (1986-89), Day/Night Mirror (1986-89), Rear Defrost (1988-89)
6. 6 - 20 Amp Trunk Release & Speed Control, Cornering Lights, Chime & A/C Clutch, Heated Rear Window Control, Tripminder (1988-89)
7. 7 - 10 Amp Electric Heated Mirror
8. 8 - 15 Amp Courtesy & Trunk Lights, Clock & Garage Door Opener, Ignition Key Warning Chime, Keyless Entry & Visor Lights, Electric Mirrors & Autolight Module, Illuminated Entry (1983-85), Underhood Light (1983-85), Electronic Radio Memory (1983-85), Miles-to-Empty (1983-87), Anti-Theft Warning Light (1986-89), Tripminder (1988-89)
9. 9 - 30 Amp ATC Blower Motor
10. 10 - 20 Amp Passing Beam
11. 11 - 15 Amp Radio & Power Antenna, CB Radio (If Equipped)
12. 12 - 20 Amp (Circuit Breaker) ( 1 )( 2 ) Power Seats & Door Locks, Keyless Entry System Door Cigarette Lighters, Remote Convenience (1985)
13. 13 - 5 Amp Instrument Panel Lights, Illuminated Outside Thermometer
14. 14 - 20 Amp (Circuit Breaker) ( 2 ) Sun Roof & Power Window Relays, 2-Door Power Windows (1983-85), Keyless & Illuminated Entry (1983-85), Flash-To-Pass Relay (1986-89)
15. 15 - Blank
16. 16 - 20 Amp Horns & Instrument Panel Cigarette Lighter
17. 17 - 20 Amp Air Conditioning
18. 18 - 10 Amp Warning Lights & Seat Belt Chimes, Throttle Solenoid Positioner, Low Fuel Module & Autolight System, Low Oil Level Relay (1986-89), Day/Night Mirror (1986-89), Message Center (1986-89)

( 1 ) - 30 Amp (Circuit Breaker) on some models.

( 2 ) - 25 Amp fuse on Crown Victoria wagons.

FUSE PANEL IDENTIFICATION (1991-92 LINCOLN TOWN CAR)

The fuse panel is located in the instrument panel to the left of the steering column. To expose fuse panel, remove lower steering column finish panel.

Scheme 4

1. 1 - 15 Amp Stoplights, Hazard Warning Lights, Speed Control Module, Trailer Tow Relays, Cornering Light Relay (1983-89)
2. 2 - 8.25 Amp (Circuit Breaker) Windshield Wiper/Washer
3. 3 - Blank
4. 4 - 15 Amp Taillights, Side Marker, License Light, Parking & Coach Lights, Cluster Illumination, Trailer Tow Relay
5. 5 - 15 Amp Turn Signal & Back-Up Lights, Trailer Tow Relay, Cornering Light Relays, Heated Rear Window Relay, Rear Defrost (1988-92), A/C Clutch & ATC Module (1990-91), Load Leveling (1990-91)
6. 6 - 20 Amp Heated Rear Window Control, Speed Control Module & Clock Display, Illuminated Entry Module, Power Window & Police Accy Relays, Fuel Filler Door Release (1983-87), A/C Clutch & Cornering Lights (1983-89), Deck Lid Release (1987-92), Tripminder
7. 7 - 10 Amp Electric Heated Mirror (1992), Daytime Running Light Resistor (1990-91)
8. 8 - 15 Amp Dome LP-Clock, Key Warning Chimes & Electric Mirrors, Courtesy & Visor Mirror Lights, Autolight & Illuminated Entry Modules, Tripminder, Electronic Radio Memory, Trunk & Underhood Lights
9. 9 - 15/30 Amp Heater Blower (15 Amp), AC/ATC Blower (30 Amp)
10. 10 - Blank
11. 11 - 20 Amp Radio & Power Antenna, CB Radio
12. 12 - 20 Amp Door Cigarette Lighters, Power Seats & Door Locks (30 Amp), Tailgate Power Window (1983-89)
13. 13 - 5 Amp Illuminated Outside Thermometer, Instrument Panel Lights
14. 14 - 20/25 Amp (Circuit Breaker) Flash-To-Pass, Sun Roof, Power Windows
15. 15 - 10 Amp Taillights, Parking, Side Marker/Coach, License Lights
16. 16 - 20 Amp Horn & Front Cigarette Lighter
17. 17 - 15 Amp Electronic Cluster, Message Center
18. 18 - 10 Amp Warning Indicator Lights, Throttle Solenoid Positioner, Low Fuel Module & Autolight System, Dual Timer Buzzer & Electronic Chimes, Electronic Message Center

The fuse panel is located in the instrument panel to the left of the steering column. To expose fuse panel, remove lower steering column finish panel.

Scheme 5

1. 1 - 30 Amp Air Conditioning/Heater Blower Motor
2. 2 - 8.25 Amp (Circuit Breaker) Windshield Wiper/Washer, Interval Wiper Mode, Wiper Governor
3. 3 - Blank
4. 4 - 15 Amp Illuminated Entry, Power Mirrors, Interior Illumination, Keyless Entry, Electronic Door Lock Control, Clock, Electronic Cluster, Radio
5. 5 - 10 Amp Air Bag Module, Electronic Cluster, Radio, Clock, Air Bag Diagnostic Monitor
6. 6 - 10 Amp Illuminated Entry, Automatic Temperature, Control Warning Chime, Radio LCD Marker Lights, Radio Display Dimming, Safety Belt Warning Chime, Clock, Police, Speed Control
7. 7 - 15 Amp Hazard Lights, Stoplights
8. 8 - 20 Amp Cigarette Lighter, Fuel Filler Door Release
9. 9 - 15 Amp Parking Lights, Taillights, Clock/Lighter Illumination
10. 10 - 20 Amp Automatic Temperature Control, Manual Air Conditioning, Stoplights, Turn Signals, Hazard Lights
11. 11 - 5 Amp Instrument Panel Illumination
12. 12 - 30 Amp (Circuit Breaker) Power Windows, Deck Lid Release
13. 13 - 10 Amp Headlights, Warning Chime, Analog Cluster, Autolights Safety Belt Warning Chime
14. 14 - Blank
15. 15 - 10 Amp Anti-Lock Brakes, Analog Cluster, Electronic Cluster
16. 16 - 15 Amp Radio, Clock, Power Antenna, CD Changer, Cellular Telephone
17. 17 - 15 Amp Headlights, (Daytime Running Lights), Trailer Tow, Heated Rear Window Defroster, Heated Windshield, Keyless Entry, Electronic Door Lock Control, EVO, Air Suspension, Back-Up Lights, Speed Control
18. 18 - 15 Amp EEC, PCM, Air Bags, Electronic Cluster, Heated Oxygen Sensor (HO2S) 09F472

The power distribution box is located in the engine compartment near the battery.

Scheme 6

Fuse, Relay & Circuit Breaker Identification

1. A - 30 Amp Trailer Towing (Police Option Only)
2. B - 20 Amp Trailer Towing
3. C - 25 Amp Audio
4. D - 30 Amp Generator
5. E - 15 Amp Horn
6. F - 30 Amp Trailer Towing
7. G - 30 Amp Door Lock, Seat Motors, Fuel Filter, Luggage Compartment Lid
8. H - 30 Amp - 50 Amp Air Suspension Pump (Police Option Only)
9. J - 60 Amp Ignition Switch
10. K - 50 Amp Ignition Switch
11. L - 40 Amp Lighting
12. M - 30 Amp EEC/PCM
13. N - 30 Amp ABS Control Module
14. P - 40 Amp Heated Rear Window
15. R - 50 Amp ABS Pump
16. S - 20 Amp Fuel Pump
17. T - 20 Amp Ignition Coil
18. U - 30 Amp Air Suspension
19. V - Relay Horn Relay
20. W - Relay ABS Relay
21. X - Relay Air Suspension Relay

FUSE PANEL IDENTIFICATION (1993-96 - EXCEPT 1995-96 TOWN CAR)

The fuse panel is located in the instrument panel to the left of the steering column. To expose fuse panel, remove lower steering column finish panel.

Scheme 7

1. 1 - 15 Amp Automatic Leveling Control, Computer Controlled Suspension, Electronic Cluster, CD Changer, Clock Memory, Luggage Compartment Lid Pull-Down, Cellular Telephone Connector, Power Antenna, Memory Seats, Radio Memory
2. 2 - 8.25 Amp (Circuit Breaker) Interval Windshield Wiper/Washer
3. 3 - Blank
4. 4 - 10 Amp Air Bag, Automatic Leveling Control, Computer Controlled Suspension, Electronic Cluster, Warning Chime, Warning Lights, Speed Control
5. 5 - 10 Amp Heated Mirrors
6. 6 - 10 Amp Dome & Reading Lights, Power Windows, Moon Roof, Radio, Warning Chime, Brake Shift Interlock, Power Antenna, Clock, Speed Control, Electronic Door Lock Control, Anti-Theft
7. 7 - 5 Amp Instrument Panel Illumination
8. 8 - 15 Amp ATC, Back-Up Lights, Auto Lights, Running Lights (Canada), Day/Night Mirror, Manual Lever Position Sensor (1993), Keyless Entry(1993), Air Suspension/EVO Steering, Anti-Theft (1993)
9. 9 - 30 Amp ATC Blower
10. 10 - 30 Amp Cigarette Lighters
11. 11 - 20 Amp Anti-Theft, Exterior Lights, Keyless Entry (1993), Courtesy Lights, Auto Lights
12. 12 - 15 Amp Stoplights, Hazard Lights, Brake Shift Interlock, Speed Control
13. 13 - 15 Amp Electronic Engine Control (1993), Powertrain Control Module (1994), Ignition Coils
14. 14 - Blank
15. 15 - 15 Amp Anti-Theft (1993), Rear Window Defroster, Trailer Tow, Flash-To-Pass, ATC Clutch, Turn Signals
16. 16 - 20 Amp Electronic Engine Control (1993), Powertrain Control Module (1994)
17. 17 - 15 Amp Anti-Theft, ATC, Courtesy Lights, Keyless Entry (1993), Electronic Door Lock Control (1994), Power Mirrors, Power Door Locks (1993), Memory Seats, Warning Lights
18. 18 - 5 Amp Anti-Lock Brakes

FUSE PANEL IDENTIFICATION (1995-96 TOWN CAR)

The fuse panel is located in the instrument panel to the left of the steering column. To expose fuse panel, remove lower steering column finish panel.

1. 1 - 15 Amp Electronic automatic Temperature Control (EATC) Module, Backup Lamps, Turn Signal Indicators, Trailer Battery Charging Relay, Heated Seats, Shifts Lock
2. 2 - 30 Amp Wiper/Washer Controller Module, Windshield Wiper Motor
3. 3 - 5 Amps Instrument Cluster
4. 4 - 10 Amp Lighting Control Module (LCM)
5. 5 - 15 Amp Ignition Coil, PCM Power Relay
6. 6 - 10 Amp Lighting Control Module (LCM), Front Radio Control Unit, Clock, Cellular Phone, Electronic Day/Night Mirror, Compass Module
7. 7 - 15 Amp Air Bag Diagnostic Module, Air Suspension/EVO Steering Module, Stering Wheel Rotation Sensor, EATC Module, Anti-Lock Brake Module, Instrument Cluster, Daytime Running Lamps, Speed Control Amplifier, Warning Indicators, Transmission Control Switch
8. 8 - 15 Amp Keyless Entry, Power Mirrors, Trunk Lid Pull-Down, Memory Seats, Redundant Steering Control Module, CD Changer, Cellular Phone
9. 9 - 5 Amp Air Bag Diagnostic Module, Day/Night Sensor Amplifier, Lighting Control Module (LCM), Warning Indicators, Front Radio Control Unit
10. 10 - 30 Amp EATC Module
11. 11 - 5 Amp LF Seat Module, LF Door Module
12. 12 - 18 Amp (Circuit Braker) Headlamps, Lighting Control Module (LCM)
13. 13 - 10 Amp Rear Window Defrost/Heater Mirror
14. 14 - 20 Amp (Circuit Braker) Keyless Entry, Fuel Fill Door Release, LF Seat Module, Power Seats, LF Door Module
15. 15 - 15 Amp I/P Illumination, Courtesy Lamps, Daytime Running Lamps, Lighting Control Module (LCM)
16. 16 - 15 Amp Brake ON-OFF Switch, Brake Pressure Switch, Hazard Flasher, Trailer Adapter
17. 17 - 30 Amp Cigar Lighters
18. 18 - 10 Amp EATC Module, Instrument Cluster, On Board Diagnostic (OBD) Data Link Connector, Clock, Front Radio Control Unit

POWER DISTRIBUTION BOX ID (1990-94 LINCOLN TOWN CAR)

The power distribution box is located in the engine compartment near the battery.

Scheme 8

1. A - 50 Amp Lighting
2. B - 40 Amp Anti-Lock Brakes
3. C - 50 Amp Ignition Switch
4. D - 40 Amp Rear Window Defroster, Heated Mirrors
5. E - 40 Amp Ignition Switch
6. F - 30 Amp (Circuit Breaker) Power Windows
7. G - Spare
8. H - 30 Amp (Circuit Breaker) Power Seats, Door Locks, Decklid Release
9. J - 10 Amp Alternator
10. K - 10 Amp Air Bags
11. L - 15 Amp Horn
12. M - 20 Amp Daytime Running Lamps, Hazard (1990)
13. N - 20 Amp Fuel Pump
14. P - 25 Amp Ignition Switch
15. R - 25 Amp Radio
16. S - 30 Amp Anti-Lock Brakes
17. T - 30 Amp EEC/PCM
18. U - 30 Amp Air Suspension
19. V - 30 Amp Trailer Towing
20. W - 30 Amp Trailer Towing
21. X - 30 Amp Trailer Towing
22. Y - 40 Amp Heated Windshield (1990-93)

POWER DISTRIBUTION BOX ID (1995-96 TOWN CAR)

The power distribution box is located in the engine compartment near the battery.

Power Distribution Box Fuse & Circuit Breaker Identification

1. A - 50 Amp Lighting
2. B - 50 Amp Anti-Lock Brakes
3. C - 50 Amp Ignition Switch
4. D - 40 Amp Rear Window Defroster, Heated Mirrors
5. E - 40 Amp Ignition Switch
6. F - 30 Amp (Circuit Breaker) Power Windows/Moonroof
7. G - Spare
8. H - Spare
9. J - 10 Amp Generator/Voltage Regulator
10. K - 10 Amp Air Bags
11. L - 20 Amp Horn
12. M - Spare
13. N - 20 Amp Fuel Pump
14. P - 30 Amp Cooling Fan
15. R - 25 Amp Radio Amplifier
16. S - 30 Amp Heated Seat
17. T - 30 Amp Powertrain Control Module (PCM)
18. U - 30 Amp Air Suspension
19. V - 30 Amp Trailer Battery Charging
20. W - 30 Amp Trailer Brakes
21. X - 30 Amp Trailer Exterior Lamps
22. Y - Spare
