POWER MIRRORS
Power side view mirror system consists of mirror head with integral servo motor assembly and mirror control switch. Crown Victoria and Grand Marquis may be equipped with an optional electronic rear view mirror, which automatically adjusts to reduce glare during night driving.
The optional electronic rear view mirror is controlled by 2 light-sensitive photocells. Outside light level is measured by a sensor on backside of mirror housing. A second sensor, located inside the mirror, detects approaching rear lights. The mirror locks in normal position whenever transmission gear selector is placed in Reverse position.
Depressing side view mirror control switch push button, marked with arrows indicating adjustment directions, moves mirror up, down, left and right. A selector switch controls which mirror is adjusted. Selector switch should be placed in neutral position after adjustment.
Scheme 1
PINPOINT TESTS
Note. To determine correct pinpoint test, see PINPOINT TEST INDEX . The following tests and illustrations are provided courtesy of Ford Motor Co.
| Symptom | Go To Pinpoint Test |
|---|---|
| Both Side Mirrors Inoperative | A |
| Single Side Mirror Inoperative | B |
| Side Mirrors Do Not Function Properly | C |
| Electronic Inside/Outside Mirrors Inoperative | D |
| Heated Mirrors Inoperative | E |
PINPOINT TEST INDEX
| CAUTION | Unless otherwise directed, perform pinpoint tests in order listed. |
Note. In following diagnostic tests, illustrations are provided courtesy of Ford Motor Co.
PINPOINT TEST A - BOTH SIDE MIRRORS INOPERATIVE
Pinpoint Test A
- MIRROR CIRCUIT FUNCTION Mirror Function Wire Color Right Mirror Up Purple Down White Right White Left Dark Green Left Mirror Up Dark Blue Down Yellow Right Yellow Left Red
PINPOINT TEST B - SINGLE SIDE MIRROR INOPERATIVE
Pinpoint Test B
PINPOINT TEST C - SIDE MIRRORS DO NOT FUNCTION PROPERLY
Pinpoint Test C
- CIRCUIT FUNCTION TEST Pin No. (Wire Color) Circuit Function Right Mirror 1 (Red) Left/Right Motor 2 (Purple) Up/Down Motor 3 (White) (1) Mirror Solenoid Control Left Mirror 1 (Red) Left/Right Motor 2 (Dark Blue) Up/Down Motor 3 (Yellow) Mirror Solenoid Control (1) Yellow wire on some applications.
PINPOINT TEST D - ELECTRONIC INSIDE/OUTSIDE MIRROR
INOPERATIVE
Pinpoint Test D
PINPOINT TEST E - HEATED MIRRORS INOPERATIVE
Pinpoint Test E
REMOVAL & INSTALLATION
| WARNING | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. Refer to the COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
Disconnect wiring connectors at mirror and automatic dimmer (if equipped). Loosen mirror mounting set screw. Slide mirror upward and away from bracket. To install, reverse removal procedure.
Disconnect negative battery cable. Remove interior door trim panel. Remove push pin from mirror access hole cover. Remove screw under pin, and remove access hole cover. Remove wiring guides as required. Remove 3 mirror attaching nuts and mirror. To install, reverse removal procedure.
Point mirror glass as far inboard as possible to allow finger clearance at outboard edge of mirror. Insert fingers into clearance, and pull mirror glass. Glass will snap out without being damaged. Remove motor attaching screws. Disconnect motor connector, and remove motor. To install, reverse removal procedure.
Disconnect negative battery cable. Remove screw attaching switch plate to driver-side armrest. Pry up front of switch. Pry switch out of armrest. Unplug switch connector, and remove switch. To install, reverse removal procedure.
Power Mirror System Wiring Diagram. Scheme 2
