ENGINE COMPRESSION
Warm engine to normal operating temperature. Check compression at cranking speed with throttle wide open and all spark plugs removed. Ensure crankcase is at correct level and oil is of correct viscosity. With compression gauge installed, use remote starter to crank engine.
Crank engine 5 revolutions (minimum) and record highest reading. Repeat procedure for all cylinders using approximately same number of revolutions. Lowest compression reading should not be less than 75 percent of highest compression reading. Cylinder compression readings should not be less than 100 psi (7 kg/cm 2 ).
| Application | Compression Ratio |
|---|---|
| 2.0L (DOHC) | 9.6:1 |
COMPRESSION RATIO SPECIFICATIONS
VALVE CLEARANCE
For valve clearance procedures and specifications, see 2.0L 4-CYLINDER -- CONTOUR, COUGAR & MYSTIQUE .
HIGH TENSION WIRE RESISTANCE
| Application (1) | Ohms |
|---|---|
| 2.0L | 4000-7000 Per Foot |
| (1) High tension wire resistance is 30,000 ohms maximum per wire. | |
| (1) | High tension wire resistance is 30,000 ohms maximum per wire. |
HIGH TENSION WIRE RESISTANCE
SPARK PLUGS
| Application | Motorcraft No. |
|---|---|
| 2.0L [VIN 3] | AZFS-22PP Or AZFS-22FE |
SPARK PLUG TYPE
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|---|---|
| 2.0L [VIN 3] | .048-.052 (1.20-1.32) | 9-13 (13-17) |
SPARK PLUG SPECIFICATIONS
Firing Order & Timing Marks (VIN 3). Scheme 1
IGNITION TIMING
Note. Manufacturer does not recommend checking ignition timing, as faulty readings are common and timing is not adjustable.
| Application | Degrees BTDC |
|---|---|
| 2.0L | (1) 8-12 |
| (1) Timing is not adjustable. | |
| (1) | Timing is not adjustable. |
BASE IGNITION TIMING
FUEL PUMP
For fuel pressure specifications, see FUEL PRESSURE SPECIFICATIONS article.
IDLE SPEED & MIXTURE
Note. Idle mixture is not adjustable. If idle mixture is incorrect, see TESTS W/CODES - 2.0L article.
| Application | RPM |
|---|---|
| A/T | 775-825 |
| M/T | 855-905 |
| (1) Idle speed is not adjustable. Specifications are for reference purposes only. | |
| (1) | Idle speed is not adjustable. Specifications are for reference purposes only. |
IDLE RPM SPECIFICATION (1)
THROTTLE POSITION (TP) SENSOR
| Throttle Angle Degrees | (1) Volts |
|---|---|
| 0 | .65 |
| 10 | .97 |
| 20 | 1.30 |
| 30 | 1.50 |
| 45 | 2.37 |
| 53 | 2.84 |
| 60 | 3.20 |
| 70 | 3.60 |
| (1) Values may vary by 15 percent. For testing, refer to CIRCUIT TEST DH in TESTS W/CODES - 2.0L article. | |
| (1) | Values may vary by 15 percent. For testing, refer to CIRCUIT TEST DH in TESTS W/CODES - 2.0L article. |
TP SENSOR OUTPUT
