Fuse & Relay Identification
- 1 - 80 Amp (Maxi Fuse) Main Power Supply
- 2 - 60 Amp (Maxi Fuse) Engine Cooling Fan
- 3 - 60 Amp (Maxi Fuse) ABS Braking System
- 4 - 20 Amp (Yellow) Ignition, Daytime Running Lights (Canada)
- 5 - 15 Amp (Blue) Foglights
- 6 - Not Used
- 7 - 30 Amp (Green) ABS Braking System
- 8 - 30 Amp (Green) Air Pump
- 9 - 20 Amp (Yellow) EEC Module
- 10 - 20 Amp (Yellow) Ignition Switch
- 11 - 3 Amp (Violet) EEC Memory
- 12 - 15 Amp (Blue) Hazard Flashers, Horn
- 13 - 15 Amp (Blue) HEGO Sensor
- 14 - 15 Amp (Blue) Fuel Pump
- 15 - 10 Amp (Red) Right Low Beam
- 16 - 10 Amp (Red) Left Low Beam
- 17 - 10 Amp (Red) Right High Beam
- 18 - 10 Amp (Red) Left High Beam
Relay Identification
- R1 - White Relay Daytime Running Lights (Canada)
- R2 - Black Relay High Speed Engine Cooling Fan
- R3 - Blue Relay A/C Wide Open Throttle
- R4 - Yellow Relay A/C Clutch
- R5 - Dark Green Relay Engine Cooling Fan
- R6 - Yellow Relay Starter
- R7 - Brown Relay Horn
- R8 - Brown Relay Fuel Pump
- R9 - White Relay Low Beam
- R10 - White Relay High Beam
- R11 - Brown Relay PCM Module
- D1 - Black Relay Reverse Voltage Protection
Scheme 1
Scheme 1: INSTRUMENT PANEL FUSE IDENTIFICATION
Fuse & Circuit Breaker Identification
- 19 - 7.5 Amp (Brown) Heated Rearview Mirrors
- 20 - 10 Amp (Circuit Breaker) Wipers
- 21 - 40 Amp (Amber) Power Windows
- 22 - 7.5 Amp (Brown) ABS Module
- 23 - 15 Amp (Blue) Backup Lamps
- 24 - 15 Amp (Blue) Brake Lamps
- 25 - 20 Amp (Yellow) Door Locks
- 26 - 7.5 Amp (Brown) Main Lights
- 27 - 15 Amp (Blue) Cigarette Lighter
- 28 - 30 Amp (Green) Power Seats
- 29 - 30 Amp (Green) Rear Window Defroster
- 30 - 7.5 Amp (Brown) Engine Management System (EMS)
- 31 - 7.5 Amp (Brown) Instrument Panel Illumination
- 32 - 7.5 Amp (Brown) Radio
- 33 - 7.5 Amp (Brown) Left-Hand Parking Lamps
- 34 - 7.5 Amp (Brown) Courtesy Lamps
- 35 - 7.5 Amp (Brown) Right-Hand Parking Lamps
- 36 - 10 Amp (Red) Air Bag
- 37 - 30 Amp (Green) Blower Motor
- 38 - Not Used
- R12 - White Relay Courtesy Lamps
- R13 - Yellow Relay Rear Window Defroster
- R14 - Yellow Relay Heater Fan Motor
- R15 - Green Relay Wipers
- R16 - Black Relay Ignition
- D2 - Black Relay Reverse Voltage Protection
- R17 - Not Used
- R18 - Black Relay Express Down Windows
- R19 - Blue Relay Speed Control Cut-Out
- R20 - Not Used
- R21 - Not Used
- R22 - White Relay Fog Lamps
- R23 - Black Relay Turn Signal
- R24 - White Relay Left Panic Alarm Flasher
- R25 - White Relay Right Panic Alarm Flasher
- R26 - Not Used
- R27 - Not Used
- R28 - Not Used
- R29 - Brown Relay Door Lock Control
