MIRROR CONTROL SWITCH
Remove mirror control switch. Measure resistance between specified terminals while operating switch in appropriate direction. See MIRROR SWITCH TEST table. (Scheme 4) Resistance in all tests should be less than 5 ohms. If switch fails any portion of test, replace switch.
| Switch Position | Continuity Between Terminals No. | |
|---|---|---|
| Driver Mirror | ||
| Up | 3 & 8; 5 & 6 | |
| Down | 3 & 6; 5 & 8 | |
| Left | 2 & 3; 5 & 6 | |
| Right | 3 & 6; 2 & 5 | |
| Passenger Mirror | ||
| Up | 3 & 7; 5 & 6 | |
| Down | 3 & 6; 5 & 7 | |
| Left | 3 & 4; 5 & 6 | |
| Right | 3 & 6; 4 & 5 | |
MIRROR SWITCH TEST
