FUSE PANEL LOCATION
Fuse panel is located under the instrument panel to the left of the steering column. Refer to appropriate illustration to identify fuses and circuit breakers.
Scheme 2
Fuse & Circuit Breaker Identification
1 - 15 Amp
Horn, Taillights, Marker Lights, License & Park Lights
Instrument Panel Illumination
2 - 3 Amp
Instrument Panel Lights, Cluster Lights, Ashtray Light
Transmission Indicator Light, Radio & Heater Light, A/C
Light, Headlight Switch Illumination, Wiper Switch
Illumination
3 - 15 Amp
Throttle Solenoid
4 - 7.5 Amp
Auxiliary Fuel Tank Solenoid
5 - 7.5 Amp (Circuit Breaker)
Wiper Switch, Seat Belt Warning
6 - 35 Amp
Heater &/Or A/C
7 - 15 Amp
Emergency Warning Flashers, Stoplight, Horn, Speed Control
8 - 20 Amp
Dome & Cargo Lights, Courtesy Lights, Cigarette Lighter
Clock, 4.9L Fan Relay
9 - 20 Amp
Accessory Feed, Speed Control, Trailer Tow, Power Windows
10 - 15 Amp
Turn Signals, Windshield Washer, Back-Up Lights
11 - 7.5 Amp
Radio, Premium Sound
FUEL PUMP SHUT-OFF SWITCH
This switch stops flow of fuel to engine after a collision. The impact does not have to be great to trigger the switch. To reset, press White reset button on switch located on floorboard, to left and above where steering column passes through the floorboard.
FUEL CONDITIONER (DIESEL ENGINES)
Allowing water to remain in fuel conditioner could result in extensive damage to or failure of fuel injection system. Diesel fuel can damage asphalt and other surfaces. Always place a drain pan under fuel conditioner to collect fuel, and dispose of fuel properly.
ANTI-LOCK BRAKE SYSTEM
On models with anti-lock brake systems, ALWAYS observe the following cautions
- DO NOT attempt to bleed or add hydraulic fluid to system without first referring to appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES section.
- Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in ABS-equipped vehicles.
- DO NOT mix tire sizes. As long as tires remain close to original diameter, increasing width is acceptable. Rolling diameter must be identical on all 4 tires.
