Overview
The windshield wiper/washer system is activated by the wiper/washer switch. The following functions/features of the windshield wiper/washer system are
- Windshield wash
- Courtesy wipe
- Windshield wipers (low/high speed)
- Intermittent wipers
- Speed dependent wipers
- Wiper activated exterior lamps
- Rain sensitive wipers (if equipped)
- Rear window wipe
- Rear window wash
- Reverse gear wipe
There are 6 intermittent/sensitivity settings to choose from for the intermittent/rain sensitive wipers.
There are 2 settings to choose from for the rear window wiper operation.
Scheme 1
Normal Operation and Fault Conditions
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1095:12 | Wiper On/Off Relay: Circuit Short To Battery | Sets when the BCM detects a short to battery from the windshield wiper on/off relay coil controlled circuit. |
| B1095:13 | Wiper On/Off Relay: Circuit Open | Sets when the BCM detects an open from the windshield wiper on/off relay coil controlled circuit. |
| B1095:14 | Wiper On/Off Relay: Circuit Short To Ground or Open | Sets when the BCM detects an open from the windshield wiper on/off relay coil controlled circuit. |
| B1095:19 | Wiper On/Off Relay: Circuit Current Above Threshold | Sets when the BCM detects excessive current draw (short to voltage for example) from the windshield wiper on/off relay coil controlled circuit. |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B112B:87 | Steering Wheel Module: Missing Message | Sets when the BCM loses communication with the SASM over the LIN . |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1096:11 | Wiper High/Low Relay: Circuit Short To Ground | Sets when the BCM detects a short to ground from the windshield wiper low/high speed relay coil controlled circuit. |
| B1096:14 | Wiper High/Low Relay: Circuit Short To Ground or Open | Sets when the BCM detects a short to ground from the windshield wiper low/high speed relay coil controlled circuit. |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1096:12 | Wiper High/Low Relay: Circuit Short To Battery | Sets when the BCM detects a short to voltage from the windshield wiper low/high speed relay coil controlled circuit. |
| B1096:13 | Wiper High/Low Relay: Circuit Open | Sets when the BCM detects an open from the windshield wiper low/high speed relay coil controlled circuit. |
| B1096:14 | Wiper High/Low Relay: Circuit Short To Ground or Open | Sets when the BCM detects an open from the windshield wiper low/high speed relay coil controlled circuit. |
| B1096:19 | Wiper High/Low Relay: Circuit Current Above Threshold | Sets when the BCM detects excessive current draw (short to voltage for example) from the windshield wiper low/high speed relay coil controlled circuit. |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1095:11 | Wiper On/Off Relay: Circuit Short To Ground | Sets when the BCM detects a short to ground from the windshield wiper on/off relay coil controlled circuit. |
| B1095:14 | Wiper On/Off Relay: Circuit Short To Ground or Open | Sets when the BCM detects a short to ground from the windshield wiper on/off relay coil controlled circuit. |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B10AD:83 | Rain Sensor: Value of Signal Protection Calculation Incorrect | Sets when the BCM receives corrupt data from the rain sensor. |
| U0231:00 | Lost Communication With Rain Sensing Module: No Sub Type Information | Sets when the BCM determines a communication error has occurred on the LIN . This may be caused by an open in the rain sensor power or ground circuit or an open in the LIN circuit between the rain sensor and the BCM . |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1C45:13 | Front Wiper Park Position Switch: Circuit Open | Sets when the BCM detects an open from the windshield wiper motor park position switch input circuit. |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1C77:12 | Rear Wiper Relay: Circuit Short To Battery | Sets when the BCM detects excessive current draw from the rear window wiper motor relay control circuit. |
| B1C77:13 | Rear Wiper Relay: Circuit Open | Sets when the BCM detects an open from the rear window wiper motor relay control circuit. |
| B1C77:14 | Rear Wiper Relay: Circuit Short to Ground Or Open | Sets when the BCM detects an open from the rear window wiper motor relay control circuit. |
| B1C77:19 | Rear Wiper Relay: Circuit Current Above Threshold | Sets when the BCM detects excessive current draw (short to voltage for example) from the rear window wiper motor relay control circuit. |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| DTC | Description | Fault Trigger Conditions |
| B1C77:11 | Rear Wiper Relay: Circuit Short To Ground | Sets when the BCM detects a short to ground from the rear window wiper relay coil controlled circuit. |
| B1C77:14 | Rear Wiper Relay: Circuit Short To Ground or Open | Sets when the BCM detects a short to ground from the rear window wiper relay coil controlled circuit. |
BCM DTC FAULT TRIGGER CONDITIONS
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
REFER to: WIPERS AND WASHERS - SYSTEM OPERATION AND COMPONENT DESCRIPTION .
