Electronic Engine Controls - 2.0L: Other Ford C-MAX II

Electronic Engine Controls - Hybrid Electric Vehicle (HEV)

Diagnostics in this article assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Electronic Engine Controls - Plug-In Hybrid Electric Vehicle (PHEV)

Diagnostics in this article assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Camshaft Position (CMP) Sensor

MATERIALS SPECIFICATION

Scheme 17

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000) .
2. Refer to: «AIR CLEANER»(ref-635250-S37976058432014070200000) .
3. Visual check.

Scheme 18

1. Apply the specified lubricant to the specified component. Material : Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (U.S.)/XO-5W20-QSP (U.S.) (WSS-M2C945-A) Torque : 71 lb.in (8 Nm)
2. Refer to: «AIR CLEANER»(ref-635250-S37976058432014070200000) .

Catalyst Monitor Sensor

SPECIAL TOOL DESCRIPTION 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M

Scheme 19

MATERIALS SPECIFICATION

Scheme 20

Scheme 21

1. WARNING: Before beginning any service procedure in this article, refer to Safety Warnings in «GENERAL INFORMATION»(ref-635189) . Failure to follow this instruction may result in serious personal injury. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000) .
2. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
3. Apply the specified chemical with a spray can. Use Special Service Tool: 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor . Material : Penetrating and Lock Lubricant/XL-1

Scheme 22

1. Apply the specified lubricant to the specified component. Material : High Temperature Nickel Anti-Seize Lubricant/XL-2 Use Special Service Tool: 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor . Calculate the correct torque wrench setting for the following torque. Refer to the chart below. Torque : 35 lb.ft (48 Nm)

Crankshaft Position (CKP) Sensor

SPECIAL TOOL DESCRIPTION 303-1521 Alignment Tool, Crankshaft Position Sensor 303-507 Timing Peg, Crankshaft TDC TKIT-2001N-FLM

Scheme 23

Scheme 24

Engine Coolant Temperature (ECT) Sensor - Hybrid Electric Vehicle (HEV)

Special Tool(s)/General Equipment

Hose Clamp(s)

MATERIALS SPECIFICATION

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Refer to: «AIR CLEANER»(ref-635250-S37976058432014070200000) .
2. Use the General Equipment: Hose Clamp(s)
3. NOTE: Have new component ready to install to minimize coolant loss. NOTE: Be prepared to capture escaping fluid with a shop towel.

Heated Oxygen Sensor (HO2S)

SPECIAL TOOL DESCRIPTION 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M

MATERIALS SPECIFICATION

Scheme 29

Scheme 30

1. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
2. Refer to: «AIR CLEANER»(ref-635250-S37976058432014070200000) .
3. Apply the specified chemical with a spray can. Use Special Service Tool: 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor . Material : Penetrating and Lock Lubricant/XL-1

Scheme 31

1. Apply the specified lubricant to the specified component. Material : High Temperature Nickel Anti-Seize Lubricant/XL-2 Use Special Service Tool: 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor . Calculate the correct torque wrench setting for the following torque. Refer to the chart below. Torque : 35 lb.ft (48 Nm)
2. Refer to: «AIR CLEANER»(ref-635250-S37976058432014070200000) .

Powertrain Control Module (PCM)

Special Tool(s)/General Equipment

Ford Diagnostic Equipment
