Information System and Entertainment System - Am/fm/cd/sync: Specifications Ford C-MAX II

Entertainment Systems 1 illustration

SPECIFICATIONS

ItemNm
ACM bolts2
Antenna bolt6
APIM bolts2.8
DACMC bolts2.5
FCDIM bolts1.5
FCIM screws1.5
Front door speaker bolts2
Glove box screws2
GPSM bolt2
Rear door speaker bolts2
Upper B-pillar bolt2

Scheme 1

Scheme 1: Information and Entertainment System - Component Location
Scheme 1: Information and Entertainment System - Component Location
ItemDescription
1Driver side instrument panel speaker (passenger side similar)
2GPSM , located behind the IPC
3FCDIM
4DACMC
5SYNC® microphone (located in the overhead console)
6Noise cancellation microphones (located in headliner)
7Antenna
8Antenna cable
9Audio input socket and USB port
10USB cable
11Rear door speaker
12APIM
13FCIM
14Front door speaker
15ACM
16RH upper and lower steering wheel controls
