Preliminary Checks
Confirm concern, operate all switches. Ensure battery is fully charged. Ensure windows are properly aligned. Check the following for possible cause of malfunction
- Faulty fuses or circuit breaker.
- Open or shorted supply circuit.
- Loose or corroded connectors.
- Poor ground connections.
- Faulty Master Switch. See WINDOW SWITCHES under TESTING.
Confirm concern. Ensure battery is fully charged. Ensure window in question is properly aligned. Check the following for possible cause of malfunction
- Damaged track or regulator mechanism.
- Malfunctioning window regulator and motor. See WINDOW REGULATOR & MOTOR under TESTING.
- Open or shorted circuit.
Confirm concern. Ensure battery is fully charged. Check the following for possible cause of malfunction
- Malfunctioning switch. See WINDOW SWITCHES under TESTING.
- Open or shorted circuit. Check circuits between master switch and single switch.
Master Window Switch With Door Lock
Testing information is not available from manufacturer. See illustration for master window switch with door lock terminal locations. (Scheme 4)
Scheme 4
| Pin. No. | Circuit Function |
|---|---|
| 1 | Ground |
| 2 | Left Window Motor Feed/Return |
| 3 | Lock Motors Feed/Return |
| 4 | Ground |
| 5 | Power |
| 6 | Left Window Motor Feed/Return |
| 7 | Ground |
| 8 | Power |
| 9 | Ground |
| 10 | Right Window Motor Feed/Return |
| 11 | Ground |
| 12 | Lock Motors Feed/Return |
| 13 | Power |
| 14 | Right Window Motor Feed/Return |
| 15 | Ground |
MASTER WINDOW SWITCH WITH DOOR LOCK TERMINALS
Master Window Switch With Door Lock & Keyless Entry
Testing information is not available from manufacturer. See illustration for master window switch with door lock and keyless entry terminal locations. (Scheme 5)
Scheme 5
| Pin. No. | Circuit Function |
|---|---|
| 1 | Ground |
| 2 | Left Window Switch & Motor |
| 3 | Lock Motors Feed/Return |
| 4 | Not Used |
| 5 | Safety Relay Load |
| 6 | Left Window Switch & Motor |
| 7 | Ground |
| 8 | Ground |
| 9 | Ground |
| 10 | Right Window Switch & Motor |
| 11 | Not Used |
| 12 | Lock Switch (Unlock) |
| 13 | Power |
| 14 | Left Window Switch To Right Window Motor |
| 15 | Ground |
MASTER WINDOW SWITCH WITH DOOR LOCK & KEYLESS ENTRY TERMINALS
Right Window Switch With Door Lock
Testing information is not available from manufacturer. See illustration for master window switch with door lock terminal locations. (Scheme 6)
Scheme 6
| Pin. No. | Circuit Function |
|---|---|
| 1 | Lock Motors Feed/Return |
| 2 | Feed/Return From Left Switch |
| 3 | Feed/Return From Left Switch |
| 4 | Right Window Motor Feed/Return |
| 5 | Power |
| 6 | Power |
| 7 | Feed/Power From Left Switch |
| 8 | Lock Motors Feed/Return |
| 9 | Right Window Motor Feed/Return |
| 10 | Feed/Return From Left Switch |
RIGHT WINDOW SWITCH WITH DOOR LOCK TERMINALS
Right Window Switch With Door Lock & Keyless Entry
Testing information is not available from manufacturer. See illustration for master window switch with door lock and keyless entry terminal locations. (Scheme 7)
Scheme 7
| Pin. No. | Circuit Function |
|---|---|
| 1 | Lock Switch (Unlock) |
| 2 | Not Used |
| 3 | Right Window Down Input |
| 4 | Right Window Down Output |
| 5 | Ground |
| 6 | Safety Relay Load |
| 7 | Not Used |
| 8 | Lock Switch (Lock) |
| 9 | Right Window Up Output |
| 10 | Right Window Up Input |
RIGHT WINDOW SWITCH WITH DOOR LOCK & KEYLESS ENTRY TERMINALS
Right Window Switch Without Door Lock & Keyless Entry
- Remove window switch from vehicle. See WINDOW SWITCH under REMOVAL & INSTALLATION. Position raised portion of window switch knob with face right exposing 5 terminals. Use a self-powered test light or ohmmeter to test window switch.
- With window switch in neutral position, there should be continuity between terminals No. 1 and 2, and terminals No. 3 and 4. (Scheme 8) Terminal No. 5 should be disconnected from all other terminals.
- When raised portion of window switch rocker knob is pushed, closing windows, there should be continuity between terminals No. 1 and 5, and terminals No. 3 and 4. Terminal No. 2 should be disconnected from all other terminals.
- When depressed portion of window switch rocker knob is pushed, opening windows, there should be continuity between terminals No. 1 and 2, and terminals No. 4 and 5. Terminal No. 3 should be disconnected from all other terminals. If window switch does not test correctly, replace window switch.
Scheme 8
Tailgate Window Switch
- Remove window switch from vehicle. See WINDOW SWITCH under REMOVAL & INSTALLATION. Use a self-powered test light or ohmmeter to test window switch. With switch in neutral position, there should be continuity between terminals No. 1, 2, and 3. (Scheme 9)
- With rear window glass up position, there should be continuity between terminals No. 1 and 5, and No. 2 and 4. With rear window glass in down position, there should be continuity between terminals No. 2 and 5, and No. 3 and 4. If window switch does operate as specified, replace tailgate mounted window switch.
Scheme 9
Regulator & Motor
- Remove door trim panel. See WINDOW REGULATOR & MOTOR under REMOVAL & INSTALLATION. Disconnect motor connector. Disconnect window regulator from motor.
- Supply power to motor connector with an ammeter in series. Current drew for no-load test should not exceed 4 amps, and should not fluctuate. Reversal of motor wire connections will reverse direction of motor rotation.
- Operate motor and observe current draw. Replace motor if current draw exceeds 4 amps. If window switch does not test correctly, replace window switch.
