STARTER MOTOR SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Brush Length | ||
| Minimum | 0.45" (11.5 mm) | |
| New | 0.67" (17 mm) | |
| Brush Spring Force | 2.2-4.3 Lbs. (1-2 kg) | |
| Commutator | ||
| Runout | 0.002" (0.05 mm) | |
| Minimum Diameter | 1.22" (31.0 mm) | |
| Segment Depth | 0.02-0.03" (0.5-0.8 mm) | |
| Pinion Gap | 0.02-0.08" (0.5-2.0 mm) | |
STARTER MOTOR SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Starter Motor Mounting Bolts | 23-34 (31-46) |
| INCH Lbs. (N.m) | |
| Solenoid Retaining Screws | 36-66 (4.1-7.5) |
| Terminal Nuts | 71-106 (8-12) |
| Through-Bolts | 53-71 (6-8) |
TORQUE SPECIFICATIONS
