Interior Fuse & Circuit Breaker Identification
- 1 - 10 Amp ENGINE Blower Motor Relay, Anti-Lock Brake System Relay, ABS System, Ignition Main Relay, Cooling Fan, Air Bag
- 2 - 15 Amp METER Instrument Cluster Waning Indicators, Heated Rear Window Relay, Central Processing Unit Module, Backup Lights, Instrument Cluster, Turn Signal Lights
- 3 - 20 Amp DEFOG Heated Rear Window
- 4 - 20 Amp Spare Fuse
- 5 - 15 Amp Spare Fuse
- 6 - Blank
- 7 - 15 Amp F.FOG Fog Lights
- 8 - Blank
- 9 - Blank
- 10 - 20 Amp WIPER Front Wiper/Washer System, A/C Switch, A/C Relay, A/C Condenser Fan Relay
- 11 - 15 Amp R. WIPER Rear Wiper/Washer, Blower Motor, Daytime Running Lights (DRL) Relay
- 12 - 30 Amp BLOWER (Circuit Breaker) Climate Control Blower Motor
- 13 - 15 Amp HAZARD Hazard Warning Flashers
- 14 - 15 Amp STOP Luggage Compartment Light, Horn, Stoplights, ABS Control Module, Horn Relay
- 15 - 15 Amp TAIL Illumination, Turn Signal, Parking, Front Side Marker, License & Tail Lights
- 16 - 15 Amp CIGAR Cigarette Lighter, Audio
- 17 - Blank
- 18 - Blank
- 19 - 10 Amp ROOM CPU Module, Powertrain Control Module (PCM), Interior Lights, Radio Chassis, Backup Lights
UNDERHOOD FUSE PANEL IDENTIFICATION
The "high-current fuse panel is located in the engine compartment next to the battery.
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
Scheme 1
Underhood Fuse Identification
- 1 - 30 Amp Cooling Fan Electric Cooling Fan, A/C Condenser Cooling Fan, A/C Magnetic Clutch
- 2 - 60 Amp ABS Anti-Lock Brake System
- 3 - 80 Amp Main Hydraulic Anti-Lock Actuator Assembly, Powertrain Control Module (PCM), Anti-Lock Brake (ABS) Control Module, ABS Relay, Ignition Coil, Ignition Main Relay, Blower Motor Relay, Central Processing Unit (CPU), Instrument Panel Warning Indicators, Horn, Audio System, Heated Rear Window Switch/Relay, Air Bag Diagnostic Monitor, Rear Wiper/Washer, DRL Control Rely (Canada), Interior & Exterior Lights
- 4 - 30 Amp EGI INJ Multi-Port Fuel Injection (MFI) System, Air Bag Diagnostic Module
- 5 - 30 Amp Head Headlamps
