FUSE & CIRCUIT BREAKER IDENTIFICATION - 1986-94

  1. 1 - 15 Amp - Brakelights, Speed Control (1992-94), Emergency Flasher, Brake Shift Interlock (1992-94), Indicator Lights (1992-94)
  2. 2 - 6 Amp (Circuit Breaker) - Front Wiper/Washer
  3. 3 - 15 Amp - Stoplights, Parking Lights, Side Marker & License Lights, Trailer Lights Relay (1986-90)
  4. 4 - 15 Amp - Turn, Visor & Back-Up Lights, Trailer Tow Turn Signal Relay, Illuminated Entry, Day/Night Mirror
  5. 5 - 20 Amp - Speed Control, Rear Washer/Wiper/Defrost, Washer Fluid Sensor, Warning Chime, Clock (1986)
  6. 6 - Blank (1986-89) 20 Amp (1990-91) - Antilock Brakes
  7. 7 - 15 Amp - Headlights On Indicator, Courtesy Lights, Clock, Visor Vanity, Dome Lights, Glove Box Lights, Cargo Lights, Footwell & Reading Lights, Trip Computer, Radio Memory, Electronic Instrument Cluster, Illuminated Entry
  8. 8 - 30 Amp - Heater & A/C Blower Motor, A/C Clutch
  9. 9 - 20 Amp (Yellow) - Flash-To-Pass Light Function
  10. 10 - 15 Amp - Radio/Tape Player, Amplifier, Graphic Equalizer (If Equipped)
  11. 11 - 20 Amp (Yellow) - Rear Cigarette Lighter, Power Lumbar
  12. 12 - 5 Amp - Instrument & Control Illumination, Floor Shift Illumination
  13. 13 - 20 Amp (Circuit Breaker) - Power Windows
  14. 14 - Blank (1986-89) 15 Amp (1990-91) - Electronic All-Wheel Drive
  15. 15 - 20 Amp - Horn, Front Cigar Lighter (1992), Front/Rear Cigar Lighter (1993-94)
  16. 16 - 10 Amp - Instrument Cluster, Electronic Cluster Day Lights, Speedometer, PSOM (1992-94)
  17. 17 - 10 Amp (Red) - Seat Belt Buzzer, Low Fuel Warning, Door Ajar & Warning Lights, Carburetor Circuits (If Equipped), Warning Chime, Indicator Lights

UNDERHOOD FUSE & PANEL IDENTIFICATION (1993-94)

The fuse/relay panel is located in the engine compartment on left rear side of inner fender panel.

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Scheme 3

Scheme 3
Scheme 3

FUSE & CIRCUIT BREAKER IDENTIFICATION

  1. 1 - 60 Amp - Ignition
  2. 2 - 40 Amp - Fuse Panel
  3. 3 - 60 Amp - Fuse Panel
  4. 4 - 30 Amp - Electronic Engine Control Power
  5. 5 - Blank
  6. 6 - 20 Amp - Power Door Locks
  7. 7 - 20 Amp - All-Wheel Drive Module
  8. 8 - Blank
  9. 9 - Blank
  10. 10 - Blank
  11. 11 - Blank
  12. 12 - Blank
  13. 13 - Blank
  14. 14 - Diode - Electronic Engine Control System
  15. 15 - 20 Amp - Fog LIghts
  16. 16 - 15 Amp - Alternator
  17. 17 - 15 Amp - Hood Light/Daytime Running Lights
  18. 18 - 20 Amp - Fuel Pump
  19. 19 - Blank
  20. 20 - Blank
  21. 21 - Blank
  22. 22 - Blank

Scheme 4

Scheme 4
Scheme 4

FUSE & CIRCUIT BREAKER IDENTIFICATION - 1995-96

  1. 1 - 15 Amp - Brake Shift Interlock, Hazard Flashers, Indicator Lights, Speed Control, Stop Lamps
  2. 2 - 6 Amp (Circuit Breaker) - Windshield Wiper/Washer
  3. 3 - Not Used
  4. 4 - 15 Amp - Daytime Running Lamps, Headlamp ON Warning Chime, Instrument Panel Illumination, License Lamps, Parking Lamps, Rear Anti-Lock Brakes (1996), Side Marker Lamps, Underhood Lamp
  5. 5 - 15 Amp - Air Bag Module, Back Up Lamps, Brake Shift Interlock, Daytime Running Lamps Module, Rear Defroster Switch, Turn Signal Flasher, Turn Signal Indicator, Heated Exhaust Gas Oxygen Sensor (1995)
  6. 6 - 20 Amp - Speed Control Amplifier, Warning Chime Module (1995), A/C Clutch, Door Ajar Relay, Air Conditioning Clutch, Autolamp Relay (1995)
  7. 7 - 20 Amp - Rear Anti-Lock Brake System (RABS) Module
  8. 8 - 15 Amp - Cargo Lamp, Courtesy Lamp, Dome Lamp, Glove Box Lamp, Illuminated Entry, Instrument Panel Courtesy Lamps, Power Mirrors, Programmable Speedometer/Odometer Module (PSOM), Radio, Reading Lamps, Stepwell Lamps, Visor Vanity Lamps, Clock (1995), Electronic Instrument Cluster (1995)
  9. 9 - 30 Amp - Auxiliary Air Conditioning Relay, Blower Motor, Front Air Conditioning
  10. 10 - 15 Amp - Air Bag Module
  11. 11 - 15 Amp - Premium Sound Amp, Radio, Graphic Equilizer (1995)
  12. 12 - 30 Amp - Flash-To-Pass, High Beam Indicator, Horn, Power Lumbar
  13. 13 - 5 Amp - Instrument & Control Illumination
  14. 14 - 20 Amp - Power Window Motors
  15. 15 - 15 Amp (Blue) - All Wheel Drive & Indicator
  16. 16 - 20 Amp - Front Cigar Lighter, Rear Cigar Lighter
  17. 17 - 10 Amp - Programmable Speedometer/Odometer Module (PSOM), Electronic Ignition Control
  18. 18 - 15 Amp (Blue) - Indicator Lamps, Instrument Cluster Gauges (1996), Low Oil Relay (1996), Transmission Control Switch (1996), Warning Chime
