Maintenance Information: Overview Eagle Vision I

Procedures 2 illustrations ~796 words

MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see SCHEDULED SERVICES article in this section. Warranty information and specifications for fluid capacities, lubrication specifications, wheel and tire size, and battery type are covered in this article.

FUSE PANEL IDENTIFICATION

The fuse block is behind the end cover at the left side of the instrument panel. Pull the cover straight away from the instrument panel for access to fuses. A Power Distribution center, for circuits that operate only under the hood, is located in the engine compartment. An identification label is located on the underside of the cover.

Scheme 1

Scheme 1: FUSE PANEL IDENTIFICATION
Scheme 1: FUSE PANEL IDENTIFICATION

Fuse & Circuit Breaker Identification

  1. 1 - 5 Amp (Tan)- Power Mirrors
  2. 2 - 10 Amp (Red)- Radio
  3. 3 - 10 Amp (Red)- Right & Left Turn Signals
  4. 4 - 20 Amp (Yellow)- Stoplights
  5. 5 - 5 Amp (Tan)- Headlight Delay Sense
  6. 6 - 10 Amp (Red)- Climate Control, Rear Window Defrost, Back-Up Lights, ABS Module, Daytime Running Lights (Canada)
  7. 7 - 10 Amp (Red)- Air Bag Module
  8. 8 - 20 Amp (Yellow)- Horns, Horn Relay, Cigarette Lighter, Radio Amplifier
  9. 9 - 15 Amp (Light Blue)- Tail Lights, License & Parking Lights, Illumination Lights, Radio
  10. 10 - 10 Amp (Red)- Wiper Motor Relay, Washer Motor
  11. 11 - 15 Amp (Light Blue)- Left High Beam Headlight
  12. 12 - 15 Amp (Light Blue)- Right High Beam Headlight, High Beam Indicator
  13. 13 - 10 Amp (Red)- Body Controller, Door Lock Switches, Instrument Panel Connector, Radio Memory, Power Mirrors, Trunk Release, Remote Keyless Entry, Message Center, ATC Aspirator Motor, Lights: Rear Reading Lamps, Map, Glove Box, Key-In, Vanity Mirror, Underhood, Trunk, Door & Front Courtesy
  14. 14 - 5 Amp (Tan)- Body Controller, Message Center, Speed Control Relay, Power Window Switch, Door Lock Switch Light, Power Mirrors, Overhead Console, Remote Keyless Entry
  15. 15 - 15 Amp (Light Blue)- Left Low Beam
  16. 16 - 15 Amp (Light Blue)- Right Low Beam, Fog Lights
  17. 17 - 5 Amp (Tan)- Auto Trans Controller, Body Controller, Gear Selector Indicator
  18. 18 - 10 Amp (Red)- Engine Controller, Fuel Pump Relay, ASD Relay
  19. 19 - 10 Amp (Red)- Air Bag Module
  20. 20 - 10 Amp (Red)- Oxygen Sensor, Fan Relay, Purge Solenoid, EGR Solenoid, A/C Relay, Fan Relays
  21. 21 - 25 Amp (Clear)- Blower Motor
  22. 22 - 20 Amp (Yellow)- Power Window Motors, Power Window Switch Lights
  23. 23 - 20 Amp (Circuit Breaker) - Power Door Lock Motors, Power Seats, Power Antenna
  24. A - Horn Relay
  25. B - Door Lock Relay
  26. C - Door Unlock Relay
  27. D - Vehicle Speed Control Relay
  28. E - Head Lamp Delay Relay

Scheme 2

Scheme 2
Scheme 2
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Fuse Identification

  1. 1 - 40 Amp (Green)- Anti-Lock Brake Pump
  2. 2 - 40 Amp (Green)- Ignition Switch, Fuse Block
  3. 3 - 30 Amp (Pink)- ABS Controller, ABS Main Relay
  4. 4 - 20 Amp (Yellow)- Fuse Block
  5. 5 - 20 Amp (Yellow)- Fuse Block
  6. 6 - 20 Amp (Yellow)- Transmission Control System Shutdown Relay, Automatic Shutdown Relay, Transmission Control Module, Powertrain Control Module
  7. 7 - 20 Amp (Yellow)- Starter Relay, Ignition Switch, Fuel Pump Relay
  8. 8 - 30 Amp (Pink)- Intermittent Wiper Relay
  9. 9 - 40 Amp (Green)- High Speed Radiator Fan Relay, Low Speed Radiator Fan Relay A/C Compressor Clutch Relay
  10. 10 - 30 Amp (Pink)- Daytime Running Lights Module, Headlights
  11. 11 - 20 Amp (Yellow)- Turn Signals, Combination Flasher
  12. 12 - 10 Amp (Red)- Daytime Running Light Module
  13. 13 - Not Used
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. 1 - 20 Amp (Yellow)- Fuse Block
  2. 2 - 20 Amp (Yellow)- Fuse Block
  3. 3 - 30 Amp (Pink)- Daytime Running Lights Module, Headlights
  4. 4 - 30 Amp (Pink)- ABS Main Relay
  5. 5 - 40 Amp (Green)- Ignition Switch, Fuse Block
  6. 6 - 20 Amp (Yellow)- Starter Relay, Ignition Switch, Fuel Pump Relay
  7. 7 - 20 Amp (Yellow)- Transmission Control System Shutdown Relay, Automatic Shutdown Relay, Transmission Control Module, Powertrain Control Module
  8. 8 - 40 Amp (Green)- ABS Pump Motor Relay
  9. 9 - 20 Amp (1994) (Yellow)- High Speed Radiator Fan Relay, Low Speed Radiator Fan Relay A/C Compressor Clutch Relay 40 Amp (1995-96) (Green)- High Speed Radiator Fan Relay, Low Speed Radiator Fan Relay A/C Compressor Clutch Relay
  10. 10 - 30 Amp (Pink)- Intermittent Wiper Relay, Wiper Motor Relay, Washer Motor
  11. 11 - 20 Amp (Yellow)- Turn Signals, Combination Flasher
  12. 12 - 10 Amp (Red)- Daytime Running Light Module
  13. 13 - Not Used

Relay Identification

  1. A - Radiator Fan (High Speed) Relay
  2. B - Radiator Fan (Low Speed) Relay
  3. C - A/C Compressor Clutch Relay
  4. D - Auto Shutdown Relay
  5. E - Fuel Pump Relay
  6. F - Intermittent Wiper Relay
  7. G - Automatic Transmission Relay
  8. H - Starter Relay
  9. I - Not Used
  10. J - High/Low Wiper Relay
  11. K - ABS Main Relay
  12. L - ABS Pump Relay
