Starter: Specifications Eagle Talon II

Starter 6 illustrations

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
DOHC
Air Injection Valve25 (34)
Starter Mounting Bolts40 (54)
SOHC (Non-Turbo)
Front Exhaust Pipe36 (49)
Starter Mounting Bolts20-25 (27-34)
SOHC (Turbo)
Starter Mounting Bolts22 (30)

TORQUE SPECIFICATIONS

Fig. 10: Starter System Wiring Diagram (2.0L Non-Turbo A/T With Anti-Theft)
Scheme 10: Starter System Wiring Diagram (2.0L Non-Turbo A/T With Anti-Theft)
Fig. 11: Starter System Wiring Diagram (2.0L Non-Turbo M/T With Anti-Theft)
Scheme 11: Starter System Wiring Diagram (2.0L Non-Turbo M/T With Anti-Theft)
Fig. 12: Starter System Wiring Diagram (2.0L Non-Turbo Without Anti-Theft)
Scheme 12: Starter System Wiring Diagram (2.0L Non-Turbo Without Anti-Theft)
Fig. 13: Starter System Wiring Diagram (2.0L Turbo A/T With Anti-Theft)
Scheme 13: Starter System Wiring Diagram (2.0L Turbo A/T With Anti-Theft)
Fig. 14: Starter System Wiring Diagram (2.0L Turbo M/T With Anti-Theft)
Scheme 14: Starter System Wiring Diagram (2.0L Turbo M/T With Anti-Theft)
Fig. 15: Starter System Wiring Diagram (2.0L Turbo Without Anti-Theft)
Scheme 15: Starter System Wiring Diagram (2.0L Turbo Without Anti-Theft)
