FUSE PANEL IDENTIFICATION (1989 MODELS)
Fuse panel is located under instrument panel on driver's side of vehicle. Fusible link wires are used to protect a number of circuits. These links will melt in the event of excessive current flow. Replace after determining cause.
Scheme 1
Fuse & Circuit Breaker Identification
- 1 - 10 Amp Dome Light
- 2 - 10 Amp Stoplights
- 3 - 10 Amp Hazard
- 4 - 15 Amp Wiper
- 5 - 15 Amp Radio
- 6 - 10 Amp Horn
- 7 - 10 Amp Turn Signals
- 8 - 10 Amp Back-Up Lights
- 9 - 10 Amp Air Conditioner
- 10 - 20 Amp Defogger
- 11 - 20 Amp Heater
- 12 - 10 Amp Taillights
- 13 - 10 Amp Spare
- 14 - 15 Amp Headlight (Lower)
- 15 - 15 Amp Headlight (Upper)
FUSE PANEL IDENTIFICATION (1990-91 MODELS)
Fuse panel is located under instrument panel on driver's side of vehicle. Fusible link wires are used to protect a number of circuits. These links will melt in the event of excessive current flow. Replace after determining cause.
Scheme 2
- 1 - 15 Amp Washer/Wiper
- 2 - 10 Amp Gauges
- 3 - 10 Amp Radio
- 4 - 10 Amp Automatic Transaxle
- 5 - 10 Amp Turn Signals
- 6 - 10 Amp Horn
- 7 - 15 Amp Cigarette Lighter
- 8 - 10 Amp Dome Light
- 9 - 10 Amp Heater
- 10 - 20 Amp Heater
- 11 - 15 Amp Automatic Seat Belt
- 12 - 10 Amp Stoplights
- 13 - Amp Spare Fuses
FUSE PANEL IDENTIFICATION (1992 MODELS)
Fuse panel is located under instrument panel on driver's side of vehicle. Fusible link wires are used to protect a number of circuits. These links will melt in the event of excessive current flow. Replace after determining cause.
Scheme 3
- 1 - 15 Amp Windshield Wiper/Washer, Rear Wiper/Washer
- 2 - 10 Amp Meter & Gauges, Indicator Lights, Warning Lights, Clutch Switch, Seat Belt Warning Timer
- 3 - 10 Amp Radio, Clock
- 4 - 10 Amp 4 A/T Control Unit, Overdrive Switch, Inhibitor Switch, Auto-Cruise Control Unit
- 5 - 10 Amp Back-Up Light, Inhibitor Switch, Hazard Warning Light, 3 A/T Control Unit
- 6 - 10 Amp Horn, Headlight Relay, Upper Beam Relay
- 7 - 15 Amp Cigarette Lighter, Remote-Controlled Mirror
- 8 - 10 Amp Dome/Luggage Compartment Lights, Clock, Radio, MPI Control Unit, A/T Control Unit, Door Ajar Warning Light, Automatic Seat Belt Control Unit, Seat Belt Warning Buzzer, Key Reminder Switch
- 9 - 10 Amp Power Window/Defogger Relays, Defogger Timer/Switch, Heater Relay, Blower Switch, Auto Compressor Control Unit, DRL Control Relay (Canada), DRL Control Unit (Canada)
- 10 - 20 Amp Heater Relay
- 11 - 15 Amp Door Lock Relay, Door Lock Control Unit
- 12 - 15 Amp Stoplight
- 13 - Not Used
FUSE PANEL IDENTIFICATION (1993-96 MODELS)
Fuse panel is located under instrument panel on driver's side of vehicle. Fusible link wires are used to protect a number of circuits. These links will melt in the event of excessive current flow. Replace after determining cause.
Scheme 4
- 1 - 10 Amp Dome Light
- 2 - 10 Amp Heater Relay
- 3 - 10 Amp 4 A/T
- 4 - 15 Amp Stoplights
- 5 - 10 Amp Turn Signals
- 6 - 20 Amp Door Locks
- 7 - 10 Amp Horn
- 8 - 20 Amp Wiper
- 9 - 25 Amp Heater
- 10 - 10 Amp Backup Lights
- 11 - 10 Amp Meters
- 12 - 15 Amp Cigarette Lighter
- 13 - 10 Amp Radio
- 14 - Spare Fuses
Scheme 5
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- 1 - 10 Amp (Red) ABS
- 2 - 10 Amp (Red) Headlamps High-Beam
- 3 - 10 Amp (Red) Taillights
- 4 - 10 Amp (Red) Hazard
- 5 - 30 Amp (Green) Rear Window Defogger
- 6 - 30 Amp (Green) Power Window
- 7 - 40 Amp Fusible Link
- 8 - 40 Amp Ignition Switch
- 9 - 30 Amp (Green) Radiator Fan
- 10 - 30 Amp (Green) Lamp
- 11 - 20 Amp (Yellow) Electronic Fuel Injection
