ROTOR
- Check continuity across rotor slip rings. Resistance should be within specification. See «ROTOR RESISTANCE SPECIFICATIONS»(ref-58263-S16181894932001011700000) table. Replace rotor if no continuity exists or resistance is not within specification.
- Check continuity between individual slip rings and rotor shaft. If continuity exists, rotor coil or slip ring is grounded. Replace rotor.
STATOR
Ensure no continuity exists between stator coil leads and stator core. Check continuity between leads of stator coil. If no continuity exists between coil leads, replace stator.
ALTERNATOR MINIMUM OUTPUT
| Application | Amps | ||
|---|---|---|---|
| Colt, Colt 200, Galant, Precis & Summit | 52.5 | ||
| Colt Vista & Summit Wagon | 52.5 | ||
| Diamante | 63 | ||
| Eclipse | |||
| Non-Turbo | 45.5 | ||
| Turbo | 52.5 | ||
| Expo/Expo LRV | |||
| 1.8L | 42 | ||
| 2.4L | |||
| M/T | 45.5 | ||
| A/T | 52.5 | ||
| Turbo | 52.5 | ||
| Mirage | |||
| 1.5L & 1.6L A/T | 52.5 | ||
| 1.6L M/T | 45.5 | ||
| Montero | 52.5 | ||
| Pickup | |||
| 2.4L | 28 | ||
| 3.0L | 45.5 | ||
| Ram-50 | |||
| 2.4L | |||
| Standard Alternator | 28 | ||
| Optional Alternator | 42 | ||
| Canada | 31.5 | ||
| 3.0L | 45.5 | ||
| Stealth | |||
| DOHC | 77 | ||
| SOHC | 63 | ||
| 3000GT | 77 | ||
ALTERNATOR MINIMUM OUTPUT SPECIFICATIONS
REGULATOR VOLTAGE
| Ambient Temperature | Voltage |
|---|---|
| 4°F (-20°C) | 14.2-15.4 |
| 68°F (20°C) | 13.9-14.9 |
| 140°F (60°C) | 13.4-14.6 |
| 176°F (80°C) | 13.1-14.5 |
REGULATOR VOLTAGE SPECIFICATIONS
ROTOR RESISTANCE
| Application | Ohms |
|---|---|
| Colt, Colt 200, Precis & Summit | 3.1 |
| All Others | 3.0-5.0 |
ROTOR RESISTANCE SPECIFICATIONS
