Maintenance Information: Overview Dodge Stratus I

Procedures 1 illustration ~486 words

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp (Red) Downstream Oxygen Sensor
  2. 2 - 20 Amp (Yellow) ABS Main Relay
  3. 3 - 20 Amp (Yellow) Transmission Control Module (TCM), Transmission Solenoids
  4. 4 - 20 Amp (Yellow) Stop Lights, Vanity, Dome, Map, Ignition and Trunk Lights, Power Door Locks, Door Lock Arm/Disarm Switches, Power Mirrors, Radio Clock Memory, Power Antenna, Data Link Connector, Body Control Module
  5. 5 - 20 Amp (Yellow) Powertrain Control Module (PCM), ASD Relay, Injectors, Generator Field, DIS Coil, Oxygen Sensor Heater, EGR Solenoid, Downstream Oxygen Sensor
  6. 6 - 20 Amp (Yellow) Hazard Flashers
  7. 7 - 10 Amp (Red) Off/Run/Start Ignition Switch Feed
  8. 8 - 20 Amp (Yellow) Run/Start, Run/ACC, and Start Ignition Switch Feed, Starter Solenoid, Fuel Pump
  9. 9 - 10 Amp (Red) Instrument Cluster, Radiator Fan Relay, A/C Relay, Purge Solenoid
  10. 10 - 10 Amp (Red) Powertrain Control Module (PCM), ABS Module, Fuel Pump Relay, 2.5L Engine Distributor
  11. 11 - Not Used
  12. 12 - 40 Amp (Orange) Rear Window Defroster and Lighted Switch, Heated Mirrors
  13. 13 - 40 Amp (Orange) ABS Pump Motor
  14. 14 - 40 Amp (Orange) Parking Lights, Horns, Radio Amplifier, Power Receptacle, (Cigarette Lighter)
  15. 15 - 40 Amp (Orange) Headlights, Power Seats, Power Door Locks, Headlight Delay Relay, Daytime Running Lights (Canada)
  16. 16 - 40 Amp (Orange) Run/Ignition Switch Feed
  17. 17 - Not Used
  18. 18 - 40 Amp (Orange) Windshield Wiper Motor
  19. 19 - 40 Amp (Orange) A/C Clutch, Radiator Fan Motors

Scheme 2

Scheme 2: INTERIOR FUSE PANEL IDENTIFICATION
Scheme 2: INTERIOR FUSE PANEL IDENTIFICATION
  1. 1 - 30 Amp (Green) Blower Motor
  2. 2 - 10 Amp (Red) Right High Beam Headlight, High Beam Indicator
  3. 3 - 10 Amp (Red) Left Headlight High Beam
  4. 4 - 15 Amp (Blue) Back-up Lights Switch & Relay, Speed Proportional Steering Module, Power Door Lock Switch Illumination, Daytime Running Light Module (Canada)
  5. 5 - 10 Amp (Red) Power Door Lock Arm/Disarm Switches, Power Mirrors, Vanity, Dome, Map, Ignition and Trunk Lights, Sunroof, Radio, Power Antenna, Data Link Connector, Body Control Module
  6. 6 - 10 Amp (Red) Heated Mirrors, Heated Rear Window Indicator
  7. 7 - 20 Amp (Yellow) Instrument Cluster Illumination, Park & Tail Lights
  8. 8 - 20 Amp (Yellow) Power Receptacle (Cigarette Lighter), Radio Amplifier, Horns
  9. 9 - 15 Amp (Blue) Power Door Lock Motors (Body Control Module)
  10. 10 - 20 Amp (Yellow) Daytime Running Light Module (Canada)
  11. 11 - 10 Amp (Red) Instrument Cluster, Transmission Control, Park/Neutral Switch, Body Control Module (BCM)
  12. 12 - 10 Amp (Red) Left Headlight Low Beam
  13. 13 - 20 Amp (Yellow) Right Headlight Low Beam, Fog Light Switch
  14. 14 - 10 Amp (Red) Radio
  15. 15 - 10 Amp (Red) Turn Signal and Hazard Flashers, Wiper Switch, Wiper Relays, Rear Window Defroster Relay
  16. 16 - 10 Amp (Red) Air Bag Control Module
  17. 17 - 10 Amp (Red) Air Bag Control Module
  18. 18 - 20 Amp (Circuit Breaker) Power Seat Switch
  19. 19 - 20 Amp (Circuit Breaker) Sunroof Control Module and Motor, Window Motors and Switch Illumination
