A/C SYSTEMS SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES & EQUIPMENT section. |
| Application | Specification |
|---|
| Compressor Type | Sanden TRS-90 Scroll |
| Compressor Belt Tension |
| New | 150 lbs. (68.0 kg) |
| Used | 80 lbs. (36.3 kg) |
| System Oil Capacity | (1) 5.0 ozs. |
| Refrigerant (R-134a) Capacity | 1.75 lbs. (.794 kg) |
| System Operating Pressures | (2) |
| (1) Use SP-15 PAG Oil. (2) See A/C SYSTEM CHARGE LEVEL TEST. |
| (2) | See A/C SYSTEM CHARGE LEVEL TEST. |
A/C SYSTEMS SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Mounting Bolts | 30 (41) |
| INCH Lbs. (N.m) |
| A/C Pressure Transducer | 50 (6) |
| Receiver-Drier Refrigerant Lines | 125 (14) |
Manual A/C-Heater System Wiring Diagram. Scheme 1
Scheme 1: Manual A/C-Heater System Wiring Diagram
