LUMBAR/SIDE ADJUSTMENT SWITCH
Remove switch from center console. Using ohmmeter, check continuity of switch. See LUMBAR/SIDE ADJUSTMENT SWITCH CONTINUITY and (Scheme 1). Replace switch as necessary if switch continuity is not as specified.
| Switch Position | Check Continuity Between | |
|---|---|---|
| Lumbar Support | ||
| Push | Pins 2 & 3; Pins 5 & 7 | |
| Off | Pins 2, 3 & 5 | |
| Release | Pins 2 & 5; Pins 3 & 7 | |
| Side Support | ||
| Spread | Pins 1 & 2; Pins 7 & 8 | |
| Off | Pins 1, 2 & 8 | |
| Close | Pins 1 & 7; Pins 2 & 8 | |
LUMBAR/SIDE ADJUSTMENT SWITCH CONTINUITY
