Maintenance Information: Overview Dodge Stealth I

MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see SCHEDULED SERVICES article below

1. SCHEDULED SERVICES - TURBO
2. SCHEDULED SERVICES - NON-TURBO

Warranty information and specifications for fluid

capacities, lubrication specifications, wheel and tire size

and battery type are covered in this article.

FUSE PANEL IDENTIFICATION

Fuse block is located under instrument panel on driver's side. In event of a blown fuse, locate cause before replacing fuse. Spare fuses are contained in the fuse cover.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. 1 - 15 Amp (Light Blue) - Cigarette Lighter
2. 2 - 10 Amp (Red) - Radio
3. 3 - 10 Amp (Red) - Heater Relay
4. 4 - 10 Amp (Red) - Seat Belt Warning Buzzer
5. 5 - 15 Amp (Light Blue) - Engine
6. 6 - 15 Amp (Light Blue) - Turn Signals
7. 7 - 15 Amp (Light Blue) - Headlight Relay
8. 8 - 15 Amp (Light Blue) - Wiper
9. 9 - 10 Amp (Red) - (Automatic Transaxle)
10. 10 - 10 Amp (Red) (1991-93) - Headlight, Pop-Up Relay
11. 10 - 10 Amp (Red) (1994-95) - Door Locks
12. 11 - 10 Amp (Red) - Dome Light
13. 12 - 10 Amp (Red) - Back-Up Lights
14. 13 - 15 Amp (Light Blue) - Stoplights
15. 14 - 30 Amp (Green) - Heater
16. 15 - 10 Amp (Red) - Anti-Theft
17. 16 - Spare Fuse (1991-92)
18. 16 - 15 Amp (Light Blue) 1994-95 - Amplifier
19. 17 - Spare Fuse 1994-95
20. 1 - 10 Amp (Red) - Seat Belt Solenoid, MFI Relay
21. 2 - Not Used
22. 3 - 10 Amp (Red) - Radiator Fan Motor Relay, A/C Compressor Lock Controller, Blower Motor Relay, A/C Control Unit, ECS Control Unit, Condenser Fan Motor Relay
23. 4 - 10 Amp (Red) - Audio, Power Antenna Control Unit, Auto-cruise Control Unit, ETACS Unit
24. 5 - 15 Amp (Light Blue) - Cigarette Lighter, Power Mirrors
25. 6 - 10 Amp (Red) - Power Door Lock Relay, Power Antenna Control Unit
26. 7 - 10 Amp (Red) - ELC-4 A/T Control Module
27. 8 - Not Used
28. 9 - 15 Amp (Light Blue) - Wiper Relay, Wiper/Washer Motor, Rear Intermittent Wiper, Keyless Entry Control Unit
29. 10 - 15 Amp (Light Blue) - Accessory Socket, ETACS Unit
30. 11 - 15 Amp (Light Blue) - Combination Meter, Combination Gauge, ETACS Unit, Speed Sensor, Motor Antenna Control Unit, Turn Signal Unit, Hazard Flasher Unit, Auto-Cruise Control Main Switch, SRS (Air Bag) Diagnosis Unit, Auto-Cruise Relay
31. 12 - 15 Amp (Light Blue) - Ignition Coil, Power Transistor, MFI Relay, Engine Control Module (ECM)
32. 13 - 15 Amp (Light Blue) - Amplifier
33. 14 - 10 Amp (Red) - Anti-Theft Horn
34. 15 - Not Used
35. 16 - 30 Amp (Green) - Blower Motor
36. 17 - 15 Amp (Light Blue) - Stop Light, High-Mounted Stop Light
37. 18 - 10 Amp (Red) - Back-up Light, Light Automatic Shutoff Unit, SRS (Air Bag) Diagnosis Unit
38. 19 - 10 Amp (Red) - Engine Control Module, ELC-4 A/T Control Module, ETACS Unit, Dome Light, Foot Light, Door Light, Luggage Compartment Lamp, Combination Meter, A/C Control Unit, Auto-Cruise Control, Ignition Key Illumination, Audio, Light Automatic Shut-Off, ECS Control Unit
39. 1 - Power Door Lock Relay
40. 2 - Not Used
41. 3 - Rear Window Defogger Relay
42. 4 - Power Window Relay
43. 5 - 10 Amp (Red) - Power Mirror, Heated Mirror WARNING: Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
44. 1 - 120 Amp (Wine Red) - Generator
45. 2 - Not Used
46. 3 - 40 Amp (Green) - Lighting
47. 4 - 30 Amp (Pink) - Ignition
48. 5 - 40 Amp (Green) - Radiator Fan and Condenser Fan Motor
49. 6 - 40 Amp (Green) - Fuse 1, 6, 14, 16, 17, 19
50. 7 - 60 Amp (Yellow) - ABS
51. 8 - Not Used
52. 9 - 30 Amp (Pink) - Power Windows
53. 10 - 40 Amp (Green) - Defogger
54. 11 - Not Used
55. 12 - 20 Amp (Yellow) - MFI
56. 13 - 15 Amp (Blue) - Tail Lights
57. 14 - 10 Amp (Red) - Horn
58. 15 - 15 Amp (Blue) - Fog Light
59. 16 - 10 Amp (Red) - High-Beams
60. 17 - 10 Amp (Red) - Hazard
61. 18 - Not Used
62. A - Headlight Relay
63. B - Not Used
64. C - Fog Light Relay
65. D - Radiator (LO) Fan Relay
66. E - Tail Light Relay
67. F - Horn Relay
68. G - Radiator (HI) Fan Relay
69. H - Not Used
70. I - Starter Relay
71. J - Generator Relay
72. K - IOD or Storage Connector
73. 1 - 20 Amp (Yellow) - Condenser Fan Motor
74. 2 - 10 Amp (Red) - Air Conditioner
75. 3 - Condenser (HI) Fan Relay
76. 4 - Not Used
77. 5 - Magnetic Clutch Relay
78. 6 - Condenser (LO) Fan Relay
