POWER MIRROR MOTOR TEST
Connect 12-volt power source to mirror connector terminals. (Scheme 1)- (Scheme 3). Replace mirror as necessary.
Scheme 1
Scheme 2
Scheme 3
POWER MIRROR SWITCH TEST
Remove mirror switch. Using ohmmeter, check continuity of switch. See POWER MIRROR SWITCH CONTINUITY CHART. (Scheme 4) Replace switch as necessary if switch continuity is not as specified.
| Switch Position | Check Continuity Between | |
|---|---|---|
| Left Side (1) | ||
| UP | Pins 4 & 8; Pins 6 & 7 | |
| DOWN | Pins 4 & 7; Pins 6 & 8 | |
| LEFT | Pins 3 & 6; Pins 4 & 7 | |
| RIGHT | Pins 3 & 4; Pins 6 & 7 | |
| Right Side (1) | ||
| UP | Pins 2 & 4; Pins 6 & 7 | |
| DOWN | Pins 2 & 6; Pins 4 & 7 | |
| LEFT | Pins 4 & 7; Pins 6 & 9 | |
| RIGHT | Pins 4 & 9; Pins 6 & 7 | |
| (1) (Scheme 4) | ||
| (1) | (Scheme 4) |
POWER MIRROR SWITCH CONTINUITY CHART
