INTRODUCTION

Note. Shadow and Sundance Convertible models equipped with 2.5L TBI engine are manufactured with either early or late design fuel, ignition and emission systems. Late design vehicles use an epoxy ignition coil, mounted on thermostat housing, and a high pressure fuel system requiring quick-connect fuel fittings. Early design vehicles use an oil-filled ignition coil, mounted on right inner fender, and a low pressure fuel system using hoses and clamps.

If no faults were found while performing BASIC DIAGNOSTIC PROCEDURES in BASIC TESTING , proceed with self-diagnostics. If no fault codes or only pass codes are present after entering self-diagnostics, proceed to TESTS W/O CODES article for diagnosis by symptom (i.e. ROUGH IDLE, NO START, etc.) in the ENGINE PERFORMANCE section.

MODEL IDENTIFICATION

VEHICLE BODY IDENTIFICATION

SYSTEM DIAGNOSIS

The self-diagnostic capabilities of this system, if properly utilized, can simplify testing. The Single Board Engine Controller (SBEC) monitors several different engine control system circuits.

If a problem is sensed with a monitored circuit, a fault code is stored in the SBEC, the CHECK ENGINE light illuminates and SBEC enters limp-in mode. In limp-in mode, SBEC compensates for component failure by substituting information from other sources. This allows vehicle operation until repairs can be made.

Once codes are known, refer to FAULT CODES listed in this article to determine the questionable circuit. Test circuits and repair or replace components as required. If problem is repaired or ceases to exist, the SBEC cancels that fault code after 50 ignition on/off cycles. To clear codes, refer to CLEARING CODES in this article.

A specific fault code results from a particular system failure. It is NOT necessarily the reason for that failure. The fault code does not condemn a specific component. The fault code calls out a probable malfunction area.

Hard Failures

Hard failures cause CHECK ENGINE light to illuminate and remain on until the malfunction is repaired. If light comes on and remains on (light may flash) during vehicle operation, cause of malfunction must be determined using diagnostic (code) charts. If a sensor fails, SBEC will use a substitute value in its calculations, allowing engine operation in limp-in mode. In this condition, vehicle will run but driveability may be poor.

Intermittent Failures

Intermittent failures may cause CHECK ENGINE light to flicker or stay on until the intermittent fault goes away. However, the corresponding trouble code will be retained in SBEC memory. If related fault does not reoccur within a certain time frame, related trouble code will be erased from SBEC memory. Intermittent failures can be caused by faulty sensor, bad connector or wiring related problems. See INTERMITTENTS in TESTS W/O CODES article in the ENGINE PERFORMANCE section.

DIAGNOSTIC PROCEDURE

Refer to ENTERING ON-BOARD DIAGNOSTICS to retrieve fault codes. If fault codes are NOT present and/or DRB-II (Diagnostic Readout Box-II) is used, proceed to one of the following tests

1. Go to NO START TEST 1A (NS-1A) chart if a no-start condition exists or engine stalls after start-up. Perform indicated VERIFICATION PROCEDURE chart after repairs. Ensure charts apply to engine being tested.
2. Go to DRIVEABILITY TEST 1A (DR-1A) chart if engine runs but has performance problems. Perform indicated VERIFICATION PROCEDURE chart after repairs. Ensure charts apply to engine being tested.

Note. When using trouble shooting charts for diagnosis, DO NOT skip any steps in chart or incorrect diagnosis may result.

Before proceeding with diagnosis, the following precautions must be followed

1. Vehicle must have a fully charged battery and functional charging system.
2. Probe SBEC connector from pin side. DO NOT backprobe SBEC connector.
3. DO NOT cause short circuits when performing electrical tests. This will set additional fault codes, making diagnosis of original problem more difficult.
4. DO NOT use a test light in place of a voltmeter.
5. When checking for spark, ensure coil wire is NO more than 1/4" from ground. If coil wire is more than 1/4" from ground, damage to vehicle electronics and/or SBEC may result.
6. DO NOT prolong testing of fuel injectors or engine may hydrostatically (liquid) lock.
7. Always repair lowest fault code number (CHECK ENGINE light) or first fault displayed (DRB-II) first.
8. Always perform verification procedure test after repairs are made.
9. Always disconnect DRB-II after use.
10. Always disconnect DRB-II before charging battery.

ENTERING ON-BOARD DIAGNOSTICS

Note. Manufacturer recommends using DRB-II (Diagnostic Readout Box-II) to diagnose the system. CHECK ENGINE light function can be used but has limited diagnostic usage.

Check Engine Light Diagnostic Mode

1. Start engine (if possible). Move transmission shift lever through all positions, ending in Park. Turn A/C switch on, then off (if equipped).
2. Turn engine off. Without starting engine again, turn ignition on, off, on, off and on. Record 2-digit fault codes as displayed by flashing CHECK ENGINE light.
3. For example, Code 23 is displayed as flash, flash, 4-second pause, flash, flash, flash. After a slightly longer pause, other codes stored are displayed in numerical order.
4. When CHECK ENGINE light begins to flash fault codes, it cannot be stopped. If you lose count, it will be necessary to start over. Code 55 indicates end of fault code display.
5. Refer to FAULT CODES table to translate trouble code number to a system fault description (DRB-II display). Once trouble area is identified, refer to NO START TEST 1A (NS-1A) or DRIVEABILITY TEST 1B (DR-1B) trouble shooting chart to diagnose problem. Use trouble shooting chart titles to find appropriate chart.
6. As an example, a 3.0L engine starts and runs, but has a driveability problem. CHECK ENGINE light indicates a Code 14. Refer to FAULT CODES table to translate trouble code number to a system fault description (DRB-II display).
7. When system fault description (DRB-II display) is obtained, refer to DR-1B: DRB-II FAULT MESSAGES since vehicle has a driveability problem. Select fault message and corresponding test from table and proceed to appropriate chart.

DRB-II Diagnostic Mode

1. Turn ignition off. Attach DRB-II to engine diagnostic connector. Connector is located in engine compartment, near SBEC.
2. Start engine (if possible). With foot on brake, move transmission shift lever through all positions, ending in Park. Turn A/C switch on, then off (if equipped).
3. Turn engine off. Without starting engine again, turn ignition on. Enter FUEL/IGN MENU. To enter FUEL/IGN MENU, see DRB-II TEST FUNCTIONS. At FUEL/IGN MENU, press "2" (READ FAULTS) key. Press ENTER key. After fault codes are accessed, refer to NO START TEST 1A (NS-1A) or DRIVEABILITY TEST 1A (DR-1A) for your engine.
4. To erase faults while in this option go to next step. Press ATM key. At DRB-II display, press "2" (ERASE) key. DRB-II will display ERASE FAULTS ARE YOU SURE? (ENTER TO ERASE). Press ENTER key.
5. When DRB-II is finished erasing fault codes, it will display FAULTS ERASED. This display will remain until ATM key is pressed. After ATM key is pressed, display will return to FUEL/IGN MENU screen.

DRB-II TEST FUNCTIONS

Note. DO NOT touch DRB-II keypad during DRB-II power-up sequence or an error message will result.

1. In order to perform diagnostic tests using the DRB-II, the DRB-II must be in the FUEL/IGN MENU. At the FUEL/IGN MENU, fault codes and DRB-II test functions can be accessed.
2. To reach FUEL/IGN MENU, turn ignition off. Attach DRB-II to engine diagnostic connector. Connector is located in engine compartment, near SBEC. Turn ignition switch to RUN position.
3. All DRB-II character positions will illuminate and copyright information will appear on screen for a few seconds. If DRB-II screen is blank or any error messages appear, refer to «DRB-II PROBLEMS & ERROR MESSAGES»(/dodge/spirit/i-1988-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-4-cyl) in this article.
4. After a few seconds DRB-II menu will appear. At DRB-II menu, press "4" (SELECT SYSTEM) key. Press ENTER key. At SELECT SYSTEM menu, press "1" (ENGINE) key. Press ENTER key. DRB-II menu will appear indicating engine year, size, type of transmission and SBEC part number.
5. After a few seconds AIR COND menu will appear. Press "1" (WITH A/C) or press "2" (WITHOUT A/C). DRB-II display will change to ENGINE SYSTEMS menu. At ENGINE SYSTEMS menu, press "1" (FUEL/IGNITION) key. Press ENTER key.
6. Display will change to FUEL/IGN MENU. At FUEL/IGN menu of engine diagnostic program, specific test functions programmed into DRB-II can be performed. The following DRB-II modes can be accessed: SYSTEM TEST, READ FAULTS, STATE DISPLAYS, ACTUATOR TEST and ADJUSTMENTS.

System Test Mode

This function is not available in the engine diagnostics program.

Read Faults Mode

This function allows the user to read and erase fault codes. A fault counter will appear along with fault displayed on DRB-II. As an example, DRB-II will display 1 OF 2 FAULTS. SBEC will store up to 8 fault messages. Faults are numbered in reverse order of setting. The most recent fault to occur will be number one. Vehicles without air conditioning will always have A/C CLUTCH RELAY CKT (circuit) stored in memory. This fault will always be number one if vehicle is not equipped with A/C. If no fault messages are stored, DRB-II will display NO FAULTS DETECTED and start counter will show 0 STARTS SINCE ERS (Erased).

A start counter will appear below DRB-II fault counter display. Start counter counts the number of times vehicle is started since faults were last set, erased, or battery was disconnected. This helps determine if fault is intermittent. Memory space limits start counter to first 3 faults. Start counter of zero equals a hard fault. Start counter of more than zero indicates an intermittent fault. Start counter will count up to 255 starts. If no fault messages are stored, DRB-II will display NO FAULTS DETECTED and start counter will show 0 STARTS SINCE ERS (Erased).

State Display Mode

This function allows user to read states or values of a variety of sensors, inputs/outputs and components.

The SBEC can only recognize high and low states on switch circuits. SBEC cannot tell the difference between an open or short circuit or a defective switch. If DRB-II displays a change between INPUT HIGH and INPUT LOW, it can be assumed that the entire switch circuit to the SBEC is functioning.

Actuator Test Mode

This function allows the user to check for proper operation of output circuits or devices, which the SBEC cannot internally recognize. DRB-II allows SBEC to activate these outputs or devices, allowing an observer to verify proper operation.

Most of the tests available in this mode provide an audible or visual indication of device operation (click of relay contacts, spray fuel, etc.). With the exception of an intermittent condition, if a device functions properly during its test, it can be assumed that the device, wiring and its driver circuit are functioning properly.

Adjustments Mode

This function allows the user to erase fault codes. Function also allows user to reset Emission Maintenance Reminder (EMR) light and mileage (trucks only).

DRB-II Volt/Ohmmeter Mode

1. To access volt/ohmmeter mode of DRB-II, connect Red volt/ohmmeter test lead to Red port, located on right top side of DRB-II. NOTE: Because DRB-II is grounded through engine diagnostic connector, only one volt/ohmmeter test lead is required when using volt/ohmmeter option. DRB-II volt/ohmmeter should only be used when diagnostic flow charts require the use of this option.
2. To access voltmeter, press VOLT/OHM key once. DRB-II is now in voltmeter mode. Touch test probe to connector or wire to be measured. Read voltage on DRB-II display. When voltage testing is complete, press VOLT/OHM key 3 times to exit voltmeter mode.
3. To access ohmmeter, press VOLT/OHM key twice. DRB-II is now in ohmmeter mode. Touch test probe to connector or wire to be measured. Read resistance to circuit ground on DRB-II display. When resistance testing is complete, press VOLT/OHM key twice to exit ohmmeter mode.

DRB-II Continuity Meter Mode

Press VOLT/OHM key 3 times. Display will read NO CONTINUITY. Touch test probe to connector or wire to be measured. Read continuity on DRB-II display. When continuity testing is complete, press VOLT/OHM key once to exit continuity meter mode.

Vehicles Tested Mode

1. Vehicles tested mode is used to show what vehicles are covered by DRB-II cartridge. To access vehicles tested mode, turn ignition off. Attach DRB-II to engine diagnostic connector. Connector is located in engine compartment, near SBEC.
2. Turn ignition switch to RUN position. All DRB-II character positions will illuminate and copyright information will appear on screen for a few seconds. After a few seconds DRB-II menu will appear.
3. At DRB-II menu, press "1" (VEHICLES TESTED) key. Press ENTER key. DRB-II will display vehicles covered by cartridge. Screen will display for 5 seconds and return to DRB-II menu.

How To Use Mode

Enter DRB-II menu display. Refer to steps 1) and 2) under VEHICLES TESTED MODE. At DRB-II menu, press "2" (HOW TO USE) key. Press ENTER key. A series of screens will be displayed explaining the use of DRB-II keys used to move through engine diagnostic program.

Configure Mode

1. Configure option allows user to customize DRB-II display. For example, if metric system is more useful to use, simply select METRIC from the appropriate menu.
2. All selections made under CONFIGURE option remain active until user changes selection. To enter configure mode, enter DRB-II menu display. Refer to steps 1) and 2) under VEHICLES TESTED MODE. At DRB-II menu, press "3" (CONFIGURE) key. Press ENTER key. DRB-II will display CONFIGURE menu.

Blank Message Screen

1. Connect DRB-II to a different vehicle. If message screen is still blank, DRB-II or cable adapter are faulty. Substitute to find faulty component.
2. If message screen is not blank, DRB-II and cable adapter are functioning properly. Inspect diagnostic connector for proper wire placement, damaged terminals or pushed out pins. Repair as necessary.
3. If diagnostic connector is okay, using an ohmmeter, check resistance between Black/White or Black/Yellow wire and ground at engine diagnostic connector. If resistance is greater than 10 ohms, repair open in Black/White or Black/Yellow wire.

No Response Message

1. Connect DRB-II to another vehicle. If DRB-II displays NO RESPONSE message again, DRB-II or cable adapter are faulty. Substitute to find faulty component. If message screen does not display NO RESPONSE, DRB-II and cable adapter are functioning properly. Go to next step.
2. Turn ignition off. Disconnect DRB-II. Using an ohmmeter, check Pink or Black/Red wire for resistance between SBEC and engine diagnostic connectors. If resistance is more than 10 ohms, repair open in Pink or Black/Red wire.
3. If resistance is less than 10 ohms, check Light Green/Orange or Black/Pink wire for resistance between SBEC and engine diagnostic connectors. If resistance is more than 10 ohms, repair open in Light Green/Orange or Black/Pink wire.

Ram Test Failure Message

Replace DRB-II.

Cartridge Error Message

Replace DRB-II cartridge.

Key Pad Test Failure Message

Power up DRB-II again with fingers off the keypad. If error message returns, replace DRB-II.

High Or Low Battery Message

Correct condition of vehicle battery and reconnect DRB-II.

SELF-DIAGNOSTICS FAULT CODES TABLE

SELF-DIAGNOSTICS FAULT CODES

EMISSION MAINTENANCE REMINDER (EMR) MILEAGE TRANSFER

Note. EMR information applies only to trucks, but will be referred to in flow charts.

1. When SBEC is replaced, vehicle mileage must be copied from odometer to replacement SBEC memory. Transfer of vehicle mileage will enable new SBEC to operate EMR light properly.
2. Using DRB-II, enter FUEL/IGN MENU. See DRB-II TEST FUNCTIONS in this article. At FUEL/IGN menu, press "5" (ADJUSTMENTS) key. Press ENTER key. At ADJUSTMENTS menu, press "3" (EMR MEMORY CHECK) key. Press ENTER key. DRB-II display will read EMR MEMORY CHECK ARE YOU SURE? ENTER TO CONTINUE.
3. Press ENTER key. DRB-II will display IS INSTRUMENT PANEL MILEAGE BETWEEN 9953 AND 10051? If vehicle mileage is within specification, EMR memory check is complete. Press YES key. If vehicle mileage is not within specification, go to next step.
4. Press NO key. DRB-II will display ENTER MILEAGE SHOWN ON INSTRUMENT PANEL, USE ENTER KEY TO END. Enter vehicle mileage. DO NOT enter tenths. When correct vehicle mileage is entered, press ENTER key.
5. DRB-II will ask for verification of mileage entry. If mileage entry was accurate, press ENTER key. DRB-II will display EMR MEMORY CHECK TEST COMPLETE. Vehicle must travel at least 8 miles for reset to occur.

EMISSION MAINTENANCE REMINDER (EMR) LIGHT RESET PROCEDURE

Note. EMR information applies only to trucks, but will be referred to in flow charts.

1. The Emission Maintenance Reminder (EMR) light is designed to be a reminder to service the vehicle emissions control system. It is not an emissions warning system, only a reminder to perform emissions servicing.
2. The components to be serviced include PCV valve, oxygen sensor and some vacuum-operated components. EMR light will illuminate after a predetermined mileage.
3. Using DRB-II, enter FUEL/IGN MENU. See DRB-II TEST FUNCTIONS in this article. At FUEL/IGN menu, press "5" (ADJUSTMENTS) key. Press ENTER key.
4. At ADJUSTMENTS menu, press "3" (EMR MEMORY CHECK) key. Press ENTER key. Press F1 or F2 key until display reads RESET EMR LIGHT. Press YES key.
5. Display will read RESET EMR LIGHT ARE YOU SURE? YES, NO. Press YES key. When DRB-II is finished resetting EMR light, DRB-II display will read EMR LIGHT RESET.

CLEARING CODES

Note. Fault codes can also be cleared in READ FAULTS option of DRB-II. To ensure that all faults are read, it is advisable to use READ FAULTS option to erase fault codes. See DRB-II DIAGNOSTIC MODE under ENTERING ON-BOARD DIAGNOSTICS in this article.

1. If DRB-II is not available, go to step 3). If DRB-II is available, enter FUEL/IGN MENU. See «DRB-II TEST FUNCTIONS»(/dodge/spirit/i-1988-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-4-cyl__drb-ii-test-functions) in this article. At FUEL/IGN menu, press "5" (ADJUSTMENTS) key. Press ENTER key. At ADJUSTMENTS menu, press "1" (ERASE FAULTS) key. Press ENTER key.
2. DRB-II will display ERASE FAULTS ARE YOU SURE? (ENTER TO ERASE). Press ENTER key. When DRB-II is finished erasing fault codes, screen will display FAULTS ERASED.
3. If DRB-II is not available, fault codes may be cleared by disconnecting negative battery cable for at least 15 seconds, allowing SBEC to clear fault codes.

NO START DIAGNOSTIC FLOW CHARTS: NS-1A TO NS-17A

Note. The following trouble shooting charts and illustrations are courtesy of Chrysler Motors.

Test NS-1A: Ignition Spark & Power Feed To Coil Ckt Diag. Scheme 8

Test NS-1A: (1 of 3) Ignition Spark & Power Feed To Coil. Scheme 9

Test NS-1A: (2 of 3) Ignition Spark & Power Feed To Coil. Scheme 10

Test NS-1A: (3 of 3) Ignition Spark & Power Feed To Coil. Scheme 11

Test NS-2A: (1 of 2) Fuel Spray & Fault Messages With DRB-II. Scheme 12

Test NS-2A: (2 of 2) Fuel Spray & Fault Messages With DRB-II. Scheme 13

Test NS-3A Ckt Diag: Injector Faults, Power To SBEC, MAP Sensor & Theft status. Scheme 14

Test NS-3A: (1 of 3) Injector Faults, Power To SBEC, MAP Sensor & Theft status. Scheme 15

Test NS-3A: (2 of 3) Injector Faults, Power To SBEC, MAP Sensor & Theft status. Scheme 16

Test NS-3A: (3 of 3) Injector Faults, Power To SBEC, MAP Sensor & Theft status. Scheme 17

NS-4A: CHKNG FOR FUEL PRESSURE, TPS & PWR FEED TO INJECTORS

Shadow and Sundance Convertible models are manufactured with either early or late design fuel, ignition and emission systems. Late design vehicles use an epoxy ignition coil, mounted on thermostat housing, and a high pressure fuel system requiring quick-connect fuel fittings. Early design vehicles use an oil-filled ignition coil, mounted on right inner fender, and a low pressure fuel system using hoses and clamps.

Test NS-4A: (1 of 2) Fuel Pressure, TPS & Power Feed To Injectors. Scheme 18

Test NS-4A: (2 of 2) Fuel Pressure, TPS & Power Feed To Injectors. Scheme 19

Test NS-5A Ckt Diag: Wet Plugs, MAP Sensor/Ignition Timing. Scheme 20

Test NS-5A: (1 of 2): Wet Plugs, MAP Sensor/Ignition Timing. Scheme 21

Test NS-5A: (2 of 2): Wet Plugs, MAP Sensor/Ignition Timing. Scheme 22

Test NS-5B: Valve Gear. Scheme 23

Test NS-6A: (1 of 2) Fuel Filter, Fuel Pump, Pressure Regulator & Power To Fuel Pump. Scheme 24

Test NS-6A: (2 of 2) Fuel Filter, Fuel Pump, Pressure Regulator & Power To Fuel Pump. Scheme 25

Test NS-6B: Fuel Filter, Fuel Pump, Pressure Regulator & Power To Fuel Pump. Scheme 26

Test NS-7A Ckt Diag: Flooding Fuel Injector. Scheme 27

Test NS-7A: (1 of 3) Flooding Fuel Injector. Scheme 28

Test NS-7A: (2 of 3) Flooding Fuel Injector. Scheme 29

Test NS-7A: (3 of 3) Flooding Fuel Injector. Scheme 30

Test NS-7B: (1 of 2) Flooding Fuel Injector. Scheme 31

Test NS-7B: (2 of 2) Flooding Fuel Injector. Scheme 32

Test NS-8A: (1 of 2) High Fuel Pressure At Psi. Regulator. Scheme 33

Test NS-8A: High Fuel Pressure At Psi. Regulator (2 of 2). Scheme 34

Test NS-9A: (1 of 2) Defective Coil or Control Circuitry. Scheme 35

Test NS-9A: (2 of 2) Defective Coil or Control Circuitry. Scheme 36

Test NS-10A: (1 of 2) Injector, Control Circuit & SBEC. Scheme 37

Test NS-10A: (2 of 2) Injector, Control Circuit & SBEC. Scheme 38

Test NS-10B: (1 of 2) Injector, Control Circuit & SBEC. Scheme 39

Test NS-10B: (2 of 2) Injector, Control Circuit & SBEC. Scheme 40

Test NS-11A: DRB-II & System Faults. Scheme 41

Test NS-12A: Ckt Diag. System Power, MAP Sensor & SBEC. Scheme 42

Test NS-12A: (1 of 2) System Power, MAP Sensor & SBEC. Scheme 43

Test NS-12A: (2 of 2) System Power, MAP Sensor & SBEC. Scheme 44

Test NS-12B: Ckt Diag. System Power, MAP Sensor & SBEC. Scheme 45

Test NS-12B: (1 of 2) System Power, MAP Sensor & SBEC. Scheme 46

Test NS-12B: (2 of 2) System Power, MAP Sensor & SBEC. Scheme 47

Test NS-13A: Ckt Diag. Code 11, No Ignition Reference Signal During Cranking. Scheme 48

Test NS-13A: (1 of 3) Code 11, No Ignition Reference Signal During Cranking. Scheme 49

Test NS-13A: (2 of 3) Code 11, No Ignition Reference Signal During Cranking. Scheme 50

Test NS-13A: (3 of 3) Code 11, No Ignition Reference Signal During Cranking. Scheme 51

Test NS-13B: (1 of 2) Code 11, No Ignition Reference Signal During Cranking. Scheme 52

Test NS-13B: (2 of 2) Code 11, No Ignition Reference Signal During Cranking. Scheme 53

Test NS-13C: Code 11, No Ignition Reference Signal During Cranking. Scheme 54

Test NS-14A: (1 of 2) Asd Relay Circuit. Scheme 55

Test NS-14A: (2 of 2) Asd Relay Circuit. Scheme 56

Test NS-15A: (1 of 3) Checking ASD Relay Power Feed To Fuel Pump O2 Sensor & Injector. Scheme 57

Test NS-15A: (2 of 3) Checking ASD Relay Power Feed To Fuel Pump O2 Sensor & Injector. Scheme 58

Test NS-15A: (3 of 3) Checking ASD Relay Power Feed To Fuel Pump O2 Sensor & Injector. Scheme 59

Test NS-16A: Ckt Diag. Idle Speed Motor Operation. Scheme 60

Test NS-16A: Idle Speed Motor Operation. Scheme 61

Test NS-16B: Idle Speed Motor Operation. Scheme 62

Test NS-16C: Idle Speed Motor Operation. Scheme 63

Test NS-16D: Idle Speed Motor Operation. Scheme 64

Test NS-16E: Idle Speed Motor Operation. Scheme 65

NS-17A: PERFORMING NO FAULT CODE MECHANICAL TEST

At this point in the start-and-stall test procedure, if it is determined that all engine control systems are operating as designed and are not the cause of a no start-and-stall problem, the following additional items should be checked as possible causes

1. Check if any TECHNICAL SERVICE BULLETINS (TSBs) apply to vehicle.
2. Check engine vacuum.
3. Check engine compression.
4. Check for exhaust system restriction.
5. Check camshaft and crankshaft sprockets.
6. Check valve timing.
7. Check torque converter stall speed.
8. Check secondary ignition circuit for abnormal scope pattern.
9. Check for fuel contamination.
10. Ensure PCV system is functioning properly.

DRIVEABILITY DIAGNOSTIC FLOW CHARTS DR-1A TO DR-45A

Note. The following trouble shooting charts and illustrations are courtesy of Chrysler Motors.

DR-1A: CHECKING SYSTEM FOR FAULTS

Note. Battery must be fully charged and at rated capacity before performing any driveability test procedure. If vehicle starts and stalls repeatedly, perform test NS-3A: CHECKING FOR INJECTOR FAULTS, POWER TO ENGINE CONTROLLER, MAP SENSOR & THEFT ALARM STATUS.

1. Connect DRB-II to engine diagnostic connector. Read fault messages. If DRB-II displays fault messages, go to DR-1B: DRB-II FAULT MESSAGES. Go to step 9) if DRB-II displays ENGINE COLD TOO LONG. If DRB-II displays INTERNAL CONTROLLER FAILURE, go to step 8). If DRB-II displays NO FAULTS, go to next step.
2. If NO FAULTS message appears on DRB-II display, start engine. Allow engine to reach normal operating temperature. Set engine speed manually ( DO NOT use DRB-II to set speed) to 2000 RPM for about 10 seconds. Return engine to idle.
3. If vehicle is not equipped with A/C, go to step 5). If vehicle is equipped with A/C, put A/C fan on low speed. Turn A/C on. If engine stalls when A/C is turned on, turn ignition switch off.
4. Disconnect engine controller connector. Inspect engine controller connector for corroded or loose terminals. Repair as required. Turn ignition switch on. Put DRB-II in voltmeter mode.
5. Probe engine controller connector DB (Dark/Blue ) wire at cavity No. 9. If voltage is less than 10 volts, repair DB wire. If voltage is more than 10 volts, replace engine controller. Perform test VER-2: VERIFICATION PROCEDURE 2.
6. If vehicle is equipped with A/T, apply brakes and shift through all gears. Return shift lever to Park. Read fault messages displayed on DRB-II.
7. If DRB-II still shows NO FAULTS, check TECHNICAL SERVICE BULLETINS for any pertinent information relating to driveability problems. If a TSB exists, perform corrective action. If driveability problem continues after performing TSB procedure or if no TSB information is found, perform test DR-30A: CHECKING SECONDARY IGNITION & TIMING.
8. If INTERNAL CONTROLLER FAILURE message appears on DRB-II display, replace engine controller. Perform test VER-2: VERIFICATION PROCEDURE 2.
9. If ENGINE COLD TOO LONG message appears on DRB-II display, check engine cooling system. Repair as required. Perform test VER-3: VERIFICATION PROCEDURE 3.

DR-1B: DRB-II FAULT MESSAGES

Using the DRB-II FAULT MESSAGES table, select the fault message and corresponding test. Correct all hard fault messages before proceeding to intermittent fault message.

DRB-II FAULT MESSAGES

Test DR-2A, Code 13: (1 of 2) Slow Change In Idle MAP Signal. Scheme 66

Test DR-2A, Code 13: (2 of 2) Slow Change In Idle MAP Signal. Scheme 67

Test DR-3A, Code 13, No Change In MAP From Start To Run. Scheme 68

Test DR-4A, Code 14: MAP Voltage Too Low. Scheme 69

Test DR-5A, Code 14: (1 of 2) MAP Voltage Too High. Scheme 70

Test DR-5A, Code 14: (2 of 2) MAP Voltage Too High. Scheme 71

Test DR-6A, Ckt Diag. Code 15, No Vehicle Speed Signal. Scheme 72

Test DR-6A, Code 15: (1 of 3) No Vehicle Speed Signal. Scheme 73

Test DR-6A, Code 15: (2 of 3) No Vehicle Speed Signal. Scheme 74

Test DR-6A, Code 15: (3 of 3) No Vehicle Speed Signal. Scheme 75

Test DR-7A, Ckt Diag. Code 21, O2 Signal Stays At Center. Scheme 76

Test DR-7A, Code 21: (1 of 2) O2 Signal Stays At Center. Scheme 77

Test DR-7A, Code 21: (2 of 2) O2 Signal Stays At Center. Scheme 78

Test DR-8A, Code 21: (1 of 2) O2 Signal Shorted To Voltage. Scheme 79

Test DR-8A, Code 21: (2 of 2) O2 Signal Shorted To Voltage. Scheme 80

Test DR-9A, Ckt Diag. Code 22, Coolant Sensor Voltage High. Scheme 81

Test DR-9A, Code 22: (1 of 2) Coolant Sensor Voltage High. Scheme 82

Test DR-9A, Code 22: (2 of 2) Coolant Sensor Voltage High. Scheme 83

Test DR-10A, Code 22: Coolant Sensor Voltage Low. Scheme 84

Test DR-11A, Code 23: Ckt Diag. Throttle Body Temp High. Scheme 85

Test DR-11A, Code 23: (1 of 2) Throttle Body Temp High. Scheme 86

Test DR-11A, Code 23: (2 of 2) Throttle Body Temp High. Scheme 87

Test DR-12A, Code 23: Throttle Body Temp Low. Scheme 88

Test DR-13A, Code 24: Ckt Diag. TPS Voltage High. Scheme 89

Test DR-13A, Code 24: (1 of 2) TPS Voltage High. Scheme 90

Test DR-13A, Code 24: (2 of 2) TPS Voltage High. Scheme 91

Test DR-14A, Code 24: TPS Voltage Low. Scheme 92

Test DR-15A, Code 25: (1 of 4) AIS Motor Circuits. Scheme 93

Test DR-15A, Code 25: (2 of 4) AIS Motor Circuits. Scheme 94

Test DR-15A, Code 25: (3 of 4) AIS Motor Circuits. Scheme 95

Test DR-15A, Code 25: (4 of 4) AIS Motor Circuits. Scheme 96

Test DR-16A, Code 31: Ckt Diag. Purge Solenoid Circuit. Scheme 97

Test DR-16A, Code 31: (1 of 3) Purge Solenoid Circuit. Scheme 98

Test DR-16A, Code 31: (2 of 3) Purge Solenoid Circuit. Scheme 99

Test DR-16A, Code 31: (3 of 3) Purge Solenoid Circuit. Scheme 100

Test DR-17A, Code 32: Ckt Diag. EGR Solenoid Circuit. Scheme 101

Test DR-17A, Code 32: (1 of 3) EGR Solenoid Circuit. Scheme 102

Test DR-17A, Code 32: (2 of 3) EGR Solenoid Circuit. Scheme 103

Test DR-17A, Code 32: (3 of 3) EGR Solenoid Circuit. Scheme 104

Test DR-18A, Code 32: (1 of 5) EGR System Failure. Scheme 105

Test DR-18A, Code 32: (2 of 5) EGR System Failure. Scheme 106

Test DR-18A, Code 32: (3 of 5) EGR System Failure. Scheme 107

Test DR-18A, Code 32: (4 of 5) EGR System Failure. Scheme 108

Test DR-18A, Code 32: (5 of 5) EGR System Failure. Scheme 109

Test DR-18B, Code 32: (1 of 5) EGR System Failure. Scheme 110

Test DR-18B, Code 32: (2 of 5) EGR System Failure. Scheme 111

Test DR-18B, Code 32: (3 of 5) EGR System Failure. Scheme 112

Test DR-18B, Code 32: (4 of 5) EGR System Failure. Scheme 113

Test DR-18B, Code 32: (5 of 5) EGR System Failure. Scheme 114

Test DR-18C, Code 32: EGR System Failure. Scheme 115

Test DR-19A, Code 33: (1 of 4) A/C Clutch Relay Circuit. Scheme 116

Test DR-19A, Code 33: (2 of 4) A/C Clutch Relay Circuit. Scheme 117

Test DR-19A, Code 33: (3 of 4) A/C Clutch Relay Circuit. Scheme 118

Test DR-19A, Code 33: (4 of 4) A/C Clutch Relay Circuit. Scheme 119

Test DR-20A, Code 33: (1 of 2) A/C Clutch Relay Circuit. Scheme 120

Test DR-20A, Code 33: (2 of 2) A/C Clutch Relay Circuit. Scheme 121

Test DR-21A, Code 33: (1 of 2) A/C Clutch Relay Circuit. Scheme 122

Test DR-21A, Code 33: (2 of 2) A/C Clutch Relay Circuit. Scheme 123

Test DR-22A, Code 33: (1 of 2) A/C Clutch Relay Circuit. Scheme 124

Test DR-22A, Code 33: (2 of 2) A/C Clutch Relay Circuit. Scheme 125

Test DR-23A, Code 33: (1 of 3) A/C Clutch Relay Circuit. Scheme 126

Test DR-23A, Code 33: (2 of 3) A/C Clutch Relay Circuit. Scheme 127

Test DR-23A, Code 33: (3 of 3) A/C Clutch Relay Circuit. Scheme 128

Test DR-24A, Code 35: Ckt Diag. Radiator Fan Relay Circuit. Scheme 129

Test DR-24A, Code 35: (1 of 4) Radiator Fan Relay Circuit. Scheme 130

Test DR-24A, Code 35: (2 of 4) Radiator Fan Relay Circuit. Scheme 131

Test DR-24A, Code 35: (3 of 4) Radiator Fan Relay Circuit. Scheme 132

Test DR-24A, Code 35: (4 of 4) Radiator Fan Relay Circuit. Scheme 133

Test DR-25A, Code 35: (1 of 2) Radiator Fan Relay Circuit. Scheme 134

Test DR-25A, Code 35: (2 of 2) Radiator Fan Relay Circuit. Scheme 135

Test DR-26A, Code 35: (1 of 2) Radiator Fan Relay Circuit. Scheme 136

Test DR-26A, Code 35: (2 of 2) Radiator Fan Relay Circuit. Scheme 137

Test DR-27A, Code 35: (1 of 2) Radiator Fan Relay Circuit. Scheme 138

Test DR-27A, Code 35: (2 of 2) Radiator Fan Relay Circuit. Scheme 139

Test DR-28A, Code 37: Ckt Diag. Torque Converter Lock-Up Solenoid. Scheme 140

Test DR-28A, Code 37: (1 of 3) Torque Converter Lock-Up Solenoid. Scheme 141

Test DR-28A, Code 37: (2 of 3) Torque Converter Lock-Up Solenoid. Scheme 142

Test DR-28A, Code 37: (3 of 3) Torque Converter Lock-Up Solenoid. Scheme 143

Test DR-29A, Code 63: (1 of 2) SBEC Failure EMR Mileage Not Stored & EEPROM Write Denied. Scheme 144

Test DR-29A, Code 63: (2 of 2) SBEC Failure EMR Mileage Not Stored & EEPROM Write Denied. Scheme 145

Test DR-30A: (1 of 2) Secondary Ignition & Timing. Scheme 146

Test DR-30A: (2 of 2) Secondary Ignition & Timing. Scheme 147

Test DR-31A: (1 of 2) Fuel Pressure. Scheme 148

Test DR-31A: (2 of 2) Fuel Pressure. Scheme 149

Test DR-31B: (1 of 2) Fuel Pressure. Scheme 150

Test DR-31B: (2 of 2) Fuel Pressure. Scheme 151

Test DR-32A: (1 of 2) Coolant & TPS Sensor Calibration. Scheme 152

Test DR-32A: (2 of 2) Coolant & TPS Sensor Calibration. Scheme 153

Test DR-33A: (1 of 2) MAP Sensor Calibration. Scheme 154

Test DR-33A: (2 of 2) MAP Sensor Calibration. Scheme 155

Test DR-34A: Oxygen Sensor Switching. Scheme 156

Test DR-34B: (1 of 2) Oxygen Sensor Switching. Scheme 157

Test DR-34B: (2 of 2) Oxygen Sensor Switching. Scheme 158

Test DR-35A: Ckt Diag. Idle Speed Motor Operation. Scheme 159

Test DR-35A: (1 of 2) Idle Speed Motor Operation. Scheme 160

Test DR-35A: (2 of 2) Idle Speed Motor Operation. Scheme 161

Test DR-35B: Idle Speed Motor Operation. Scheme 162

Test DR-35C: Idle Speed Motor Operation. Scheme 163

Test DR-35D: Idle Speed Motor Operation. Scheme 164

Test DR-35E: Idle Speed Motor Operation. Scheme 165

Test DR-36A: Ckt Diag. Park/Neutral Switch Operation. Scheme 166

Test DR-36A: (1 of 2) Park/Neutral Switch Operation. Scheme 167

Test DR-36A: (2 of 2) Park/Neutral Switch Operation. Scheme 168

Test DR-37A: Ckt Diag. SBEC Grounds & Power Circuits. Scheme 169

Test DR-37A: (1 of 2) SBEC Grounds & Power Circuits. Scheme 170

Test DR-37A: (2 of 2) SBEC Grounds & Power Circuits. Scheme 171

Test DR-38A: (1 of 2) EGR Operation Federal Emissions. Scheme 172

Test DR-38A: (2 of 2) EGR Operation Federal Emissions. Scheme 173

Test DR-38B: EGR Operation Federal Emissions. Scheme 174

Test DR-38C: (1 of 5) EGR Operation Federal Emissions. Scheme 175

Test DR-38C: (2 of 5) EGR Operation Federal Emissions. Scheme 176

Test DR-38C: (3 of 5) EGR Operation Federal Emissions. Scheme 177

Test DR-38C: (4 of 5) EGR Operation Federal Emissions. Scheme 178

Test DR-38C: (5 of 5) EGR Operation Federal Emissions. Scheme 179

Test DR-39A: Ckt Diag. Engine Vacuum. Scheme 180

Test DR-40A: (1 of 2) Engine Vacuum. Scheme 181

Test DR-40A: (2 of 2) Engine Vacuum. Scheme 182

DR-41A: PERFORMING NO FAULT CODE MECHANICAL TEST

At this point in the driveability test procedure, if it is determined that all engine control systems are operating as designed and are not the cause of driveability problem, check the following additional items for possible causes

1. Check valve timing.
2. Check torque converter stall speed.
3. Check engine compression.
4. Check camshaft and crankshaft sprockets.
5. Check for internal power brake booster vacuum leaks.
6. Check for fuel contamination.
7. Check for exhaust system restriction.
8. Ensure injectors are not plugged or restricted.
9. Ensure injector control wire is connected to correct injector.
10. Ensure engine vacuum is at least 13 in. Hg.
11. Ensure PCV system is functioning properly.

Test DR-42A: Intermittent Test For Solenoids & Relays. Scheme 183

Test DR-43A: Intermittent Voltage Sensor. Scheme 184

Test DR-43B: Intermittent Test For MAP Sensor Signal Change. Scheme 185

Test DR-44A: Intermittent Test For Idle Motor Circuits. Scheme 186

Test DR-45A: Intermittent Test For Injector Circuits. Scheme 187

VER-1: VERIFICATION PROCEDURE 1

1. Inspect vehicle to ensure all components are connected. Reassemble and reconnect components as necessary. Attempt to start engine. If engine does not start, return to test NS-1A: CHECKING FOR IGNITION SPARK & POWER FEED TO COIL.
2. If engine starts and engine controller has been changed, go to next step. If engine starts and engine controller has not been changed, connect DRB-II to engine diagnostic connector and erase faults. Repair is now complete.
3. If vehicle is equipped with factory theft alarm system, start engine about 20 times to activate theft alarm system. If vehicle is an AS or AN body, write EMR mileage into the new engine controller. Repair is now complete.

VER-2: VERIFICATION PROCEDURE 2

1. If test VER-3: VERIFICATION PROCEDURE 3 has been performed previously, perform test VER-3 again. Inspect vehicle to ensure all engine components are connected. Reassemble and reconnect components as necessary.
2. If another fault exists that has not been corrected, return to DR-1B: DRB-II FAULT MESSAGES and follow path specified by other fault. If engine controller has been replaced and vehicle is equipped with factory theft alarm system, start engine about 20 times to activate theft alarm system. If vehicle is an AS or AN body, write EMR mileage into new engine controller.
3. Connect DRB-II to engine diagnostic connector and erase faults. Ensure no other faults are present. To ensure no other faults are present, start engine. Allow engine to reach normal operating temperature. Increase engine speed to 2000 RPM for about 10 seconds. Return engine to idle.
4. If vehicle is equipped with A/T, apply brakes and cycle through all transmission gear positions. Place gear selector in Park. If vehicle is equipped with A/C, turn A/C on. Set blower speed to LOW.
5. Turn engine off. Start engine. Allow engine to idle for about 2 minutes. Turn engine off. Using DRB-II, check for fault messages. If NO FAULT message appears on DRB-II display, test is complete.
6. If repaired fault resets or another fault sets, check TECHNICAL SERVICE BULLETINS for any pertinent information relating to problem. If a TSB exists, perform corrective action. If another fault sets, return to DR-1B: DRB-II FAULT MESSAGES.

VER-3: VERIFICATION PROCEDURE 3

1. Inspect vehicle to ensure all engine components are connected. Reassemble and reconnect components as necessary. If another fault is present that has not been corrected, return to DR-1B: DRB-II FAULT MESSAGES and follow path specified by other fault.
2. If engine controller has been changed and vehicle is equipped with factory theft alarm system, start engine about 20 times to activate theft alarm system. If vehicle is an AS or AN body, write EMR mileage into new engine controller.
3. Connect DRB-II to engine diagnostic connector. Erase fault messages. Disconnect DRB-II. Ensure no other fault messages are present. To ensure no other fault messages are present, start engine. If vehicle is equipped with A/C, turn A/C on. Set blower speed to LOW.
4. Drive vehicle for about 5 minutes. During this time, attain a speed above 40 MPH or more. Ensure transmission shifts through all gears. Upon completion of road test, turn engine off.
5. Start engine. Allow engine to idle for about 2 minutes. Turn engine off. Connect DRB-II to engine diagnostic connector. Using DRB-II, check for fault messages. If no fault messages are present, test is complete.
6. If repaired fault message resets or another fault message sets, check TECHNICAL SERVICE BULLETINS for any pertinent information relating to driveability problems. If a TSB exists, perform corrective action. If another fault sets, return to DR-1B: DRB-II FAULT MESSAGES.

SUMMARY

If no hard fault codes or only pass codes are present, driveability symptoms exist or intermittent codes exist, proceed to TESTS W/O CODES article for diagnosis by symptom (i.e. ROUGH IDLE, NO START, etc.) or intermittent diagnostic procedures in the ENGINE PERFORMANCE section.

See also:
• CLEARING CODES
• ENTERING ON-BOARD DIAGNOSTICS
• DRB-II PROBLEMS & ERROR MESSAGES
• DRB-II TEST FUNCTIONS
