Engine Controls - Specifications Dodge Spirit I

Specifications 7 illustrations ~585 words

INTRODUCTION

Note. Monaco and Premier models are manufactured with either an early or late design. Only late design models are covered in this article. Late design models are equipped with DIS, with engine controller (SBEC) located next to battery. Service procedures for early design models, with engine code Z7X711, are the same as those found in 1990 DOMESTIC SERVICE & REPAIR

Note. Shadow and Sundance Convertible models equipped with 2.5L TBI engine are manufactured with either early or late design fuel, ignition and emission systems. Late design vehicles use an epoxy ignition coil, mounted on thermostat housing, and a high pressure fuel system requiring quick-connect fuel fittings. Early design vehicles use an oil-filled ignition coil, mounted on right inner fender, and a low pressure fuel system using hoses and clamps.

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article for when you are familiar with proper adjustment procedures and only need a specification.

BATTERY SPECIFICATIONS

Application & GroupAmp. Hour Rating
All Models(1)
(1) Information not available from manufacturer.
(1)Information not available from manufacturer.

BATTERY SPECIFICATIONS

FLUID CAPACITIES - 4-CYLINDER

ApplicationQuantity
Crankcase (Includes Filter)
1.8L4.1 qts. (3.9L)
All 2.0L4.6 qts. (4.4L)
All 2.2L & 2.5L4.0 qts. (3.8L)
Cooling System (Includes Heater)
1.8L6.6 qts. (6.2L)
All 2.0L7.6 qts. (7.2L)
All 2.2L & 2.5L9.0 qts. (8.5L)
Manual Transaxle (SAE 5W-30 Engine Oil)
A-523, A-543 & A-5684.4 pts. (2.1L)
A-5254.6 pts. (2.2L)
Manual Transaxle (SAE 80W-90/API GL-4)
F5M22-1-VPKV (1)3.8 pts. (1.8L)
F5M22-2-VPZV (2)3.8 pts. (1.8L)
F5M33-2-SPZV (3)4.6 pts. (2.2L)
Automatic Transaxle (Dexron-II)
A-413 (3-Speed)
Except Fleet8.9 qts. (8.4L)
Fleet9.2 qts. (8.7L)
A-604 (4-Speed)9.1 qts. (8.6L)
Automatic Transaxle (Mopar ATF Plus)
F4A22-2-MPD (1)6.4 qts. (6.1L)
F4A22-2-MPD1 (2)6.4 qts. (6.1L)
F4A33-UP61 & W4A33-1-UP6 (3)8.0 qts. (7.6L)
(1) Used with 1.8L engine. (2) Used with 2.0L engine. (3) Used with 2.0L Turbo engine.
(1)Used with 1.8L engine.
(2)Used with 2.0L engine.
(3)Used with 2.0L Turbo engine.

FLUID CAPACITIES - 4-CYLINDER

FLUID CAPACITIES - V6

ApplicationQuantity
Crankcase (Includes Filter)
3.0L (VIN U) (1)6.0 qts. (5.7L)
3.0L (VIN 3), 3.3L & 3.8L4.0 qts. (3.8L)
Cooling System (Includes Heater)
3.0L (VIN U) (1)9.5 qts. (9.0L)
3.0L (VIN 3), 3.3L & 3.8L9.5 qts. (9.0L)
Manual Transaxle (SAE 5W-30 Engine Oil)
A-523, A-543 & A-5684.4 pts. (2.1L)
A-5254.6 pts. (2.2L)
Automatic Transaxle (Dexron-II)
A-413 (3-Speed)
Except Fleet8.9 qts. (8.4L)
Fleet9.2 qts. (8.7L)
A-604 (4-Speed)9.1 qts. (8.6L)
Automatic Transaxle (Mopar-Mercon)
ZF-4(2) 5.6 pts. (2.6L)
Differential (SAE 75W-140 Synthetic) (3)
ZF-41.3 pts. (0.7L)
(1) Used in Monaco and Premier. (2) For dry refill add 7.4 qts. (7.0L). (3) Synthetic fluid does not require replacement.
(1)Used in Monaco and Premier.
(2)For dry refill add 7.4 qts. (7.0L).
(3)Synthetic fluid does not require replacement.

FLUID CAPACITIES - V6

SERVICE INTERVALS & SPECIFICATIONS - 4-CYLINDER

ComponentInterval (Miles)
1.8L & All 2.0L
Air Filter30,000
Coolant30,000
Fuel Filter50,000
Oil(1) 7500
Oil Filter10,000
Spark Plugs30,000
Timing Belt(2) 60,000
All 2.2L & 2.5L
Air Filter15,000
Coolant(3) 52,500
Fuel Filter(4)
Oil(5) 7500
Oil Filter7500
Spark Plugs48,000
(1) Every 5000 miles on 2.0L Turbo. (2) Including balancer belt. (3) Every 30,000 thereafter. (4) Replace only if fuel contamination problem is suspected. (5) Every 3000 miles if SG grade oil is used.
(1)Every 5000 miles on 2.0L Turbo.
(2)Including balancer belt.
(3)Every 30,000 thereafter.
(4)Replace only if fuel contamination problem is suspected.
(5)Every 3000 miles if SG grade oil is used.

REPLACEMENT INTERVALS - 4-CYLINDER

SERVICE INTERVALS & SPECIFICATIONS - V6

ComponentInterval (Miles)
3.0L (VIN 3), 3.3L & 3.8L
Air Filter15,000
Coolant(1) 52,500
Fuel Filter(2)
Oil(3) 7500
Oil Filter7500
Spark Plugs48,000
3.0L (VIN U) (4)
Air Filter15,000
Coolant30,000
Fuel Filter30,000
Oil7500
Oil & Filter7500
Spark Plugs30,000
(1) Every 30,000 thereafter. (2) Replace only if fuel contamination problem is suspected. (3) Every 3000 miles if SG grade oil is used. (4) Used in Monaco and Premier.
(1)Every 30,000 thereafter.
(2)Replace only if fuel contamination problem is suspected.
(3)Every 3000 miles if SG grade oil is used.
(4)Used in Monaco and Premier.

REPLACEMENT INTERVALS - V6

DRIVE BELT ADJUSTMENT - 1.8L & 2.0L 4-CYLINDER

Application(1) Deflection: In. (mm)
1.8L
Alternator/Water Pump.32-.43 (8.0-11.0)
A/C Compressor
New.16-.22 (4.0-5.5)
Used.22-.24 (5.5-6.0)
All 2.0L
A/C Compressor
New.18-.22 (4.5-5.5)
Used.22-.24 (5.5-6.0)
Alternator/Water Pump.35-.45 (9.0-11.5)
(1) With 22 lbs. (10 kg) pressure applied midway on longest belt run.
(1)With 22 lbs. (10 kg) pressure applied midway on longest belt run.

BELT ADJUSTMENT - 1.8L & 2.0L 4-CYLINDER

DRIVE BELT ADJUSTMENT - 2.2L & 2.5L 4-CYLINDER

Application(1) Tension
2.2L TBI & All 2.5L
A/C Compressor
New Belt125 (56.7)
Used Belt80 (36.3)
Alternator/Water Pump
New Belt130 (58.9)
Used Belt80 (36.3)
Power Steering Pump
New Belt105 (47.6)
Used Belt80 (36.3)
2.2L Turbo Serpentine Belt(2) *
(1) Using belt tension gauge. (2) Belt tension is maintained by dynamic tensioner.
(1)Using belt tension gauge.
(2)Belt tension is maintained by dynamic tensioner.

BELT ADJUSTMENT - 2.2L & 2.5L 4-CYLINDER

DRIVE BELT ADJUSTMENT - V6

Application(1) Tension
3.0L (VIN U) (2)
New Belt180-200 (81.6-90.7)
Used Belt140-160 (63.5-72.6)
3.0L (VIN 3)
A/C Compressor
New Belt125 (56.7)
Used Belt80 (36.3)
Serpentine Belt(3) *
3.3L & 3.8L(3) *
(1) Using belt tension gauge. (2) Used in Monaco and Premier. (3) Belt tension is maintained by dynamic tensioner.
(1)Using belt tension gauge.
(2)Used in Monaco and Premier.
(3)Belt tension is maintained by dynamic tensioner.

BELT ADJUSTMENT - V6

ENGINE COMPRESSION - 4-CYLINDER

Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed and throttle wide open.

ApplicationSpecification
Compression Ratio
1.8L PFI9.0:1
2.0L PFI9.0:1
2.0L Turbo7.8:1
2.2L TBI9.5:1
2.2L Turbo8.1:1
2.5L TBI8.9:1
2.5L Turbo7.8:1
Minimum Compression Pressure
1.8L(1) 131 psi (9.2 kg/cm 2 )
2.0L(1) 137 psi (9.6 kg/cm 2 )
2.0L Turbo(1) 114 psi (8.1 kg/cm 2 )
All 2.2L & 2.5L(2) 100 psi (7.0 kg/cm 2 )
(1) Maximum difference between each cylinder should not exceed 14 psi (.98 kg/cm 2 ). (2) Maximum difference between each cylinder should not exceed 25 percent.
(1)Maximum difference between each cylinder should not exceed 14 psi (.98 kg/cm 2 ).
(2)Maximum difference between each cylinder should not exceed 25 percent.

COMPRESSION SPECIFICATIONS - 4-CYLINDER

ENGINE COMPRESSION - V6

Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed and throttle wide open.

ApplicationSpecification
Compression Ratio
3.0L (VIN U) (1)9.3:1
3.0L (VIN 3)8.85:1
3.3L8.9:1
3.8L8.9:1
Minimum Compression Pressure
3.0L (VIN U) (1) , 3.3L & 3.8L(2) 100 psi (7.0 kg/cm 2 )
3.0L (VIN 3)(2) 178 psi (12.5 kg/cm 2 )
(1) Used in Monaco and Premier. (2) Maximum difference between each cylinder should not exceed 25 percent.
(1)Used in Monaco and Premier.
(2)Maximum difference between each cylinder should not exceed 25 percent.

COMPRESSION SPECIFICATIONS - V6

VALVE CLEARANCE

Note. Hydraulic lifters are used. No adjustments are required.

IGNITION COIL - 4-CYLINDER

ApplicationPrimarySecondary
1.8L0.9-1.219,000-27,000
All 2.0L.77-.9510,300-13,900
2.2L TBI & All 2.5L
Epoxy Filled
Diamond (1).97-1.1811,300-15,300
Toyo Denso (1).95-1.2011,300-13,300
Oil Filled
Diamond (1)1.34-1.5515,000-19,000
Essex (1)1.34-1.559000-12,200
Prestolite (1)1.34-1.559400-11,700
2.2L Turbo.52-.6311,600-15,800
(1) Resistance measured at 70-80°F (21-27°C).
(1)Resistance measured at 70-80°F (21-27°C).

IGNITION COIL RESISTANCE - 4-CYLINDER (Ohms @ 68°F (20°C))

IGNITION COIL - V6

ApplicationPrimarySecondary
3.0L (VIN U) (1)
Diamond.45-.657000-14,000
Marshall.45-.657000-14,000
3.0L (VIN 3)
Diamond (Epoxy).97-1.1811,000-15,300
3.3L & 3.8L
Diamond.52-.6311,600-15,800
Toyo Denso.51-.6111,500-13,500
(1) Used in Monaco and Premier.
(1)Used in Monaco and Premier.

IGNITION COIL RESISTANCE - V6 (Ohms @ 70-80°F (21-27°C))

HIGH TENSION WIRE RESISTANCE

Application (1)Ohms
All Models30,000 Maximum
(1) Not applicable to direct ignition systems.
(1)Not applicable to direct ignition systems.

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS - 4-CYLINDER

ApplicationChampion No.
1.8L PFI & 2.0L PFIRN9YC4
2.0L Turbo & 2.2L TurboRN9YC
2.2L TBI & All 2.5LRN12YC

SPARK PLUG TYPE - 4-CYLINDER

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
1.8L PFI & 2.0L PFI.041 (1.00)18 (24)
2.0L Turbo.030 (.76)18 (24)
All 2.2L & 2.5L.035 (.89)20 (28)

SPARK PLUG SPECIFICATIONS - 4-CYLINDER

SPARK PLUGS - V6

ApplicationChampion No.
3.0L (VIN U) (1)RS9YCX
3.0L (VIN 3)RN11YC4
3.3L & 3.8LRN16YC5
(1) Used in Monaco and Premier.
(1)Used in Monaco and Premier.

SPARK PLUG TYPE - V6

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
3.0L (VIN U) (1).035 (.89)11 (15)
3.0L (VIN 3).041 (1.00)20 (28)
3.3L & 3.8L.050 (1.27)20 (28)
(1) Used in Monaco and Premier.
(1)Used in Monaco and Premier.

SPARK PLUG SPECIFICATIONS - V6

IGNITION TIMING - 4-CYLINDER

ApplicationBase(1) Actual
1.8L5 @ 600-80010 @ 600-800
All 2.0L5 @ 650-8508 @ 650-850
(1) If altitude is more than 2300 feet above sea level, actual timing may be advanced.
(1)If altitude is more than 2300 feet above sea level, actual timing may be advanced.

IGNITION TIMING - 1.8L & 2.0L 4-CYLINDER (Degrees BTDC @ RPM)

ApplicationMan. Trans.Auto. Trans.
2.2L & 2.5L TBI12 @ 85012 @ 850
2.2L Turbo(1)(1)
2.5L Turbo12 @ 95012 @ 900
(1) Ignition timing on 2.2L Turbo engine is computer- controlled and is not adjustable.
(1)Ignition timing on 2.2L Turbo engine is computer- controlled and is not adjustable.

IGNITION TIMING - ALL OTHER 4-CYLINDER (Degrees BTDC @ RPM)

Firing Order/Distributor Rotation (1.8L & 2.2L Turbo). Scheme 1

Scheme 1: Firing Order/Distributor Rotation (1.8L & 2.2L Turbo)
Scheme 1: Firing Order/Distributor Rotation (1.8L & 2.2L Turbo)

Firing Order/Distributor Rotation (2.0L). Scheme 2

Scheme 2: Firing Order/Distributor Rotation (2.0L)
Scheme 2: Firing Order/Distributor Rotation (2.0L)

Firing Order & Distributor Rotation (2.2L, All 2.5L). Scheme 3

Scheme 3: Firing Order & Distributor Rotation (2.2L, All 2.5L)
Scheme 3: Firing Order & Distributor Rotation (2.2L, All 2.5L)

IGNITION TIMING - V6

ApplicationMan. Trans.Auto. Trans.
3.0L (VIN U)(1)(1)
3.0L (VIN 3)12 @ 80012 @ 700
3.3L & 3.8L(2)(2)
(1) Used in Monaco and Premier. Engine controller determines ignition timing. No adjustment is possible. (2) Ignition timing on 3.3L and 3.8L engine is computer- controlled and is not adjustable.
(1)Used in Monaco and Premier. Engine controller determines ignition timing. No adjustment is possible.
(2)Ignition timing on 3.3L and 3.8L engine is computer- controlled and is not adjustable.

IGNITION TIMING - V6 (Degrees BTDC @ RPM)

WARNINGOn the 3.0L V6, the firing order and the spark plug connection order on the top of the distributor do not match. Circuits internal to the distributor cap differ from the external spark plug wire connections. This is intentional and is done to avoid spark plug wires crossover. (Scheme 4)

Firing Order & Distributor Rotation (3.0L - VIN 3). Scheme 4

Scheme 4: Firing Order & Distributor Rotation (3.0L - VIN 3)
Scheme 4: Firing Order & Distributor Rotation (3.0L - VIN 3)

Firing Order (3.0L - VIN U). Scheme 5

Scheme 5: Firing Order (3.0L - VIN U)
Scheme 5: Firing Order (3.0L - VIN U)

Scheme 6

Scheme 6: Firing Order (3.3L & 3.8L)
Scheme 6: Firing Order (3.3L & 3.8L)

FUEL PUMP - 4-CYLINDER

Note. Fuel pump performance measures fuel pressure and fuel volume, not regulated fuel pressure.

ApplicationPressure psi (kg/cm 2 )
1.8L & All 2.0L(1)
All 2.2L & All 2.5L(2) 39 (2.7)
(1) Information not available from manufacturer. See 4-CYLINDER FUEL PRESSURE REGULATOR PERFORMANCE table in this article. (2) Except early Shadow convertible. Early Shadow convertible specification is 14.5 psi (1.0 kg/cm 2 ).
(1)Information not available from manufacturer. See 4-CYLINDER FUEL PRESSURE REGULATOR PERFORMANCE table in this article.
(2)Except early Shadow convertible. Early Shadow convertible specification is 14.5 psi (1.0 kg/cm 2 ).

FUEL PUMP PERFORMANCE - 4-CYLINDER

FUEL PUMP - V6

Note. Fuel pump performance measures fuel pressure and fuel volume, not regulated fuel pressure.

ApplicationPressure psi (kg/cm 2 )
3.0L (VIN U) (1)138 (9.7)
3.0L (VIN 3), 3.3L & 3.8L135 (9.5)
(1) Used in Monaco and Premier.
(1)Used in Monaco and Premier.

FUEL PUMP PERFORMANCE - V6

FUEL PRESSURE REGULATOR PERFORMANCE - 4-CYLINDER

ApplicationPressure psi (kg/cm 2 )
1.8L & 2.0L
W/Vacuum Hose Connected38 (2.7)
W/Vacuum Hose Disconnected47-50 (3.3-3.5)
2.0L Turbo
Manual Transmission
W/Vacuum Hose Connected27 (1.9)
W/Vacuum Hose Disconnected36-38 (2.5-2.7)
Automatic Transmission
W/Vacuum Hose Connected33 (2.3)
W/Vacuum Hose Disconnected41-46 (2.9-3.2)
2.2L TBI & 2.5L TBI(1) 39 (2.7)
2.2L Turbo & 2.5L Turbo55 (3.9)
(1) Regulated fuel pressure on early Shadow/Sundance convertible is 14.5 psi (1.0 kg/cm 2 ).
(1)Regulated fuel pressure on early Shadow/Sundance convertible is 14.5 psi (1.0 kg/cm 2 ).

FUEL PRESSURE REGULATOR PERFORMANCE - 4-CYLINDER

FUEL PRESSURE REGULATOR PERFORMANCE - V6

ApplicationPressure psi (kg/cm 2 )
3.0L (VIN 3), 3.3L & 3.8L48 (3.4)
3.0L (VIN U) (1)43 (3.0)
(1) Used in Monaco and Premier.
(1)Used in Monaco and Premier.

FUEL PRESSURE REGULATOR PERFORMANCE - V6

INJECTOR RESISTANCE

ApplicationOhms
1.8L & 2.0L PFI13-16
2.0L Turbo2-3
2.5L2-4
3.0L (VIN U) (2)2.4
(1) Resistance measured at 70-80°F (21-27°C). (2) Used in Monaco and Premier.
(1)Resistance measured at 70-80°F (21-27°C).
(2)Used in Monaco and Premier.

INJECTOR RESISTANCE SPECIFICATIONS (1)

IDLE SPEED & MIXTURE

ApplicationCurb IdleBasic Idle
1.8L600-800650-750
All 2.0L650-850700-800
(1) Minimum airflow rate specifications not available from manufacturer.
(1)Minimum airflow rate specifications not available from manufacturer.

IDLE SPEED SPECIFICATIONS (1)

ApplicationRPM
2.2L TBI1100-1300
2.2L Turbo550-900
2.5L TBI1050-1250
2.5L Turbo650-1200

MINIMUM AIRFLOW RATE SPECIFICATIONS - 4-CYLINDER

ApplicationRPM
3.0L (VIN U) (1)
Neutral625-725
Drive565-665
3.0L (VIN 3)750-950
3.3L & 3.8L700-950
(1) Used in Monaco and Premier.
(1)Used in Monaco and Premier.

MINIMUM AIRFLOW RATE SPECIFICATIONS - V6

THROTTLE POSITION SENSOR VOLTAGE TEST - 4-CYLINDER

TerminalsVolts
1.8L & All 2.0L (1).4-.6
All 2.2L & All 2.5L (2)
At Idle1.5
At Wide Open Throttle3.4
(1) Connect digital volt-ohm meter (DVOM) between Electronic Control Unit (ECU) terminals No. 19 and No. 24. (Scheme 7) (2) Measure voltage at throttle position sensor center terminal.
(1)Connect digital volt-ohm meter (DVOM) between Electronic Control Unit (ECU) terminals No. 19 and No. 24. (Scheme 7)
(2)Measure voltage at throttle position sensor center terminal.

THROTTLE POSITION SENSOR VOLTAGE TEST - 4-CYLINDER

THROTTLE POSITION SENSOR VOLTAGE TEST - V6

TerminalsVolts
3.0L (VIN U) (1)
At Idle0.5
At Wide Open Throttle4.5
3.0L (VIN 3), 3.3L & 3.8L (2)
At Idle1.5
At Wide Open Throttle3.4
(1) Used on Monaco and Premier. Backprobe TPS connector terminal "B" to ground. Terminals are marked on sensor connector. (Scheme 7) (2) Measure voltage at throttle position sensor center terminal.
(1)Used on Monaco and Premier. Backprobe TPS connector terminal "B" to ground. Terminals are marked on sensor connector. (Scheme 7)
(2)Measure voltage at throttle position sensor center terminal.

THROTTLE POSITION SENSOR VOLTAGE TEST - V6

Scheme 7

Scheme 7
Scheme 7
