FRAME & UNDERBODY
Note. These illustrations are not intended to represent exact structure of each vehicle's frame, underbody or body outline. They are presented only to give the mechanic some point of reference.
The following illustrations indicate areas (parts) of the underbody and frame which may be used to raise and support the vehicle, using either floor jack or hoist. These points are indicated by shaded areas on the frame. (Scheme 6)- (Scheme 10).
OUTERBODY
Those points designated on the outline of the body were specifically designed to facilitate the use of the vehicle's own jack. These jacking points are indicated by circular dots on the outline of the body. (Scheme 6)- (Scheme 10). If floor jack or hoist is employed, extreme care should be exercised to avoid damaging the outer body shell.
