Power Windows: Removal & Installation Dodge Ram Wagon B1500

REMOVAL & INSTALLATION

1. Disconnect and isolate the battery negative cable.
2. Remove the end cap from the driver side end of the instrument panel.
3. Unplug the circuit breaker from the junction block. see scheme 1
4. Install the circuit breaker by aligning its terminals with the cavities in the junction block and pushing the circuit breaker firmly into place.
5. Connect the battery negative cable.
6. Test the circuit breaker operation.
7. To install, reverse removal procedure.

1. Disconnect and isolate the battery negative cable.
2. Remove the mirror flag bezel from the inside of the front door.
3. From the back side of the mirror flag bezel, remove the screws that secure the power window and power lock switch and mounting plate unit to the mirror flag bezel. (Scheme 2)
4. Remove the power window and power lock switch and mounting plate unit from the mirror flag bezel.
5. With a small thin-blade screwdriver, gently pry the snap clips at the sides of the power window switch receptacle on the back of the switch mounting plate and pull the switch out of the receptacle.
6. To install, reverse removal procedures. Be sure that both of the switch snap retainers in the receptacle on the back of the switch mounting plate are fully engaged. Tighten the mounting screws to 20 INCH lbs. (2.2 N.m)

Scheme 2

1. Disconnect and isolate the battery negative cable.
2. Remove the trim panel from the inside of the front door.
3. Disengage the power window motor wire harness connector retainer from the mounting hole on the front door module and unplug the connector. (Scheme 3)
4. Remove the three screws that secure the power window motor and mechanism to the front door module.
5. Remove the power window motor and mechanism from the front door module.
6. To install, reverse the removal procedure. Tighten the mounting screws to 98 INCH lbs. (11 N.m).

Scheme 3
