POWER DISTRIBUTION CENTER
| CAUTION | When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
The power distribution center is located under the hood near the battery. For component location (Scheme 1) For power distribution center fuse identification, see POWER DISTRIBUTION CENTER FUSE IDENTIFICATION table. For power distribution center fuse location (Scheme 2)
| Fuse (Amp) | Application |
|---|---|
| 1 (140) | Generator |
| 1/2 (30) | Van Conversion Provision & Power Outlet |
| 3 (40) | Controller Anti-Lock Brake |
| 4 (50) | HVAC, Ign. Run Relay & Blower Motor |
| 5 (20) | A/C Compressor Clutch Relay & Engine Starter Motor Relay |
| 6 (40) | Rear Window Defogger Switch |
| 7 (40) | Rear A/C Heater Unit |
| 8 (30) | Daytime Running Lamp Module, Headlamp Switch & Headlamp Relay |
| 9/10 (40) | Van Conversion Accessary Power Relay |
| 11 (20) | Junction Block |
| 12 (40) | Ignition Switch |
| 13 (20) | Brake Lamp Switch |
| 14 (40) | Junction Block |
| 15 (20) | Fuel Pump Relay |
| 16 (40) | Ignition Switch |
| 17/18 (20) | Transmission Control Relay & Powertrain Control Module |
| 19/20 (10) | Oxygen Sensors, Fuel Injectors No. 1-8 & Ignition Coil |
POWER DISTRIBUTION CENTER FUSE IDENTIFICATION
Scheme 1
Scheme 2
JUNCTION BLOCK
The junction block is located behind the access door on the left end of the instrument panel support.For component location (Scheme 3) For fuse identification, see JUNCTION BLOCK FUSE IDENTIFICATION table. For junction block fuse location (Scheme 4)
| Fuse (Amp) | Application |
|---|---|
| 1 (20) | Horn Relay |
| 2 (10) | Blend Door Actuator, A/C Heater Control, A/C Cycling Switch, A/C Compressor Clutch Relay, HVAC Ignition Run Relay & High Blower Relay |
| 3 (10) | Controller Anti-Lock Brake |
| 4 (20) | Central Timer Module, Power Door Lock Module & Driver/Passenger Door Lock Switch |
| 5 (5) | Radio, Instrument Cluster, Rear A/C Heater Control & A/C Heater Control |
| 6 (20) | Intermittent Wiper Control Module, Wiper Relay, Wiper/Washer Switch & Intermittent Wiper Motor |
| 7 (10) | Rear Window Defogger Switch & Rear A/C Heater Unit |
| 8 (15) | Radio |
| 9 (10) | Fuel Pump Relay, Automatic Shut Down Relay, Powertrain Control Module & Torque Converter Clutch Solenoid |
| 10 (15) | Combination Flasher |
| 11 (10) | Instrument Cluster |
| 12 (15) | Underhood Lamp, Radio, Power Mirror Switch, Instrument Cluster, Glove Box Lamp & Dome Lamp Switch |
| 13 (20) | Headlamp Switch & Chime/Buzzer Module |
| 14 (20) | Data Link Connector, Power Amplifier & Courtesy Lamp Relay |
| 15 (15) | Cigar Lighter & Van Conversion Accessary Power Relay |
| 16 (5) | Central Timer Module |
| 17 (10) | Chime/Buzzer Module, Duty Cycle Evap/Purge Solenoid, Park/Neutral Position Switch, Daytime Running Lamp Module & Central Timer Module |
| 18 (10) | Airbag Control Module |
| 19 (10) | Passenger Airbag On/Off Switch & Airbag Control Module |
JUNCTION BLOCK FUSE IDENTIFICATION
