SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Compressor Type | Sanden Scroll TR-105 | |
| Compressor Belt Tension | (1) | |
| Refrigerant (R-134a) Capacity | ||
| Front | 33.9 ozs. | |
| Front & Rear | 45.9 ozs. | |
| System Oil Capacity (2) | ||
| Front | 8.0 ozs. | |
| Front & Rear | 10.0 ozs. | |
| System Operating Pressures (3) | ||
| High Side | 160-235 psi (11.2-16.5 kg/cm 2 ) | |
| Low Side | 20-35 psi (1.4-2.5 kg/cm 2 ) | |
| (1) Dynamic tensioner automatically adjusts belt. Tension is okay if indicator is within marked limits on belt tensioner. (2) Use SP-10 PAG refrigerant oil. (3) Measured at ambient air temperature of 80°F (27°C). | ||
| (1) | Dynamic tensioner automatically adjusts belt. Tension is okay if indicator is within marked limits on belt tensioner. |
| (2) | Use SP-10 PAG refrigerant oil. |
| (3) | Measured at ambient air temperature of 80°F (27°C). |
SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| A/C Compressor Mounting Bolts | 30 (40) |
| A/C Compressor Bracket Mounting Bolts | 20 (27) |
| A/C Compressor Suction/Discharge Hose | 17 (23) |
| Expansion Valve Sealing Plate Bolt | 17 (23) |
| INCH Lbs. (N.m) | |
| Expansion Valve Bolts | 100 (11) |
TORQUE SPECIFICATIONS
