INSTRUMENT PANEL FUSE BLOCK
| CAUTION | When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
The instrument panel fuse block is located under the glove box liner (Scheme 1) For component identification (Scheme 2) For fuse identification see INSTRUMENT PANEL FUSE BLOCK FUSE IDENTIFICATION.
| Fuse (Amp) | Application |
|---|---|
| 1 (10) | Airbag Control Module |
| 2 (20) | Speaker Choke Relay |
| 3 (20) | Headlamp Switch, Radio Illumination, License Lights & Parking Lights |
| 4 (20) | Horn Relay |
| 5 (10) | ABS Control Module, ABS Lamp Relay, ABS Power Relay |
| 6 (10) | Rear Window Defogger Switch & Park/Neutral Switch |
| 7 (25) | A/C & Heater Control Switch, Rear Heater & A/C Relay, Blower Motor Switch (W/O A/C) |
| 8 (25) | Power Window Switches (Left & Right) |
| 9 (20) | Cigar Lighter |
| 10 (20) | Intermittent Wiper Motor, Control Module & Switch |
| 11 (10) | Radio |
| 12 (20) | Rear Wheel ABS Module, Van Conversion Accessory Relay & Turn Signal Flasher |
| 13 | Not Used |
| 14 (20) | Rear A/C Heater Relay, Chime/Buzzer Module, Rear ABS Module & Stoplamp Switch |
| 15 (20) | Stop Lights & Rear Wheel Anti-Lock Brake Module |
| 16 (25) | Power Seat Switch, Power Door Lock Module, Left & Right Door Lock Switches |
| 17 (10) | Instrument Cluster, Overdrive Switch, Seat Belt Buzzer, Power Door Lock Module, Message Center |
| 18 (10) | Instrument Cluster & Airbag Module |
| 19 (10) | Fuel Pump Relay, Automatic Shut Down Relay, A/C Compressor Clutch Relay, DRL Module, A/C Cycling Switch, PCM, TCC Solenoid (V6), EVAP Duty Cycle Purge Solenoid |
| 20 (3) | Instrument Cluster, Radio, Cigar Lighter, Rear Window Defogger, A/C Heater Control Lamp Switches Illumination Circuits |
INSTRUMENT PANEL FUSE BLOCK FUSE IDENTIFICATION
Scheme 1
Scheme 2
POWER DISTRIBUTION CENTER
| CAUTION | When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
The power distribution center is under the hood near the battery. (Scheme 3) For power distribution center identification (Scheme 4) For fuse identification see POWER DISTRIBUTION CENTER FUSE IDENTIFICATION.
| Fuse (Amp) | Application |
|---|---|
| 1/2 (50) | Van Conversion Battery |
| 3 (40) | Ignition Switch & Blower Motor Relay (Heater Only) |
| 4 (50) | Front Blower Motor Relay |
| 5 (20) | Starter Relay & A/C Compressor Clutch Relay |
| 6 (40) | Instrument Panel Fuse Block (Fuses 14, 15 & CB16) |
| 7 (40) | ABS Pump Motor Relay |
| 8 (20) | Fuel Pump Relay |
| 9/10 (50) | Van Conversion Accessory Power Relay |
| 11 | Not Used |
| 12 (40) | Rear Window Defogger Switch |
| 13 | Not Used |
| 14 (40) | Headlamp Switch & Instrument Panel Fuse Block (Fuses 2, 3 & 4) |
| 15 (20) | Hazard Warning Flasher |
| 16 (40) | Run/Accessary Feed At Ignition Switch |
| 17/18 (20) | Auto Shut Down Relay, PCM & Transmission Relay |
| 19/20 (15) | Data Link Connector, Underhood Lamp, Power Mirrors, Glove Box Lamp, Radio & Headlamp Switch |
| 21/22 (120) | Generator |
POWER DISTRIBUTION CENTER FUSE IDENTIFICATION
