ADJUSTMENTS

WARNINGVehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See AIR BAG DEACTIVATION PROCEDURES article in GENERAL INFORMATION.

Control Pressure Adjustments

There are two control pressure adjustments on the valve body: Line Pressure and Throttle Pressure. Line and throttle pressures are interdependent because each affects shift quality and timing. As a result, both adjustments must be performed properly and in the correct sequence. Adjust line pressure first and throttle pressure last.

Line Pressure Adjustment

Measure distance from the valve body to the inner edge of the adjusting screw with an accurate steel scale. Distance should be 1-5/16" (33.4 mm). If adjustment is required, turn the adjusting screw in, or out, to obtain required distance setting. If adjustment is required, turn the adjusting screw in, or out, to obtain required distance setting. (Scheme 30)

The 1-5/16" (33.4 mm) setting is an approximate setting. Manufacturing tolerances may make it necessary to vary from this dimension to obtain desired pressure.

One complete turn of the adjusting screw changes line pressure approximately 9 kPa (1-2/3 psi). Turning the adjusting screw counterclockwise increases pressure while turning the screw clockwise decreases pressure.

Scheme 30

Scheme 30: Line Pressure Adjustment

Throttle Pressure Adjustment

Insert Gauge Tool C-3763 between the throttle lever cam and the kickdown valve stem. (Scheme 31)

Push the gauge tool inward to compress the kickdown valve against the spring and bottom the throttle valve. Maintain pressure against kickdown valve spring. Turn throttle lever stop screw until the screw head touches throttle lever tang and the throttle lever cam touches gauge tool.

The kickdown valve spring must be fully compressed and the kickdown valve completely bottomed to obtain correct adjustment.

Scheme 31

Scheme 31: Throttle Pressure Adjustment
