Power Windows: Diagnosis Dodge Pickup R2500

WIRING VOLTAGE TEST

The following wiring test determines whether or not voltage is continuous through the body harness to the front switch.

1. Remove the Driver Door Module. Refer to «DRIVER DOOR MODULE»(ref-189667-S23274654882005091200000) .
2. Disconnect wire connector from back of power window switch.
3. Switch ignition to the ON position.
4. Connect the clip end of a 12-volt test light to Pin 14 of the window switch harness connector. Touch the test light probe to Pin 10.

1. If the test light illuminates, the wiring circuit between the battery and switch is OK.
2. If the lamp does not illuminate, first check the fuse in the Integrated Power Module (IPM). Check the circuit breaker located near the park brake pedal. If fuse and circuit breaker are OK, then check for a broken wire.

Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

POWER WINDOW MOTOR TEST

If the power window motor is receiving proper current and ground and does not operate, proceed with motor test. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

1. Remove door trim panel as necessary to gain access to power window motor wire connector. Refer to «DOORS - FRONT»(ref-189710) or «DOORS - REAR»(ref-189711) .
2. Disconnect power window motor wire connector from door harness.
3. Using two jumper wires, connect one to a battery (+) source and the other to a good ground (-).
4. Connect the Negative (-) jumper probe to one of the motor connector terminals.
5. Momentarily touch the Positive (+) jumper probe to the other motor connector terminal. When positive probe is connected, the motor should rotate in one direction to either move window up or down. If window is all the way up or down, the motor will grunt and the inner door panel will flex when actuated in that one direction.
6. Reverse jumper probes at the motor connector terminals and window should now move in opposite direction. If window does not move or grunt, replace the motor.

If window moved completely up or down, reverse the jumper probes and cycle window to the opposite position to verify full operation.

If motor grunts and does not move, verify that regulator is not binding.

DIAGNOSIS AND TESTING - WINDOW SWITCH

The Light-Emitting Diode (LED) illumination lamps for all of the power window and lock switch and bezel unit switch paddles receive battery current through the power window circuit breaker in the junction block. If all of the LEDs are inoperative in both the power window and lock switch units and the power windows are inoperative, refer to DIAGNOSIS AND TESTING - POWER WINDOWS . If the power windows operate, but any or all of the LEDs are inoperative, the power window and lock switch units with the inoperative LED(s) is faulty and must be replaced. For complete circuit diagrams, refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

Scheme 1

1. Check the fuse in the Integrated Power Module (IPM) and the circuit breaker located near the park brake pedal. If OK, go to Step 2. If not OK, replace the faulty fuse or circuit breaker.
2. Turn the ignition switch to the On position. Check for battery voltage at the fuse in the Integrated Power Module (IPM). If OK, turn the ignition switch to the Off position and go to Step 3. If not OK, check circuit breaker and repair the circuit to the ignition switch as required.
3. Disconnect and isolate the battery negative cable. Remove the power window switch unit from the door trim panel (passenger doors). The driver's door switch is included with the Driver Door Module. Refer to «DIAGNOSIS AND TESTING - DRIVER DOOR MODULE»(ref-189667-S22288880962005091200000) for service procedures. Unplug the wire harness connector from the switch unit.
4. Test the power window switch continuity. See the «POWER WINDOW SWITCH CONTINUITY CHART»(ref-189670-S26447780332005091200000) to determine if the continuity is correct in the Off, Up and Down switch positions (Scheme 1) If OK, refer to «DIAGNOSIS AND TESTING - POWER WINDOWS»(ref-189670-S01918140542005091200000).

POWER WINDOW SWITCH CONTINUITY CHART
