SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|---|
| Axle Ratio | 3.55, 3.92 |
| Differential Case Flange Runout | 0.076 mm (0.003 in.) |
| Differential Side Gear Clearance | 0-0.15 mm (0-0.006 in.) |
| Ring Gear Diameter | 205 mm (8.0 in.) |
| Ring Gear Backlash | 0.12-0.20 mm (0.005-0.008 in.) |
| Ring Gear Runout | 0.12 mm (0.005 in.) |
| Pinion Bearing Preload - New Bearings | 2.0-2.8 N.m (18-25 in. lbs.) |
| Pinion Bearing Preload - Original Bearings | 1-2 N.m (10-20 in. lbs.) |
AXLE SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Mounting Nuts | 95 | 70 | |
| Differential Fill Hole Plug | 34 | 25 | |
| Differential Cover Bolts | 22 | 15 | |
| Bearing Cap Bolts | 61 | 45 | |
| Ring Gear Bolts | 108 | 80 | |
| Pinion Nut | 271-475 | 200-350 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
- Remove half shaft from vehicle.
- Remove skid plate, if equipped.
- Clean axle seal area.
- Remove snap ring from the axle shaft.
- Remove axle shaft with Remover 8420A, Collar 8420-3 and Slide Hammer C-3752 see scheme 57
