TORQUE SPECIFICATIONS
| DESCRIPTION | Nm | Ft. Lbs. | In. Lbs. | |
|---|---|---|---|---|
| Automatic Belt Tensioner to Block-Bolts | 41 | 30 | ||
| Automatic Belt Tensioner Pulley-Bolt | 61 | 45 | ||
| Block Heater-Bolt | 2 | 17 | ||
| Generator/Compressor Mounting Bracket-Bolts | ||||
| # 1 and 2 | 54 | 40 | ||
| #3 | 40 | 30 | ||
| Fan Shroud to Radiator Mounting-Bolts | 6 | 55 | ||
| Radiator to Support - Bolts | 8.5 | 75 | ||
| Fan Blade to Viscous Fan Drive-Bolts | 24 | 18 | ||
| Idler Pulley-Bolt | 54 | 40 | ||
| Thermostat Housing-Bolts - All Except 5.9L | 13 | 112 | ||
| Thermostat Housing-Bolts - 5.9L | 23 | 16 | ||
| Power Steering Oil Cooler - Bolts | 6 | 55 | ||
| Transmission Auxiliary Oil Cooler-Bolts | 6 | 55 | ||
| Transmission Oil Cooler Tube Nuts | 31.5 | 24 | ||
| Coolant Bottle - Bolts | 8.5 | 75 | ||
| Transmission Oil Cooler to Transmission - 5.9L/46RE - Tube Nuts | 31.5 | 24 | ||
| Transmission Oil Cooler to Transmission - 3.7L/4.7L/ 45RFE - Tube Nuts | 20 | 18 | ||
| Water Pump-Bolts | 24 | 18 | ||
| Water Pump - Bolts - 4.7L | 58 | 43 | ||
Torque Specifications
ENGINE SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|---|
| 3.7/4.7L Engine | 15.4L (16.2 qts.) - to the middle of the cold fill range |
| 5.7L Engine | 15.4L (16.2 qts.) - to the middle of the cold fill range |
| 5.9L Engine | 15.5L (16.3 qts.) - to the MIN mark after 3 warm up, cool down cycles |
| 8.0L Engine | 24L (25.3 qts.) |
| 5.9L Diesel Engine | 28L (29.5 qts.) |
ENGINE SPECIFICATIONS
