SPECIFICATIONS
| Component | Fluids, Lubricants and Genuine Parts |
|---|---|
| Engine Coolant | Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. |
| Engine Oil | Use API Certified SAE 5W-20 Engine Oil meeting the requirements of DaimlerChrysler Material Standard MS-6395. Refer to the engine oil fill cap for correct SAE grade. |
| Engine Oil Filter | Mopar ® Engine Oil Filter, P/N 5281090 or equivalent. |
| Spark Plugs | ZFR6F-11 (Gap.043 in [1.1 mm]) |
| Fuel Selection | 87 Octane, (R+M)/2 Method |
Engine
| Component | Fluids, Lubricants, and Genuine Parts |
|---|---|
| Engine Coolant | Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) |
| Engine Oil (Gasoline Engines) - Non ACEA Catagories | Use API Certified SAE 5W-20 engine oil, meeting the requirements of DaimlerChrysler Material Standard MS-6395. Refer to your engine oil filler cap for correct SAE grade. SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. |
| Engine Oil (Gasoline Engines) - ACEA Catagories | For countries that use the ACEA European Oil Categories for Service Fill Oils, use engine oils meeting the requirements of ACEA C3, and approved to MB 229.31 or MB 229.51. SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. |
| Engine Oil - Diesel (without Particulate Filter) | Use SAE 0W-40 diesel engine oils confirming to API Quality CI-4 or CJ-4. For countries that use the ACEA European Oil Categories for Service Fill Oils, use engine oils meeting the requirements of ACEA C3 and approved to MB 229.31 or MB 229.51. |
| Engine Oil - Diesel (with Particulate Filter) | Use SAE 5W-30 diesel engine oils conforming to API Quality CI-4 or CJ-4. For countries that use the ACEA European Oil Categories for Service Fill Oils, use engine oils meeting the requirements of ACEA C3 (LOW ASH) and approved to MB 229.31 or MB 229.51. |
| Spark Plugs (3.7 Liter Engine) | ZFR6F-11 (Gap.043 in [1.1 mm]) |
| Engine Oil Filter (3.7 Liter Engine) | Mopar ® 5281090 or equivalent. |
| Engine Oil Filter (2.8 Liter Diesel Engine) | Mopar ® Oil Filter (P/N 5003558AA) |
| Fuel Selection (3.7 Liter Engine) | 91 Octane |
| Fuel Selection (Diesel Engine) | 50 Cetane or higher (Less than 15 ppm Sulfur). |
Engine - Export
| Component | Fluids, Lubricants and Genuine Parts. |
|---|---|
| Automatic Transmission | Mopar ® ATF+4, Automatic Transmission Fluid. |
| Manual Transmission | Mopar ® Manual Transmission Lubricant or equivalent (meeting the requirements of DaimlerChrysler Material Standard MS-9224) |
| Transfer Case | Mopar ® ATF+4, Automatic Transmission Fluid. |
| Brake Master Cylinder/Manual Transmission Clutch System | Mopar ® DOT 3 Brake Fluid, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids. |
| Power Steering Reservoir | Mopar ® ATF+4, Automatic Transmission Fluid. |
Chassis
| U.S. | Metric | ||
|---|---|---|---|
| Front Axle | |||
| 186 FIA (Model 30) | SAE 80W-90 Multipurpose Type, GL-5 Gear Lubricant or equivalent. | 2.6 Pints | 1.24 Liters |
| Rear Axle | |||
| 8 1/4 | SAE 75W-140 Synthetic Gear Lubricant or equivalent. | 4.4 Pints | 2.08 Liters |
Axles
| U.S. | Metric | |
|---|---|---|
| Fuel (Approximate) | ||
| 3.7/4.0 Liter Engine | 19.5 Gallons | 73.8 Liters |
| 2.8 Liter Diesel Engine | 18.5 Gallons | 70 Liters |
| Engine Oil with Filter | ||
| 3.7 Liter Engine (SAE 5W-20, API Certified Engine Oil) | 5 Quarts | 4.7 Liters |
| 4.0 Liter Engine (SAE 10W-30, API Certified Engine Oil) | 5.5 Quarts | 5.2 Liters |
| 2.8 Liter Diesel Engine | 7 Quarts | 6.6 Liters |
| Cooling System * | ||
| 3.7 Liter Engine (Mopar ® Antifreeze/Engine Coolant 5 Year/100,000 Mile Formula) | 14 Quarts | 13.2 Liters |
| 4.0 Liter Engine (Mopar ® Antifreeze/Engine Coolant 5 Year/100,000 Mile Formula) | 14 Quarts | 13.2 Liters |
| 2.8 Liter Diesel Engine (Mopar ® Antifreeze/Engine Coolant 5 Year/100,000 Mile Formula or equivalent). | 11.8 Quarts | 11.1 Liters |
| * Includes heater and coolant recovery bottle filled to MAX level. | ||
| POWER STEERING SYSTEM | ||
| Power steering fluid capacities are dependent on engine/chassis options as well as steering gear/cooler options. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these capacities may vary. Refer to STANDARD PROCEDURE . | ||
| A/C REFRIGERANT SYSTEM | ||
| All Models | 1.12 Pounds | 0.510 Kilograms |
| AUTOMATIC TRANSMISSION | ||
| Service Fill - NAG1 | 10.6 Pints | 5.0 Liters |
| Overhaul - NAG1 | 16.3 Pints< | 7.7 Liters< |
| Service Fill - 42RLE | 8.0 Pints | 3.8 Liters |
| O-haul Fill - 42RLE | 17.6 Pints< | 8.3 Liters< |
| <--Dry fill capacity depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. | ||
| TRANSFER CASE | ||
| MP1522 (Approximate dry fill or fill to bottom edge of the fill plug hole.) | 3.80 Pints | 1.80 Liters |
| MP3022 (Approximate dry fill or fill to bottom edge of the fill plug hole.) | 4.01 Pints | 1.90 Liters |
| MANUAL TRANSMISSION | ||
| NSG370 (Approximate dry fill or fill to bottom edge of the fill plug hole.) | 3.17 Pints | 1.5 Liters |
| *Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||
Capacities
Scheme 7
The Totally Integrated Power Module (TIPM) is located in the engine compartment near the battery. This center contains cartridge fuses, mini fuses and relays. A label that identifies each component is printed on the inside of the cover.
| Cavity | Cartridge Fuse | Mini Fuse | Description |
|---|---|---|---|
| J1 | 40 Amp Green | Power Folding Seat | |
| J2 | 30 Amp Pink | Transfer Case/Pwr Liftgate Module | |
| J3 | 40 Amp Green | Rear Door Module (RR DOOR NODE) | |
| J4 | 25 Amp Natural | Driver Door Node | |
| J5 | 25 Amp Natural | Passenger Door Node | |
| J6 | 40 Amp Green | Anti-Lock Brake System (ABS) Pump/ESP | |
| J7 | 30 Amp Pink | Anti-Lock Brake System (ABS) Valve/ESP | |
| J8 | 40 Amp Green | Power Memory Seat (If Equipped) | |
| J9 | 40 Amp Green | PZEV Motor/Flex Fuel | |
| J10 | 30 Amp Pink | Hdlp Wash Relay/Manual Tuning Valve | |
| J11 | 30 Amp Pink | Sway Bar/THATCHAM Lock-Unlock/Power Sliding Door Module | |
| J13 | 60 Amp Yellow | Ignition Off Draw (IOD) - Main | |
| J14 | 40 Amp Green | EBL (Rear Window Defogger) | |
| J15 | 30 Amp Pink | Rear Blower | |
| J17 | 40 Amp Green | Starter Solenoid | |
| J18 | 20 Amp Yellow | Powertrain Control Module (PCM) Trans Range | |
| J19 | 60 Amp Yellow | Radiator Fan | |
| J20 | 30 Amp Pink | Front Wiper LO/HI | |
| J21 | 20 Amp Yellow | Front/Rear Washer | |
| J22 | 25 Amp Natural | Sunroof Module | |
| M1 | 20 Amp Yellow | Center High Mounted Stop Light (CHMSL)/Brake Switch | |
| M2 | 20 Amp Yellow | Trailer Lighting | |
| M3 | 20 Amp Yellow | Frt/Rear Axle Lockers | |
| M4 | 10 Amp Red | Trailer Tow | |
| M5 | 25 Amp Natural | Inverter | |
| M6 | 20 Amp Yellow | Power Outlet #1/Rain Sensor | |
| M7 | 20 Amp Yellow | Power Outlet #2 (BATT/ACC SELECT) | |
| M8 | 20 Amp Yellow | Front Heated Seat | |
| M9 | 20 Amp Yellow | Rear Heated Seat (If Equipped) | |
| M10 | 20 Amp Yellow | Ignition Off Draw - Vehicle Entertainment System (IOD-VES), Satellite Digital Audio Receiver (SDARS), DVD, Hands Free Module (HFM), RADIO, Antenna (ANT), Universal Garage Door Opener (UGDO), Vanity Lamp (VANITY LP) | |
| M11 | 10 Amp Red | (Ignition Off Draw) IOD-HVAC/ATC, MW SENSR, Underhood Lamp (UH LMP) | |
| M12 | 30 Amp Green | Amplifier (AMP) | |
| M13 | 20 Amp Yellow | Ignition Off Draw- Cabin Compartment Node (IOD-CCN), Wireless Control Module (WCM), SIREN, Clock Module (CLK MOD), Multi-Function Control Switch (MULTIFCTN SW) | |
| M14 | 20 Amp Yellow | Trailer Tow (Export Only) | |
| M15 | 20 Amp Yellow | COL MOD, IR SNS, Heater Ventilation, Air Conditioning/Automatic Temperature Control (HVAC/ATC), Rear View Mirror (RR VW MIR), Cabin Compartment Node (CCN), Transfer Case Switch (T-CASE SW), RUN/ST, Multi-Function Control Switch (MULTIFTCN SW), Tire Pressure Monitor (TPM), Glow Plug Module (GLW PLG MOD) - Export Diesel Only | |
| M16 | 10 Amp Red | Occupant Restraint Controller/Occupant Classification Module (ORC/OCM) | |
| M17 | 15 Amp Blue | Left Tail/License/Park Lamp (LT-TAIL/LIC/PRK LMP) | |
| M18 | 15 Amp Blue | Right Tail/Park/Run Lamp (RT-TAIL/PRK/RUN LMP) | |
| M19 | 25 Amp Natural | Auto Shut Down (ASD #1 and #2) | |
| M20 | 15 Amp Blue | Cabin Compartment Node Interior Light (CCN INT LIGHT), Switch Bank (SW BANK), Steering Control Module (SCM) | |
| M21 | 20 Amp Yellow | Auto Shut Down (ASD #3) | |
| M22 | 10 Amp Red | Right Horn (RT HORN (HI/LOW) | |
| M23 | 10 Amp Red | Left Horn (LT HORN (HI/LOW) | |
| M24 | 25 Amp Natural | Rear Wiper (REAR WIPER) | |
| M25 | 20 Amp Yellow | Fuel Pump (FUEL PUMP), Diesel Lift Pump (DSL LIFT PUMP) - Export Only | |
| M26 | 10 Amp Red | Power Mirror Switch (PWR MIRR SW), Driver Window Switch (DRVR WIND SW) | |
| M27 | 10 Amp Red | Ignition Switch (IGN SW), Window Module (WIN MOD) | |
| M28 | 10 Amp Red | Next Generation Controller (NGC), Transmission Feed (TRANS FEED), J1962 | |
| M29 | 10 Amp Red | Occupant Classification Module (OCM) | |
| M30 | 15 Amp Blue | Rear Wiper Module (RR WIPER MOD), Power Folding Mirror (PWR FOLD MIR) | |
| M31 | 20 Amp Yellow | Back-Up Lamps (B/U LAMPS) | |
| M32 | 10 Amp Red | Occupant Restraint Controller (ORC), TT EUROPE | |
| M33 | 10 Amp Red | Next Generation Controller (NGC), Global Powertrain Engine Controller (GPEC) | |
| M34 | 10 Amp Red | Park Assist (PRK ASST), Heater Ventilation, Air Conditioning Module (HVAC MOD), Headlamp Wash (HDLP WASH), Compass (COMPAS) | |
| M35 | 10 Amp Red | Heated Mirrors | |
| M36 | 20 Amp Yellow | Power Outlet #3 (BATT) | |
| M37 | 10 Amp Red | Anti-Lock Brake System (ABS) , Electronic Stability Program (ESP), Stop Lamp Switch (STP LP SW), Fuel Pump Rly Hi Control | |
| M38 | 25 Amp Natural | Lock/Unlock Motors (LOCK/UNLOCK MTRS) |
| 1 CB1 | Circuit Breaker 1 |
|---|---|
| 2 | Run Accessory |
| 3 | Run Start |
| 4 | Run |
| 5 | Rear Window Defogger (EBL) |
| 6 | Starter Motor |
| 7 | Transmission Control (EATX) |
| 8 | Spare |
| 9 | Auto Shut Down |
| 10 | Spare |
| 11 | Radiator Fan Control |
| 12 | Spare |
Relay's
| CAUTION | When installing the Integrated Power Module cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Integrated Power Module, and possibly result in a electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
SPECIFICATIONS - EXTERIOR
| LIGHT BULBS - Exterior | Bulb Number |
|---|---|
| Headlight | 9008 H13 |
| Front Park/Turn | 3157AK |
| Front Sidemarker | 168 |
| Back-Up | 4057K |
| Center High Mounted Stoplight | 921 |
| Fog Lamp | H10 9145 |
| License Plate Light | 168 |
| Rear Tail, Stop, Turn Signal | 4057K |
SPECIFICATIONS - INTERIOR
| LIGHT BULBS - Interior | Bulb Number |
|---|---|
| Dome Light | WL212-2 |
| Liftgate Lamp | 567 |
| Overhead Console Lights | PLW214-2A |
| Reading Light | WL212-2 |
In this information you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer carefully review this information to tow your load as efficiently and safely as possible.
To maintain warranty coverage, follow the requirements and recommendations in this manual concerning vehicles used for trailer towing.
