SPECS - TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | Inch Lbs. |
|---|---|---|---|
| EVAP Canister Mounting Nut/Bolt | 11 | 95 | |
| PCV Valve | 12 | 106 | |
| EGR Valve-to-Cyl. Head Bolts - 3.7L | 28 | 21 | 248 |
| ERG Tube-to-EGR Valve Bolts | 13 | 9.6 | 115 |
| EGR Valve-to-Cyl. Head Bolts - 4.0L | 8 | 80 | |
| EGR Tube-to-Intake Manifold Bolts | 4 | 35 |
Scheme 3
The EVAP canister purge solenoid (1) is located near the battery (2).
Scheme 4
- Lift the solenoid assembly (1) from the tongue-type bracket (2).
- Disconnect electrical connector (5).
- Disconnect quick-connect fittings (3) and (4) from solenoid.
TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| EGR Mounting Bolts - 2.8L Diesel | 15 | 11 | |
| EGR Airflow Control Valve - 2.8L Diesel | 11 | 8 |
TORQUE SPECIFICATIONS
Scheme 5
The EGR valve (5) is located at the rear of the intake manifold (7).
Scheme 6
- Disconnect and isolate negative battery cable at battery.
- Remove plastic engine cover.
- Relieve cooling system pressure and remove EGR cooler (8). Refer to «COOLING»(ref-306154) article for removal procedures .
- Remove vacuum line from fitting (6).
- Remove EGR valve mounting bolts (8) and remove EGR valve (5) from intake manifold.
- Remove and discard old mounting gasket located between EGR valve and intake manifold.
- Clean mounting areas at bottom of valve and at top of intake manifold.
