Differential & Driveline: Specifications Dodge Nitro I

TORQUE

TORQUE SPECIFICATIONS

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. With vehicle in neutral, position vehicle on hoist.
2. Mark an installation reference line across the front propeller shaft CV joint (1) and transfer case flange (2).
3. Mark an installation reference line across the front propeller shaft flange (1) and the axle flange (2).
4. Remove the axle flange (1) bolts (2).
5. Remove the CV joint bolts (1) and retainers (2).
6. Compress the propeller shaft enough to remove the shaft from the flanges.

Scheme 6

Note. Clean all propeller shaft bolts and apply Mopar® Lock & Seal Adhesive or equivalent to the threads before installation.

Scheme 7

Scheme 8

Scheme 9

1. Compress the propeller shaft enough to install the shaft into the axle and transfer case flanges.
2. Align installation reference marks on the transfer case flange (1) front shaft CV joint (2).
3. Install CV joint retainers (2) and bolts (1). Tighten bolts to 30 N.m (22 ft. lbs.).
4. Align installation reference marks on the front propeller shaft flange (1) and axle flange (2).
5. Install the axle flange (1) bolts (2) and tighten to 108 N.m (80 ft. lbs.).

Scheme 10

Scheme 11

Scheme 12

1. With vehicle in neutral, position vehicle on hoist.
2. Mark a reference line across axle flange (1) and propeller shaft flange (2) for installation.
3. Mark a reference line across transmission/transfer case flange (1) and propeller shaft flange (2) for installation.
4. Remove propeller shaft flange (1) bolts from axle flange (2).
5. Remove propeller shaft flange (1) bolts from transmission/transfer case flange (2).
6. Remove propeller shaft.

Scheme 13

Note. Clean all propeller shaft bolts and apply Mopar® Lock & Seal Adhesive or equivalent to the threads before installation.

Scheme 14

1. Install propeller shaft.
2. Align reference mark on axle flange (1) with propeller shaft flange (2).
3. Align reference mark on transmission/transfer case flange (1) with propeller shaft flange (2).
4. Install propeller shaft bolts (2) in axle flange (1) and tighten to 108 N.m (80 ft. lbs.).
5. Install propeller shaft bolts in transmission/transfer case flange (2) and tighten to 108 N.m (80 ft. lbs.).

TORQUE SPECIFICATIONS

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Place shaft in vise with soft jaws and support C/V joint. CAUTION: Do not damage C/V housing or half shaft.
2. Remove clamps (2) (4) with a cut-off wheel or grinder.
3. Slide the boot down the shaft.
4. Remove lubricant to expose the C/V joint snap ring.
5. Spread snap ring (1) and slide the joint off the shaft.
6. Slide boot off the shaft and discard old boot.
7. Mark alignment marks (1) on the inner race/hub (2), bearing cage (3) and housing with dabs of paint.
8. Clamp C/V joint in a vertical position in a soft jawed vise.
9. Press down one side of the bearing cage (3) to gain access to the ball at the opposite side. NOTE: If joint is tight, use a hammer and brass drift to loosen the bearing hub. Do not contact the bearing cage with the drift.
10. Remove ball (4) from the bearing cage (3).
11. Repeat step above until all six balls are removed from the bearing cage.
12. Lift cage and inner race (2) upward and out from the housing (1).
13. Turn inner race 90° in the cage and rotate the inner race/hub out of the cage.

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Apply a light coat of grease to the C/V joint components before assembling them.
2. Align inner race, cage and housing according to the alignment reference marks.
3. Insert inner race (1) into the cage (2) and rotate race into the cage.
4. Rotate inner race/hub in the cage (1).
5. Insert cage into the housing (3).
6. Rotate cage 90° into the housing (1).
7. Apply lubricant included with replacement boot/joint to the ball races. Spread lubricant equally between all the races.
8. Tilt inner race/hub (2) and cage (3) and install the balls (4).
9. Place new clamps onto new boot and slide boot onto the shaft to its original position.
10. Apply the rest of lubricant to the C/V joint and boot.
11. Push the joint onto the shaft until the snap ring (1) seats in the groove (3). Pull on the joint to verify the span ring has engaged.
12. Position boot on the joint in its original position. Ensure boot is not twisted and remove any excess air.
13. Secure both boot clamps (2) (4) with Clamp Installer C-4975A. Place tool on clamp bridge and tighten tool until the jaws of the tool are closed.

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Clamp shaft in a vise (with soft jaws) and support C/V joint (1).
2. Remove clamps with a cut-off wheel or grinder.
3. Slide boot down (2) the shaft.
4. Remove lubricant from housing (1) to expose the C/V snap ring (2) and remove snap ring.
5. Remove bearings (4) from the cage (1).
6. Rotate cage (1) 30° and slide cage off the inner race (2) and down the shaft (3).
7. Remove spread inner race (1) snap ring (4) and remove race (1) from the shaft (3).
8. Remove boot from the shaft and discard.
9. Clean and inspect housing (1), cage (2), bearings (3), housing snap-ring (4), inner race snap-ring (5) and inner race (6) for wear or damage.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Apply a coat of grease supplied with the joint/boot to the C/V joint components before assembling them.
2. Place new clamps on the new boot and slide boot down the shaft.
3. Slide cage (2) onto the shaft (1) with the small diameter (3) end towards the boot.
4. Install the inner race (1) onto the shaft (3). Pull on the race to verify snap ring has engaged.
5. Align cage (1) with the inner race (2) and slide over the race.
6. Turn the cage 30° to align the cage windows (4) with the race (2).
7. Apply grease to the inner race and bearings and install the bearings.
8. Apply grease to the housing bore (4) then install the bearing assembly (2) into the housing (1).
9. Install the housing snap ring (3) and verify it is seated in the groove.
10. Fill the housing and boot with the remaining grease.
11. Slide the boot onto the C/V housing into its original position. Ensure boot is not twisted and remove any excess air.
12. Secure both boot clamps with Clamp Installer C-4975A. Place tool on clamp bridge and tighten tool until the jaws of the tool are closed.
