RESTRAINT SYSTEM SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Clockspring Mounting Screws | 3 | 27 | |
| Curtain Airbag Mounting Nuts | 8 | 71 | |
| Front Impact Sensor Mounting Nut | 8 | 71 | |
| Side Impact Sensor Mounting Nut | 7 | 62 | |
| Occupant Classification Module Mounting Screws | 2 | 20 | |
| Occupant Restraint Controller Mounting Screws | 10.5 | 95 | |
| Occupant Restraint Controller Mounting Nuts | 10.5 | 95 | |
| Passenger Airbag Lower Instrument Panel Bracket Nuts | 20 | 15 | |
| Passenger Airbag Lower Mounting Nuts | 7 | 62 | |
| Passenger Airbag Upper Instrument Panel Bracket To Structural Duct Screw | 2.9 | 25 | |
| Passenger Airbag Upper Instrument Panel Bracket Mounting Screws | 29.5 | 21 | |
| Front Seat Belt Buckle Lower Anchor Mounting Screw | 43 | 32 | |
| Second Row Center and Right Outboard Seat Belt Buckle Mounting Screw | 55 | 41 | |
| Second Row Seat Cushion Leg Mounting Screws | 54 | 40 | |
| Second Row Center Seat Belt Anchor and Left Outboard Buckle Mounting Nut | 62.5 | 46 | |
| Front Seat Belt Retractor Lower Bracket Mounting Screw | 44.5 | 33 | |
| Front Seat Belt Turning Loop Mounting Screw | 44.5 | 33 | |
| Front Seat Belt Lower Anchor Mounting Screw | 44.5 | 33 | |
| Second Row Center Seat Belt Retractor Mounting Screw | 55 | 41 | |
| Second Row Outboard Seat Belt Retractor Lower Bracket Mounting Screw | 44.5 | 33 | |
| Second Row Outboard Seat Belt Turning Loop Mounting Screw | 44.5 | 33 | |
| Second Row Outboard Seat Belt Lower Anchor Mounting Nut | 62.5 | 46 | |
| Seat Belt Turning Loop Adjuster Mounting Screw | 44.5 | 33 | |
| Seat Weight Sensor to Seat Adjuster Track Mounting Nuts | 28 | 21 | |
| Seat Weight Sensor to Seat Riser Mounting Nut | 44.5 | 33 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
This vehicle is equipped with a Lower Anchors and Tether for CHildren, or LATCH child restraint anchorage system. The second row seats in these vehicles are equipped with a fixed-position child restraint upper tether anchor (2) for both the center and the two outboard seating positions, and child restraint lower anchors (1) for the two outboard seating positions.
Scheme 12
The upper tether anchors (1) are each integral to the second row seat back panels. These anchors are each constructed from short lengths of heavy-gauge steel wire that is securely welded into stamped steel cups that are integral to the seat back panels. There is a separate molded plastic trim bezel (2) located around each of these anchors. The child restraint upper tether anchors cannot be adjusted or repaired and, if ineffective or damaged, they must be replaced as a unit with their respective second row seat back panels.
Scheme 13
The lower anchors (2) for this vehicle are integral to their respective second row seat brackets, which are secured to the rear floor panel at the front with studs and nuts, and at the rear with screws. These anchors are each constructed from a heavy-gauge steel wire loop that is securely welded to the seat bracket. The anchor loops are located where the second row seat back (1) meets the seat cushion (3). The child restraint lower tether anchors cannot be adjusted or repaired and, if ineffective or damaged, they must be replaced as a unit with their respective second row seat brackets.
| WARNING | To avoid serious or fatal injury during and following any seat belt or child restraint anchor service, carefully inspect all seat belts, buckles, mounting hardware, retractors, tether straps, and anchors for proper installation, operation, or damage. Replace any belt that is cut, frayed, or torn. Straighten any belt that is twisted. Tighten any loose fasteners. Replace any belt that has a damaged or ineffective buckle or retractor. Replace any belt that has a bent or damaged latch plate or anchor plate. Replace any child restraint anchor or the unit to which the anchor is integral that has been bent or damaged. Never attempt to repair a seat belt or child restraint component. Always replace damaged or ineffective seat belt and child restraint components with the correct, new and unused replacement parts listed in the DaimlerChrysler Mopar® Parts Catalog. |
