TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Engine Air Tubes | |||
| Turbocharger to Intercooler | 4.7 | 42 | |
| Intercooler to Intake Manifold | 4.7 | 42 | |
| Automatic Belt Tensioner to Mounting Bracket - 3.7L | 41 | 30 | |
| Automatic Belt Tensioner Pulley Bolt - 3.7L | 61 | 45 | |
| Accessory Drive Belt Idler Pulley Bolt - 2.8L Diesel | 53 | 39 | |
| Accessory Drive Belt Tensioner Bolt - 2.8L Diesel | 47.1 | 35 | |
| Viscous Fan Drive to Engine - 3.7L | 95 | 70 | |
| Viscous Fan Drive to Engine - 2.8L Diesel | 149 | 110 | |
| Cooling Fan Support Bolts | 47.1 | 35 | |
| Block Heater Bolt - 3.7L | 2 | 17 | |
| Transmission Oil/Condenser to Radiator Bolts | 11.9 | 105 | |
| Coolant Pressure Bottle to Plenum mounting Bolts -3.7L only | 8.5 | 75 | |
| Electric Fan to Fan Shroud Bolts | 9 | 80 | |
| Fan Blade Assy. to Viscous Drive Bolts - 3.7L/2.8L HD Cooling | 23.7 | 210 | |
| Fan Shroud to Radiator Mounting Bolts | 9 | 80 | |
| Radiator Upper Isolator to Crossmember - Bolts | 10.7 | 95 | |
| Thermostat Housing Bolts | |||
| 2.8L Diesel | 27.5 | 21 | |
| 3.7L | 13 | 115 | |
| Water Pump Bolts | |||
| 3.7L | 54 | 40 | |
| Water Pump Housing Nuts - 2.8L Diesel | 24.4 | 18 |
TORQUE SPECIFICATIONS
