Heating & Air Conditioning - Service Information: Overview Dodge Nitro I

OPERATION

The blend door actuator is connected to the A/C-heater control through the vehicle electrical system by a dedicated two-wire lead and connector of the HVAC wire harness. The blend door actuator can move the blend-air door in two directions. When the A/C-heater control pulls the voltage on one side of the motor connection high and the other connection low, the blend-air door will move in one direction. When the A/C-heater control reverses the polarity of the voltage to the motor, the blend-air door moves in the opposite direction. When the A/C-heater control makes the voltage to both connections high or both connections low, the blend-air door stops and will not move.

The A/C-heater control uses a pulse-count positioning system to monitor the operation and relative position of the blend door actuator and the blend-air door. The A/C-heater control learns the blend-air door stop positions during the actuator calibration procedure and will store a diagnostic trouble code (DTC) for any problems it detects in the blend door actuator circuits. Refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information.

The blend door actuator cannot be adjusted or repaired and must be replaced if found inoperative or damaged.

DESCRIPTION

The heating-A/C system uses a reversible, 12-volt direct current (DC) servo motor which mechanically positions the mode-air door. The mode door actuator (1) is located on the driver side of the HVAC housing.

The mode door actuator is interchangeable with the actuators for the blend-air door and the recirculation-air door. Each actuator is contained within a black molded plastic housing with an integral wire connector receptacle (2) and integral mounting tabs (3) that allow the actuator to be secured to the HVAC housing. The mode door actuator output shaft (4) is connected to the linkage that drives the mode-air door. The mode door actuator does not require mechanical indexing to the mode-air doors, as it is electronically calibrated by the A/C-heater control.

The mode door actuator is connected to the A/C-heater control through the vehicle electrical system by a dedicated two-wire lead and connector of the HVAC wire harness. The mode door actuator can move the floor, defrost/demist and the panel-air doors in two directions. When the A/C-heater control pulls the voltage on one side of the motor connection high and the other connection low, the mode-air doors will move in one direction. When the A/C-heater control reverses the polarity of the voltage to the motor, the mode-air doors moves in the opposite direction. When the A/C-heater control makes the voltage to both connections high or both connections low, the mode-air doors stop and will not move.

The A/C-heater control uses a pulse-count positioning system to monitor the operation and relative position of the mode door actuator and the mode-air doors. The A/C-heater control learns the mode-air doors stop position during the actuator calibration procedure and will store a diagnostic trouble code (DTC) for any problems it detects in the mode door actuator circuits. Refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information.

The mode door actuator cannot be adjusted or repaired and must be replaced if found inoperative or damaged.

The heating-A/C system uses a reversible, 12-volt direct current (DC) servo motor which mechanically positions the recirculation-air door. The recirculation door actuator (1) is located on the side of the HVAC air inlet housing.

The recirculation door actuator is interchangeable with the actuators for the blend-air door and the mode-air door. Each actuator is contained within a black molded plastic housing with an integral wire connector receptacle (2) and integral mounting tabs (3) that allow the actuator to be secured to the HVAC housing. The recirculation door actuator output shaft (4) is directly connected to the pivot shaft lever of the recirculation-air door. The recirculation door actuator does not require mechanical indexing to the recirculation-air door, as it is electronically calibrated by the A/C-heater control.

The recirculation door actuator is connected to the A/C-heater control through the vehicle electrical system by a dedicated two-wire lead and connector of the HVAC wire harness. The recirculation door actuator can move the recirculation-air door in two directions. When the A/C-heater control pulls the voltage on one side of the motor connection high and the other connection low, the recirculation-air door will move in one direction. When the A/C-heater control reverses the polarity of the voltage to the motor, the recirculation-air door moves in the opposite direction. When the A/C-heater control makes the voltage to both connections high or both connections low, the recirculation-air door stops and will not move.

The A/C-heater control uses a pulse-count positioning system to monitor the operation and relative position of the recirculation door actuator and the recirculation-air door. The A/C-heater control learns the recirculation-air door stop positions during the actuator calibration procedure and will store a diagnostic trouble code (DTC) for any problems it detects in the recirculation door actuator circuits. Refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information.

The recirculation door actuator cannot be adjusted or repaired and must be replaced if found inoperative or damaged.

The A/C compressor clutch components provide the means to engage and disengage the A/C compressor from the engine accessory drive belt. When the electromagnetic A/C clutch field coil is energized, it magnetically draws the clutch plate into contact with the clutch pulley and drives the compressor shaft. When the coil is not energized, the pulley freewheels on the clutch hub bearing, which is part of the pulley assembly.

A/C compressor clutch engagement is controlled by the powertrain control module (PCM) or the engine control module (ECM), depending on engine application. When the A/C-heater control is set to any A/C position, it sends a request signal on the CAN-B bus to the totally integrated power module (TIPM), which then transfers the request on the CAN-C Bus to the PCM/ECM, which determines if operating conditions are correct for A/C clutch engagement. When all operating conditions have been met, the PCM/ECM sends a signal on a dedicated hard-wired circuit back to the totally integrated power module (TIPM) to energize the internal A/C clutch high side driver. When energized, the A/C clutch high side driver provides battery current to the A/C clutch field coil.

The A/C clutch control system is diagnosed using a scan tool. Refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information.

The A/C compressor clutch components cannot be adjusted or repaired and must be replaced if found inoperative or damaged.

The blower motor power module is connected to the vehicle electrical system through a dedicated lead and connector. A second lead and connector is connected to the blower motor. The blower motor power module allows the microprocessor-based automatic temperature control (ATC) A/C-heater control to calculate and provide infinitely variable blower motor speeds based upon either manual blower switch input or the ATC programming using a pulse width modulated (PWM) circuit strategy.

The PWM voltage is applied to a comparator circuit which compares the PWM signal voltage to the blower motor feedback voltage. The resulting output drives the power module circuitry, which provides a linear output voltage to change or maintain the desired blower speed.

The blower motor power module is diagnosed using a scan tool. Refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information.

The blower motor power module cannot be adjusted or repaired must be replaced if inoperative or damaged.

The blower motor resistor is connected to the vehicle electrical system through a dedicated wire lead and connector of the HVAC wire harness. The blower motor resistor has multiple resistor circuits, each of which will reduce the current flow through the blower motor to change the blower motor speed.

The blower motor control in the MTC heating-A/C system directs the ground path for the blower motor through the correct resistor circuit to obtain the selected speed. With the blower motor control in the lowest speed position, the ground path for the blower motor is applied through all of the resistor circuits. Each higher speed selected with the blower motor control applies the blower motor ground path through fewer of the resistor circuits, increasing the blower motor speed. When the blower motor control is in the highest speed position, the blower motor resistor is bypassed and the blower motor receives a direct path to ground.

The blower motor resistor cannot be adjusted or repaired and it must be replaced if found inoperative or damaged.

The evaporator temperature sensor monitors the temperature of the conditioned air downstream of the A/C evaporator and supplies an input signal to the A/C-heater control. The A/C-heater control uses the evaporator temperature sensor input signal to optimize A/C system performance and to protect the A/C system from evaporator freezing. The evaporator temperature sensor will change its internal resistance in response to the temperatures it monitors and is connected to the A/C-heater control through sensor ground circuit and a 5-volt reference signal circuit. As the temperature of the A/C evaporator decreases, the internal resistance of the evaporator temperature sensor decreases.

The A/C-heater control uses the monitored voltage reading as an indication of evaporator temperature. The A/C-heater control is programmed to respond to this input by requesting the powertrain control module (PCM) or the engine control module (ECM) (depending on engine application) to cycle the A/C compressor clutch as necessary to optimize A/C system performance and to protect the A/C system from evaporator freezing.

The evaporator temperature sensor is diagnosed using a scan tool. See DIAGNOSIS AND TESTING .

The evaporator temperature sensor cannot be adjusted or repaired and must be replaced if found inoperative or damaged.

The infrared sensor detects thermal radiation emitted by the driver and front seat occupants and surroundings and converts its data into a linear pulse width modulated (PWM) output signal which is read by the automatic temperature control (ATC) A/C-heater control. The ATC A/C-heater control uses the infrared sensor data as one of the inputs necessary to automatically control the interior cabin temperature level. By using thermal radiation (surface temperature) measurement, rather than an air temperature measurement, the ATC heating-A/C system is able to adjust itself to the comfort level as perceived by the front seat occupants. This allows the ATC system to compensate for other ambient conditions affecting comfort levels, such as solar heat gain or evaporative heat loss.

The ATC system logic responds to the infrared sensor message by calculating and adjusting the air flow temperature and air flow rate needed to properly obtain and maintain the selected comfort level temperature of the occupants. The A/C-heater control continually monitors the infrared sensor circuit, and will store diagnostic trouble codes (DTCs) for any problem it detects.

The infrared sensor is diagnosed using a scan tool. Refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information.

The infrared sensor cannot be adjusted or repaired and must be replaced if inoperative or damaged.

The A/C pressure transducer monitors the pressures in the high side of the refrigerant system through its connection to a fitting on the A/C liquid line. The A/C pressure transducer will change its internal resistance in response to the pressures it monitors. The powertrain control module (PCM) or the engine control module (ECM) (depending on engine application) provides a five volt reference signal and a sensor ground to the A/C pressure transducer, then monitors the output voltage of the A/C pressure transducer on a sensor return circuit to determine refrigerant pressure. The PCM/ECM is programmed to respond to the A/C pressure transducer and other sensor inputs by controlling the operation of the A/C compressor clutch and the radiator cooling fan to help optimize A/C system performance and to protect the system components from damage. The PCM/ECM will disengage the A/C compressor clutch when high side pressure rises above 2971 kPa (431 psi) or fall below 206 kPa (30 psi). The A/C pressure transducer input to the PCM/ECM also prevents the A/C compressor clutch from engaging when ambient temperatures are below about 10°C (50°F) due to the pressure/temperature relationship of the refrigerant.

A Schrader-type valve in the A/C discharge line fitting permits the A/C pressure transducer to be removed or installed without disturbing the refrigerant in the A/C system.

The A/C pressure transducer is diagnosed using a scan tool. Refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information.

The A/C pressure transducer cannot be adjusted or repaired and it must be replaced if found inoperative or damaged.

Note. LHD model shown. RHD model similar.

Scheme 9

All models are equipped with a common HVAC housing assembly that combines A/C and heating capabilities into a single unit mounted within the passenger compartment. The HVAC housing assembly consists of three separate housings

1. Air distribution housing - The air distribution housing (1) is mounted to the top of the HVAC housing (2) and contains the heater core, blend-air and mode-air doors and door linkage.
2. Air inlet housing - The air inlet housing (3) is mounted to the passenger side end of the HVAC housing. The air inlet housing contains the recirculation-air door and actuator.
3. HVAC housing - The HVAC housing is mounted to the dash panel behind the instrument panel and contains the A/C evaporator. The HVAC housing consists of a upper and a lower housing that are attached together and has mounting provisions for the air inlet housing, air distribution housing, blower motor and blower motor resistor.

The heating-A/C system is a blend-air type system. The blend-air door controls the amount of conditioned air that is allowed to flow through, or around, the heater core.

The A/C system is designed for the use of a non-CFC, R-134a refrigerant and uses an A/C evaporator to cool and dehumidify the incoming air prior to blending it with the heated air. A temperature control determines the discharge air temperature by operating the temperature control cable, which moves the blend-air door. This allows an almost immediate control of the output air temperature of the system. The mode door cable operates the mode-air doors which direct the flow of the conditioned air out the various air outlets, depending on the mode selected. The recirculation door actuator operates the recirculation-air door which closes off the fresh air intake and recirculates the air already inside the vehicle. The electric recirculation door actuator and the blower motor are connected to the vehicle electrical system by the instrument panel wire harness. The blower motor controls the velocity of air flowing through the HVAC housing assembly by spinning the blower wheel within the HVAC housing at the selected speed by use of the blower motor resistor, which is located in the dash panel in the engine compartment.

The air distribution housing must be removed from the HVAC housing and disassembled for service of the blend-air and mode-air doors. The air inlet housing must be removed from HVAC housing and disassembled for service of the recirculation-air door. The HVAC housing must be removed from the vehicle and disassembled for service of the A/C evaporator.

The blower motor is used to control the velocity of air moving through the HVAC housing by spinning the blower wheel within the HVAC air inlet housing at the selected speed.

The blower motor will operate whenever the ignition switch is in the Run position and the blower motor control is in any position except Off. The blower motor receives battery current through the totally integrated power module (TIPM) whenever the ignition switch is in the Run position.

Blower motor speed is controlled by regulating the ground path through or around the blower motor resistor and through the blower motor control located within the A/C-heater control.

The blower motor can be accessed for service from underneath the instrument panel.

Note. The blower motor is supplied with a 12V feed from the TIPM, through the blower motor resistor, whenever the ignition switch is in the RUN position. Due to an open circuit condition within the blower motor control switch the TIPM is UNABLE to detect an OPEN circuit for the blower motor.

The blower motor control system is diagnosed using a scan tool. Refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information.

The blower motor and blower motor wheel are factory balanced as an assembly and cannot be adjusted or repaired and must be replaced if found inoperative or damaged.

Possible causes of an inoperative blower motor include

1. Open fuse
2. Inoperative blower motor resistor
3. Inoperative blower motor switch
4. Inoperative blower motor
5. Inoperative blower motor circuit wiring or wire harness connectors

When air passes through the fins of the A/C condenser, the high-pressure refrigerant gas within the A/C condenser gives up its heat. The refrigerant then condenses as it leaves the A/C condenser and becomes a high-pressure liquid. The volume of air flowing over the condenser fins is critical to the proper cooling performance of the A/C system. Therefore, it is important that there are no objects placed in front of the radiator grille openings at the front of the vehicle or foreign material on the condenser fins that might obstruct proper air flow. Also, any factory-installed air seals or shrouds must be properly reinstalled following radiator or A/C condenser service.

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line is disconnected. Failure to replace the rubber O-ring seals and metal gaskets could result in a refrigerant system leak.

The A/C condenser has no serviceable parts. The O-ring seals used on the connections are made from a special type of rubber not affected by R-134a refrigerant. The O-ring seals and gaskets must be replaced whenever a refrigerant line is removed from the A/C condenser.

The A/C condenser cannot be repaired and must be replaced if leaking or damaged.

Engine coolant is circulated through the heater hoses to the heater core at all times. As the coolant flows through the heater core, heat is removed from the engine and is transferred to the heater core tubes and fins. Air directed through the heater core picks up the heat from the heater core fins. The blend-air door allows control of the heater output air temperature by regulating the amount of air flowing through the heater core. The blower motor speed controls the volume of air flowing through the HVAC housing.

The heater core cannot be repaired and it must be replaced if inoperative, leaking or damaged.

Refrigerant enters the A/C evaporator from the A/C expansion valve as a low-temperature, low-pressure mixture of liquid and gas. As air flows over the fins of the A/C evaporator, the humidity in the air condenses on the fins, and the heat from the air is absorbed by the refrigerant. Heat absorption causes the refrigerant to boil and vaporize. The refrigerant becomes a low-pressure gas when it leaves the A/C evaporator.

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line or expansion valve is disconnected. Failure to replace the rubber O-ring seals and metal gaskets could result in a refrigerant system leak.

The A/C evaporator has no serviceable parts except for the O-ring seals. The O-ring seals used on the connections are made from a special type of rubber not affected by R-134a refrigerant. The O-ring seals must be replaced whenever the A/C expansion valve is removed from the A/C evaporator.

The A/C evaporator cannot be repaired and must be replaced if leaking or damaged.

The refrigerant oil used in R-134a refrigerant systems is a synthetic-based, PolyAlkylene Glycol (PAG), wax-free lubricant. Mineral-based R-12 refrigerant oils are not compatible with PAG oils, and should never be introduced to an R-134a refrigerant system.

There are different PAG oils available, and each contains a different additive package. Use only refrigerant oil of the same type as recommended to service the refrigerant system ( always refer to the specification tag included with the replacement A/C compressor or the A/C Underhood Specification Label located in the engine compartment).

The A/C compressors used in this vehicle are designed to use VC-46 PAG refrigerant oil. Use only this type of refrigerant oil when servicing the A/C compressor.

After performing any refrigerant recovery or recycling operation, always replenish the refrigerant system with the same amount of the recommended refrigerant oil as was removed. Too little refrigerant oil can cause A/C compressor damage, and too much can reduce A/C system performance.

PAG refrigerant oil is more hygroscopic than mineral oil, and will absorb any moisture it comes into contact with, even moisture in the air. The PAG oil container should always be kept tightly capped until it is ready to be used. After use, recap the oil container immediately to prevent moisture contamination.

The A/C receiver/drier performs a filtering action to prevent foreign material in the refrigerant from contaminating the A/C expansion valve. Refrigerant enters the A/C receiver/drier as a high-pressure, low temperature liquid. Desiccant inside the A/C receiver/drier absorbs any moisture which may have entered and become trapped within the refrigerant system. In addition, during periods of high demand operation of the A/C system, the A/C receiver/drier acts as a reservoir to store surplus refrigerant.

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line is disconnected. Failure to replace the rubber O-ring seals and metal gaskets could result in a refrigerant system leak.

The A/C receiver/drier has no serviceable parts except for the O-ring seals, gaskets and the high side service port valve and cap. The O-ring seals used on the connections are made from a special type of rubber not affected by R-134a refrigerant. The O-ring seals and gaskets must be replaced whenever the A/C receiver/drier is removed.

The A/C receiver/drier cannot be repaired and must be replaced if leaking or damaged, or if an internal failure of the A/C compressor has occurred.

The refrigerant used in this air conditioning system is a HydroFluoroCarbon (HFC), type R-134a. Unlike R-12, which is a ChloroFluoroCarbon (CFC), R-134a refrigerant does not contain ozone-depleting chlorine. R-134a refrigerant is a non-toxic, non-flammable, clear, and colorless liquefied gas.

Even though R-134a does not contain chlorine, it must be reclaimed and recycled just like CFC-type refrigerants. This is because R-134a is a greenhouse gas and can contribute to global warming. See STANDARD PROCEDURE .

R-134a refrigerant is not compatible with R-12 refrigerant in an A/C system. Even a small amount of R-12 refrigerant added to an R-134a refrigerant system will cause A/C compressor failure, refrigerant oil sludge or poor A/C system performance. In addition, the polyalkylene glycol (PAG) synthetic refrigerant oils used in an R-134a refrigerant system are not compatible with the mineral-based refrigerant oils used in an R-12 refrigerant system.

R-134a refrigerant system service ports, service tool couplers and refrigerant dispensing bottles have all been designed with unique fittings to ensure that an R-134a refrigerant system is not accidentally contaminated with the wrong refrigerant (R-12). There are also labels posted in the engine compartment of the vehicle and on the A/C compressor to identify that the A/C system is equipped with R-134a refrigerant.

The A/C expansion valve controls the high-pressure, low temperature liquid refrigerant from the A/C liquid line and converts it into a low-pressure, low-temperature mixture of liquid and gas before it enters the A/C evaporator. A mechanical sensor in the A/C expansion valve monitors the temperature and pressure of the refrigerant leaving the A/C evaporator through the A/C suction line, and adjusts the orifice size at the liquid line port to let the proper amount of refrigerant into the evaporator to meet the vehicle A/C cooling requirements. Controlling the refrigerant flow through the A/C evaporator ensures that none of the refrigerant leaving the A/C evaporator is still in a liquid state, which could damage the A/C compressor.

Note. Replacement of the refrigerant line O-ring seals is required anytime a refrigerant line is disconnected from the expansion valve. Failure to replace the rubber O-ring seals could result in a refrigerant system leak.

The A/C expansion valve is factory calibrated and cannot be adjusted or repaired and must be replaced if inoperative or damaged.

The positive temperature coefficient (PTC) heater unit dissipates 1 kW of electrical power through 4 heating bars. The totally integrated power module (TIPM) operates the two relays for the PTC heater unit. The PTC heater unit is split into two "banks". Each bank is driven separately based on alternator load. This allows for lower in-rush current and optimum battery charging. After a bank has been turned on, another bank can only be turned on 10 seconds after the previous. On average, the PTC banks are not switched more than 25 times for each vehicle start. Electrical power output is between 900-1050 W.

The control system for the PTC heater unit is diagnosed using a scan tool. Prior to replacing a PTC heater unit, check for any diagnostic trouble codes (DTCs) related to the ECM, TIPM and heating-A/C system (refer to HEATING & AIR CONDITIONING - ELECTRICAL DIAGNOSTICS for more information).

The PTC heater unit cannot be adjusted or repaired and, if faulty or damaged it must be replaced.

The two ISO-standard relays (1) used for the electric positive temperature coefficient (PTC) heater system are electromechanical switches that use a low current ASD power input to control the high current fused battery power output to the PTC heater unit. On each relay, the movable, common feed relay contact is held against the fixed, normally closed relay contact by spring pressure. When the electromagnetic relay coil is energized, it draws the movable common feed relay contact away from the fixed, normally closed relay contact and, holds it against the fixed, normally open relay contact. This action allows high current to flow to one or more of the heating elements of the PTC heater.

When the relay coil is de-energized, spring pressure returns the movable relay contact back against the fixed, normally closed contact point. The resistor or diode is connected in parallel with the relay coil, and helps to dissipate voltage spikes and electromagnetic interference that can be generated as the electromagnetic field of the relay coil collapses.

The terminals for the PTC relays are connected to the vehicle electrical system through receptacles in the diesel accessory fuse/relay block. The inputs and outputs of the PTC relays include

1. Terminals (30) receive battery current through a fusible link at all times.
2. Terminals (85) are connected to a ground circuit.
3. Terminals (86) are connected to control circuits of the totally integrated power module (TIPM).
4. Terminals (87) provide fused battery current to the PTC heating elements through the PTC relays only when the PTC relay coil is energized.
5. Terminals (87A) are not connected to any circuit in this application, but provide battery current output only when the PTC relay coil is de-energized.

The two PTC relays cannot be repaired and, if faulty or damaged they must be replaced. Refer to SYSTEM WIRING DIAGRAMS for diagnosis and testing of the ISO-standard relays and for complete TIPM and HVAC wiring diagrams.

Scheme 10

1. Disconnect and isolate the negative battery cable.
2. Open the cover (1) of the diesel accessory fuse/relay block (2) located at the right front of the engine compartment.
3. Remove the positive temperature coefficient (PTC) relays as necessary from the fuse/relay block.
