FRONT IMPACT SENSOR Dodge Magnum I facelift

FRONT IMPACT SENSOR

1. Disconnect and isolate the battery negative cable. WARNING: Wait two minutes for the airbag system reserve capacitor to discharge before beginning any airbag system or component service. Failure to do so may result in accidental airbag deployment, personal injury or death. NOTE: If replacing the left front impact sensor, the air intake system needs to be removed.
2. Disconnect the electrical connector (3).
3. Remove the two mounting screws (2).

Scheme 69

1. Disconnect and isolate the battery negative cable. WARNING: Wait two minutes for the airbag system reserve capacitor to discharge before beginning any airbag system or component service. Failure to do so may result in accidental airbag deployment, personal injury or death.
2. Remove the B-pillar trim panel. Refer to «REMOVAL»(ref-304464-S27391754552008111000000) .
3. Disconnect the electrical connector (1).
4. Remove the two retaining screws (2).

Scheme 70

1. Disconnect and isolate the battery negative cable. WARNING: Wait two minutes for the airbag system reserve capacitor to discharge before beginning any airbag system or component service. Failure to do so may result in accidental airbag deployment, personal injury or death.
2. Remove the C-pillar trim panel. Refer to «REMOVAL»(ref-304464-S07254381522008111000000) .
3. Disconnect the electrical connector (3).
4. Remove the two retaining screws (2).

1. Position the front impact sensor in the correct mounting location and install the two mounting screws (2). Torque screws (2) to 7 N.m (62 in. lbs.).
2. Connect the electrical connector (3).

Note. If replacing the left front impact sensor, the air intake system needs to be installed.
